ال Schneider LC1 series contactors are classic products in the field of industrial control, widely used in motor control, power distribution, and automation systems. The following is a detailed analysis of this series:

1. Product Positioning and Core Featuresقواطع دوائر التيار المستمر من سلسلة Chint NB1-63DC Price

The LC1 series belongs to Schneider Electric’s TeSys family, renowned for its high reliability and modular design. Its core advantages include:

1. Long-life Design: With a mechanical life of up to 20 million operations and an electrical life of 2 مليون عملية, it is suitable for frequent operation scenarios.
2. Wide Voltage Adaptability: The coil control voltage ranges from 70% ل 120% من القيمة المقدرة, compatible with 50Hz/60Hz universal coils for global use. Schneider Circuit Breakers Price
3. Harsh Environment Adaptation: Treated with “TH” حماية, it ensures stable operation in humid and hot environments, with a protection class of IP2X (preventing direct finger contact).
4. Modular Expansion: Supports quick installation of accessories such as auxiliary contacts, time-delay modules, and mechanical interlocks, flexibly adapting to complex control needs like star-delta starters and reversible contactors.
5. Main Models and Technical ParametersSchneider-MCCB-NSX250F-4P-250A

The LC1 series includes multiple sub-series covering different current ratings and application scenarios:

LC1-D Series Schneider low-voltage molded case circuit breaker :

النطاق الحالي: 9A–620A (AC-3 category), with a maximum power of 335kW at 380V.

الجهد لفائف: Supports various AC/DC voltages such as 24V, 36V, and 220V.

Wiring Technology: Models 40–65A adopt Everlink® patented terminals to ensure wiring firmness.

الشهادات: م, سي سي سي, أول, وكالة الفضاء الكندية, إلخ. Some models are certified by classification societies (على سبيل المثال, DNV, BV).

LC1-E Series:

النطاق الحالي: 6A–95A (extended to 630A), suitable for small and medium-power motor control.

LC1-G Series:

Large-scale Models: Such as LC1G205-KUEC (205أ) and LC1G620-EHEC (620أ), featuring electronic coils and self-diagnosis functions to replace the old LC1-F series.

Intelligent Features: Built-in LED diagnostic lights, supporting contact wear monitoring and over/under-voltage warnings.

ثالثا. Application Fields and Typical Scenarios

1. الأتمتة الصناعية:

– Motor control (مضخات, المشجعين, الضواغط).

– Capacitor bank switching and electric heating equipment control.

2. Infrastructure:

– New energy fields (wind turbines, photovoltaic inverters).

– Port machinery and lifting equipment.

3. Building Electrical Systems:

– Elevator control systems.

– Centralized control of lighting and air conditioning systems.

1. Supporting Products and Selection Recommendations
2. Thermal Relays:

– Paired with LRD series thermal relays to form electromagnetic starters, providing overload protection.

2. Auxiliary Contact Modules:

– LADN11C (1 لا + 1 نورث كارولاينا), LAG8N series (expandable to up to 4 sets of contacts).

3. اختيار النقاط الرئيسية:

المطابقة الحالية: Select contactors based on the motor’s rated current, leaving a 20% margin under AC-3 category.

الجهد لفائف: Prioritize voltages compatible with the control system (على سبيل المثال, 24V output from PLC).

الظروف البيئية: Choose “TH”-protected models for humid/hot environments, and confirm certification scope for high-altitude scenarios.

1. Upgrades and Alternative Solutions
2. TeSys D Series:

– As an upgrade to LC1-D, it offers a wider current range (9–630A) and higher breaking capacity, compatible with original accessories.

2. TeSys Giga Series:

– A new generation of high-power contactors supporting predictive maintenance and quick contact replacement, replacing the LC1-F series.

3. Compatibility Notes:

– LC1-D and TeSys D are compatible in installation dimensions and wiring methods, allowing direct replacement.

1. Installation and Certifications
2. طرق التثبيت:

– Standard 35mm rail mounting, supporting spring terminals, screws, or Everlink® quick wiring.

2. Certification Coverage:

– Complies with standards such as IEC 60947 و غيغابايت 14048; some models are ATEX explosion-proof certified.

سابعا. Price and Supply

Price Range:

– Small models (على سبيل المثال, LC1-D09M7C) cost about 370 يوان, while large models (على سبيل المثال, LC1-G620) can reach thousands of RMB.

Supply Channels:

– Available for purchase through Schneider’s authorized dealers via WhatsApp: 0086-13811355435.

خاتمة

With high reliability, modular design, وتطبيق واسع, Schneider’s LC1 series contactors are the first choice for industrial control. Users can select LC1-D (universal), LC1-E (small/medium power), or LC1-G (high-power intelligent) based on specific needs, and combine them with supporting accessories for efficient control. For upgrades, the TeSys D and Giga series offer more advanced functions and compatibility. It is recommended to refer to Schneider’s official technical manuals or contact technical support (hotline: 400-810-1315) for precise solutions during selection.
