Schneider RXZE1M4C is a plug-in relay socket from the Harmony RXZ series, designed specifically for the RXM series of interface relays. It features screw clamp terminals with a mixed contact arrangement, suitable for industrial automation control applications.
- Model Code Explanation
| Code Part | 의미 |
| RXZ | Product family: Harmony RXZ plug‑in relay socket |
| E1 | Terminal type: screw clamp terminals (E = screw, 1 = standard) |
| 중 | Contact arrangement: mixed |
| 4기음 | Compatible relay: RXM relay with 4 changeover contacts (4 C/O) |
- 주요 기술 사양
| 매개변수 | 값 |
| 정격전류 | 7에이 (Ith conventional free‑air thermal current) |
| 정격전압 | 250뷔와 (IEC 표준) |
| Compatible relays | RXM2LB (2 C/O) and RXM4LB (4 C/O) plug‑in relays |
| Number of terminals | 14‑pin (14‑hole slim socket) |
| 설치 | 35mm symmetrical DIN‑rail clip‑on or panel screw mounting |
| 치수 | 29mm 폭, standard relay socket size |
| Wiring type | Screw clamp terminals for easy wiring and maintenance |
| Contact arrangement | Mixed contact terminal arrangement |
| Minimum order quantity | 10 pieces per batch |
- Operating Environment
Operating temperature: -25°C ~ +55°C
Storage temperature: -40°C to +85°C
상대습도: ≤95%, 비응축
Ingress protection | IP20 (IEC 60529)
응용: Industrial automation control systems, PLC cabinets, motor control centers, machine tools, production line control, and other applications requiring plug-in relay connections
- Comparison of Related Models in the Same Series
| 모델 | Compatible Contacts | 터미널 유형 | 특징 |
| RXZE1M2C | 2 C/O (2 아니요 + 2 NC) | Screw clamp | For RXM2 series, 22.5mm 폭 |
| RXZE1M4C | 4 C/O (4 아니요 + 4 NC) | Screw clamp | For RXM4 series, 29mm 폭 (this model) |
| RXZE2M4C | 4 C/O | Spring clamp | Tool‑free wiring, fast installation |
| RXZE1M4F | 4 C/O | Screw clamp | With LED indicator for status monitoring |
- Alternative Models and Brand Cross-Reference
Equivalent Alternatives from Schneider
RXZE2M4C: Spring clamp terminal version for faster installation
RXZE1M4F: Version with LED indicator for visual status monitoring
Alternative Models from Other Brands
| 상표 | 대체 모델 | 호환성 |
| 지멘스 | 3RS1700‑1GW00 | For 3RT series relays, 7A/250VAC |
| 씨줄 | CR‑M024DC2 | For CR‑M series relays, 7A/250VAC |
| 옴론 | P2RF‑08 | For MY series relays, 10A/250VAC |
| Chinese Alternative | JZX‑22F Socket | Universal 14‑pin socket, 7A/250VAC |
- Installation and Usage Notes
- 설치: Can be clipped directly onto 35mm DIN rail or fixed to a panel with screws
- 배선: Screw clamp terminals; recommended torque 0.8–1.2 N·m
- 호환성: Only for RXM series plug-in interface relays, especially RXM2LB and RXM4LB
- 유지: Plug-in design allows easy relay replacement without rewiring
- 안전: Disconnect power before wiring to avoid electric shock
- Ordering Information
Official order code: RXZE1M4C
Packing: 10 pieces per box
인증: CE, UL, CSA and other international certifications
Schneider RXZE1M4C Socket
- Full List of Compatible RXM Relays
The RXZE1M4C is a standard 14-pin socket compatible with the entire Schneider RXM range of 2-contact (2CO) and 4-contact (4CO) miniature interface relays. Full list below.
1.1 4 Changeover Contacts (4CO, 4 아니요 + 4 NC, fully compatible)
DC 코일
RXM4LB1BD DC24V
RXM4LB2BD DC24V
RXM4LB1B7 DC12V
RXM4LB1JD DC48V
RXM4LB1MD DC110V
RXM4CB1BD DC24V (economy version)
RXM4AB1BD DC24V (표준 버전)
AC 코일
RXM4LB1P7 AC230V
RXM4LB1B7 AC24V
RXM4LB1F7 AC110V
RXM4CB1P7 AC230V (economy version)
RXM4AB1P7 AC230V (표준 버전)
1.2 2 Changeover Contacts (2CO, 2 아니요 + 2 NC, 호환 가능)
DC 코일
RXM2LB1BD DC24V
RXM2LB2BD DC24V
RXM2LB1B7 DC12V
RXM2LB1JD DC48V
RXM2CB1BD DC24V
AC 코일
RXM2LB1P7 AC230V
RXM2LB1B7 AC24V
RXM2LB1F7 AC110V
RXM2CB1P7 AC230V
- 14-Pin Terminal Function Assignment for RXZE1M4C
Socket terminal numbers: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14
| Terminal No. | 기능 | 설명 |
| 13, 14 | Coil supply | Connect relay operating voltage (DC+/DC– or AC/L/AC/N) |
| 1 | Common COM1 | Common for 1st contact group |
| 3 | NO1 (평상시 열림) | Conducts with 1 when coil is energized |
| 5 | NC1 (평상시 닫힘) | Breaks with 1 when coil is energized |
| 6 | Common COM2 | Common for 2nd contact group |
| 8 | NO2 | Conducts with 6 when coil is energized |
| 12 | NC2 | Breaks with 6 when coil is energized |
| 9 | Common COM3 | Common for 3rd contact group |
| 11 | NO3 | Conducts with 9 when coil is energized |
| 4 | NC3 | Breaks with 9 when coil is energized |
| 2 | Common COM4 | Common for 4th contact group |
| 7 | NO4 | Conducts with 2 when coil is energized |
| 10 | NC4 | Breaks with 2 when coil is energized |
- Quick Operating Instructions
- With 4-contact relay (RXM4xx): All 14 terminals active; 4 contact groups fully functional.
- With 2-contact relay (RXM2xx): Only terminals 1, 3, 5 그리고 6, 8, 12 used; others unused.
- Coil connection: 13(–), 14(+) for DC; 13, 14 (non-polarized) for AC.
Complete List of Schneider RXM Relays and Global Brand Cross-Reference
- RXM Series Classification and Naming Rules
1.1 Series Classification
Schneider RXM series are Zelio Harmony plug-in miniature interface relays, divided into three main series by function and features:
| 시리즈 | 주요 특징 | Contact Rating | Test Button | Indication |
| RXM‑AB | 기준, with locking test button | 2C/O: 12에이 | ✓ Locking test button | 기계 + optional LED |
| 3C/O: 10에이 | ||||
| 4C/O: 6에이 | ||||
| RXM‑LB | Economy, no test button | 2C/O: 10에이 | ✗ No test button | 기계 + optional LED |
| 4C/O: 6에이 | ||||
| RXM‑CB | 콤팩트, simplified design | 2C/O: 10에이 | ✗ No test button | Mechanical only |
| 4C/O: 6에이 |
1.2 Model Naming Structure
Number of contacts: 2 = 2C/O, 3 = 3C/O, 4 = 4C/O
시리즈: AB / LB / CB
LED: 1 = no LED, 2 = with LED, 3 = with LED + surge suppression
Coil voltage: BD=DC24V, B7=AC24V, P7=AC230V, F7=AC110V, JD=DC48V, E7=AC48V, MD=DC110V, FD=DC125V, CD=DC220V, 등.
- Complete List of RXM Relays
2.1 RXM-AB Series (기준, with test button)
2C/O (2 아니요 + 2 NC, 12에이)
RXM2AB1B7 (AC24V, no LED)
RXM2AB1BD (DC24V, no LED)
RXM2AB1P7 (AC230V, no LED)
RXM2AB1F7 (AC110V, no LED)
RXM2AB1E7 (AC48V, no LED)
RXM2AB1ED (DC48V, no LED)
RXM2AB1JD (DC48V, no LED)
RXM2AB1MD (DC110V, no LED)
RXM2AB1FD (DC125V, no LED)
RXM2AB1CD (DC220V, no LED)
RXM2AB2B7 (AC24V, with LED)
RXM2AB2BD (DC24V, with LED)
RXM2AB2P7 (AC230V, with LED)
RXM2AB2F7 (AC110V, with LED)
RXM2AB2E7 (AC48V, with LED)
RXM2AB2ED (DC48V, with LED)
RXM2AB2JD (DC48V, with LED)
RXM2AB2MD (DC110V, with LED)
RXM2AB2FD (DC125V, with LED)
RXM2AB2CD (DC220V, with LED)
RXM2AB3BD (DC24V, with LED + surge suppression)
RXM2AB3P7 (AC230V, with LED + surge suppression)
3C/O (3 아니요 + 3 NC, 10에이)
RXM3AB1B7 (AC24V, no LED)
RXM3AB1BD (DC24V, no LED)
RXM3AB1P7 (AC230V, no LED)
RXM3AB2B7 (AC24V, with LED)
RXM3AB2BD (DC24V, with LED)
RXM3AB2P7 (AC230V, with LED)
4C/O (4 아니요 + 4 NC, 6에이)
RXM4AB1B7 (AC24V, no LED)
RXM4AB1BD (DC24V, no LED)
RXM4AB1P7 (AC230V, no LED)
RXM4AB1F7 (AC110V, no LED)
RXM4AB1E7 (AC48V, no LED)
RXM4AB1JD (DC48V, no LED)
RXM4AB2B7 (AC24V, with LED)
RXM4AB2BD (DC24V, with LED)
RXM4AB2P7 (AC230V, with LED)
RXM4AB2F7 (AC110V, with LED)
RXM4AB3BD (DC24V, with LED + surge suppression)
RXM4AB3P7 (AC230V, with LED + surge suppression)
2.2 RXM-LB Series (Economy, no test button)
2C/O (2 아니요 + 2 NC, 10에이)
RXM2LB1B7 (AC24V, no LED)
RXM2LB1BD (DC24V, no LED)
RXM2LB1P7 (AC230V, no LED)
RXM2LB1F7 (AC110V, no LED)
RXM2LB2B7 (AC24V, with LED)
RXM2LB2BD (DC24V, with LED)
RXM2LB2P7 (AC230V, with LED)
RXM2LB2F7 (AC110V, with LED)
4C/O (4 아니요 + 4 NC, 6에이)
RXM4LB1B7 (AC24V, no LED)
RXM4LB1BD (DC24V, no LED)
RXM4LB1P7 (AC230V, no LED)
RXM4LB1F7 (AC110V, no LED)
RXM4LB2B7 (AC24V, with LED)
RXM4LB2BD (DC24V, with LED)
RXM4LB2P7 (AC230V, with LED)
RXM4LB2F7 (AC110V, with LED)
2.3 RXM-CB Series (콤팩트)
2C/O (2 아니요 + 2 NC, 10에이)
RXM2CB1B7 (AC24V, no LED)
RXM2CB1BD (DC24V, no LED)
RXM2CB1P7 (AC230V, no LED)
RXM2CB2B7 (AC24V, with LED)
RXM2CB2BD (DC24V, with LED)
4C/O (4 아니요 + 4 NC, 6에이)
RXM4CB1B7 (AC24V, no LED)
RXM4CB1BD (DC24V, no LED)
RXM4CB1P7 (AC230V, no LED)
RXM4CB2BD (DC24V, with LED)
RXM4CB2P7 (AC230V, with LED)
2.4 특수 모델 (서지 억제 / Special Voltage)
RXM2AB3BD (DC24V, with LED + surge suppression)
RXM4AB3P7 (AC230V, with LED + surge suppression)
RXM2AB1TQ series (compliant with railway standard EN50155)
RXM4AB1TQ series (compliant with railway standard EN50155)
- Global Brand Cross-Reference Order Codes
3.1 2C/O (DC24V, with LED)
| 슈나이더 | 지멘스 | 씨줄 | 옴론 | Weidmüller | 피닉스컨택트 |
| RXM2AB2BD | 3RT2016‑1BB01 | CR‑M024DC2 | MY2NJ‑24VDC | DRM57024 | REL‑MR‑24DC/21HC |
| 3RH1122‑1BB40 | P2RF‑08 | ||||
| RXM2LB2BD | 3RT2015‑1BB01 | CR‑M024DC0 | MY2N‑J‑24VDC | DRM27024 | REL‑MR‑24DC/21 |
| 3RH1122‑1BB00 |
3.2 4C/O (DC24V, with LED)
| 슈나이더 | 지멘스 | 씨줄 | 옴론 | Weidmüller | 피닉스컨택트 |
| RXM4AB2BD | 3RT2026‑1BB01 | CR‑M024DC4 | MY4NJ‑24VDC | DRM57024‑4 | REL‑MR‑24DC/41HC |
| 3RH1144‑1BB40 | P2RF‑12 | ||||
| RXM4LB2BD | 3RT2025‑1BB01 | CR‑M024DC3 | MY4N‑J‑24VDC | DRM27024‑4 | REL‑MR‑24DC/41 |
| 3RH1144‑1BB00 |
3.3 2C/O (AC230V, with LED)
| 슈나이더 | 지멘스 | 씨줄 | 옴론 | Weidmüller | 피닉스컨택트 |
| RXM2AB2P7 | 3RT2016‑1AP01 | CR‑M230AC2 | MY2NJ‑230VAC | DRM570230 | REL‑MR‑230AC/21HC |
| 3RH1122‑1AP40 | |||||
| RXM2LB2P7 | 3RT2015‑1AP01 | CR‑M230AC0 | MY2N‑J‑230VAC | DRM270230 | REL‑MR‑230AC/21 |
| 3RH1122‑1AP00 |
3.4 4C/O (AC230V, with LED)
| 슈나이더 | 지멘스 | 씨줄 | 옴론 | Weidmüller | 피닉스컨택트 |
| RXM4AB2P7 | 3RT2026‑1AP01 | CR‑M230AC4 | MY4NJ‑230VAC | DRM570230‑4 | REL‑MR‑230AC/41HC |
| 3RH1144‑1AP40 | |||||
| RXM4LB2P7 | 3RT2025‑1AP01 | CR‑M230AC3 | MY4N‑J‑230VAC | DRM270230‑4 | REL‑MR‑230AC/41 |
| 3RH1144‑1AP00 |
3.5 Socket Compatibility Reference
Schneider RXM series universally fit standard 14-pin sockets, including:
Original Schneider: RXZE1M2C (2C/O), RXZE1M4C (4C/O), RXZE2M4C (spring terminal)
Universal sockets: Any 14-pin plug-in socket complying with IEC 60669-1
- Selection and Replacement Guidelines
- Contact rating matching: Ensure replacement contact rated current ≥ original; distinguish AC/DC loads
- Coil voltage consistency: Strictly match DC/AC type and voltage to avoid coil burnout
- Functional equivalence: Select equivalents with matching LED, 테스트 버튼, or surge suppression
- Mounting dimensions: RXM series are standard 22.5mm (2C/O) or 29mm (4C/O) 너비; replacements must match for DIN-rail fit
- Certification matching: For critical applications, verify equivalent certifications (CE, UL, CSA, 등.)
- Ordering and Packaging Information
Standard packing: 10 pieces per box; some models available in 50-piece bulk boxes
Official order code: Same as model number, 예를 들어. RXM2AB2BD, RXM4LB2P7
Sockets ordered separately: Original Schneider RXZ series or compatible brand sockets recommended
