Siemens model number 6SL3210-1KE23-2UF1

The product with the Siemens model number 6SL3210-1KE23-2UF1 belongs to the SINAMICS G120C Series of integrated frequency converters, which are primarily used for speed control and energy-efficient operation of three-phase AC motors. The following is a summary of the key information:

1. 핵심 기술 매개변수
2. Power and Voltage

– Nominal Power: 15.0 kW

– Input Voltage: 380-480다섯 (±10%/-20%), three-phase alternating current

– Overload Capacity: 150% overload for 3 초.

2. Interfaces and Communication

– Integrated PROFINET interface supporting industrial Ethernet communication.

– I/O Configuration: 6 digital inputs (DI), 2 digital outputs (DO), 1 analog input (일체 포함), 1 analog output (에).

– For RS485 or DP interfaces, other models need to be selected (예를 들어, 6SL3210-1KE23-2UB1 supports USS/MODBUS, and 6SL3210-1KE23-2UP1 supports DP).

3. 물리적 특성:

– 보호 등급: IP20 (suitable for installation inside control cabinets).

– 치수: 295×140×225.4 mm (height × width × depth), supports side-by-side installation without derating.

– Built-in filter complies with EN 61800-3 C2 standard (Class A).

1. 응용 시나리오

Industrial Manufacturing: Used for motor control of equipment such as conveyor belts, mixers, and extruders.

Building and Building Automation: Suitable for energy-efficient speed regulation of elevators, air conditioning systems, and water pumps.

Energy Management: Optimizes the operational efficiency of fans and compressors, reducing energy consumption.

III. Supply and Procurement

Spot Supply: Inventory is still available in the market in 2025. 예를 들어, Hebei China Electric can deliver within 3 날, with a total supply of 1,000 단위.

1. Installation and Commissioning
2. 설치 요점

– Shielding plates and EMC connection strips need to be installed to ensure electromagnetic compatibility. The built-in filter model should be selected according to actual requirements.

– Power and motor connection terminals are pluggable, and the radiator fan can be easily replaced.

1. Common Issues and Maintenance
2. Fault Handling

Overvoltage Alarm (예를 들어, F0002): Check if the power supply voltage is within the allowable range (P0210), adjust the ramp-down time (P1121), or add a braking unit.

Communication Interface Issues: Select the correct model according to requirements (예를 들어, 프로피넷, DP, or RS485) to avoid compatibility issues caused by mixing.

2. Maintenance Recommendations

– Regularly inspect the power supply board and power modules to prevent strong electrical interference with weak electrical circuits.

– Ensure good heat dissipation, with the ambient temperature not exceeding 55°C (PROFINET models support side-by-side installation).

1. Alternative Models and Upgrades

Communication Requirement Changes: For a DP interface, select 6SL3210-1KE23-2UP1; for RS485, select 6SL3210-1KE23-2UB1.

Function Expansion: For higher performance, consider the SINAMICS G120 modular frequency converter, which supports flexible configuration of control units and power modules.

Ⅶ. Official Support and Documentation

Technical Documentation: Detailed user manuals and parameter setting guides are available on the Siemens official website and can be obtained by searching for “6SL3210-1KE23-2UF1”.

After-Sales Service: Agents and the Siemens technical support team can provide installation guidance, firmware updates, and fault troubleshooting services.

It is recommended to confirm specific application requirements (such as communication protocols and environmental conditions) before procurement and contact the supplier for the latest quotations and technical support.

Technical Specifications

1. 기본 매개변수

모델: 6SL3210-1KE23-2UF1

시리즈: SINAMICS G120C Integrated Frequency Converter

Power Range: 15.0 kW

Supply Voltage: 3AC 380-480V (-20%/+10%)

Frequency Range: 47-63 헤르츠

Control Type: 벡터 제어 (VC) / Vector Control with Encoder (VC+PG) / V/f Control

보호 등급: IP20

Cooling Method: Forced Air Cooling

치수: A4 (295 엑스 140 엑스 225.4 mm)

2. Performance Indicators

Overload Capacity:

– Standard Type: 150% 정격 전류의 60 초

– Enhanced Type: 180% 정격 전류의 3 초

Switching Frequency: 2-16 kHz (기본 8 kHz)

Speed Regulation Range:

– VC Control: 1:100

– VC+PG Control: 1:1000

Speed Accuracy:

– VC Control: ±0.5%

– VC+PG Control: ±0.01%

3. Input/Output Interfaces

Digital Inputs: 6 채널 (default DI1-DI6), configurable as NPN/PNP

Digital Outputs: 2 채널 (DO1-DO2), relay outputs

아날로그 입력: 1 channel (AI1: 0-10V/0-20mA)

아날로그 출력: 1 channel (AO1: 0-20mA/0-10V)

Encoder Interface: Supports SIN/COS, TTL encoders

Communication Interfaces:

– Integrated PROFINET interface (RT/IRT)

– Optional CBP2 board (Profibus DP) or other communication expansion boards

4. 전원 공급 장치 및 전력 소비

Input Power:

– Main Power: 3AC 380-480V, 50/60헤르츠

– Control Power: 24VDC (built-in)

Power Consumption: Approximately 150W

Efficiency: ≥98%

5. 환경 조건

작동 온도: -10°C to +50°C (derating required above 40°C)

보관 온도: -25°C ~ +70°C

습기: ≤95%, non-condensing

고도: ≤1000m (derating required above)

오염도: 수업 2

Functional Characteristics

1. 제어 기능

Control Modes:

– 벡터 제어 (VC)

– Vector Control with Encoder (VC+PG)

– V/f Control (linear/square)

Speed Control: Supports PID control, closed-loop speed control

Torque Control: Supports Direct Torque Control (DTC)

Positioning Function: Simple positioning (up to 16 position points)

2. 보호 기능

과부하 보호: Electronic thermal overload protection (PTC/KTY84 optional)

Overvoltage/Undervoltage Protection: Automatic Voltage Regulation (AVR)

Short Circuit Protection: Dual hardware and software protection

Ground Fault Protection: Built-in ground fault detection

Motor Protection: Stalling protection, stall prevention, underload protection

3. Communication Functions

프로피넷:

– Supports RT/IRT real-time communication

– Supports SINAMICS drive basic parameter file (GSDML)

– Allows parameter setting and monitoring via PROFINET

Expanded Communication:

– Supports Profibus DP via CBP2 board

– Supports Modbus TCP via CM AC board

– Supports Ethernet/IP, CANopen, 등. via other expansion boards

4. Operation and Monitoring

조작 패널:

– Basic Operation Panel BOP-2 (with 7-segment LED display)

– Advanced Operation Panel AOP-30 (with LCD graphic display)

매개변수 설정:

– Set via the operation panel

– Use STARTER or StartDrive software via PC

– Remote setting via communication interface

Monitoring Functions:

– Real-time monitoring of parameters such as current, voltage, 빈도, 그리고 힘

– Fault diagnosis and alarm recording (stores up to 100 fault messages)

5. Special Functions

Energy-Saving Mode: Automatically optimizes the V/f curve to reduce no-load losses

Quick Commissioning Wizard: Simplifies the initial setup process

Ramp Function Generator: Supports S-curve and multi-speed control

Braking Function: Built-in braking chopper, supports dynamic braking

Safety Functions:

– Safe Torque Off (STO) – Complies with SIL3/PLe

– Optional safety expansion board supports SS1, SS2, SBC, 등.

6. Application Macros

– Built-in multiple application macros to simplify parameter setting:

– Pump and Fan Macro

– Conveyor Belt Macro

– Hoist Macro

– Compressor Macro

– Custom Macro

7. 설치 및 유지 관리

설치 방법: Wall-mounted installation

Side-by-Side Installation: Supports installation without spacing (requires EMC shielding plate)

모듈형 디자인:

– Separate control unit and power unit

– Easy replacement of vulnerable parts (팬, capacitors)

Firmware Upgrade: Supports firmware updates via USB or communication interface

일반적인 응용 분야

– Energy-efficient control of pump and fan loads

– Speed control of conveyor belts and conveying systems

– Precise control of mixers and mixing equipment

– Constant torque control of extruders and compressors

– Speed regulation of elevators and lifting equipment
