ب&R 3DI476.6 وحدة الإدخال الرقمي

Basic Model Information

نموذج: 3DI476.6

سلسلة المنتجات: ب&نظام آر 2005 Automation System (عفا عليه الزمن)

Alternative Platform: X20 Series Digital Input Modules

2. المواصفات الفنية الأساسية

3. Terminal Definition Overview

ال 16 channels are divided into two groups:

Group1: DI0～DI7

Group2: DI8～DI15

Each group has an independent COM terminal, supporting wiring for NPN (sinking) / بنب (sourcing) أجهزة الاستشعار.

4. Phase-out & Upgrade Replacement Solution

⚠️ 3DI476.6 has been officially discontinued by the manufacturer. No new original units available; only surplus stock or used modules are on the market.

Recommended Functional Replacement on X20 Platform

X20DI4371 (16من, 24VDC, group isolation, functional equivalent to 3DI476.6)

الاختلافات الرئيسية:

1. Hardware racks are incompatible: X20 modules cannot be plugged directly into System 2005 رفوف. Full controller platform upgrade is required (وحدة المعالجة المركزية + entire backplane).
2. Program: Project migration and IO address remapping are needed; ب&R Automation Studio supports variable migration.

Spare Part Temporary Solution

Only surplus new stock or refurbished modules can be sourced. Verify production year and intact terminal blocks before purchase.

5. سيناريوهات التطبيق النموذجية

Digital signal acquisition for machine tools, آلات التعبئة والتغليف, material handling conveyors, بلاستيك & rubber equipment: proximity sensors, photoelectric sensors, pushbuttons, limit switches, relay contact signals.

6. Common Troubleshooting Guidelines
7. No signal on channel: Measure 24V supply and COM wiring; verify sensor type (نبن/بنب) matches COM wiring configuration.
8. Signal flickering / false triggering: Apply cable shielding, reduce line voltage drop, adjust input filter time parameters in Automation Studio.
9. No channel faults reported but all channels inactive: Check backplane power supply and ensure module bus latches are fully engaged.
10. Model Selection Pitfalls

❌ X20 modules cannot be inserted into System 2005 racks directly;

❌ Evaluate overall CPU upgrade costs for large-scale renovation of legacy machines; prioritize spare parts stocking for small equipment;

✅ Do not select 3DI476.6 for new projects; uniformly adopt X20 series.

Complete Matching Module List for B&R 3DI476.6 (System2005 Platform)

All modules must be installed on System2005 backplanes (3BPxxxx). Hardware is not compatible with X20 series. The whole product line is obsolete; only surplus or refurbished spare parts available.

1. Basic System Hardware (Mandatory for Rack Assembly)

(1) Power Supply Modules (Backplane Power)

3PS465.9: 24VDC 50W, with expansion interface

3PS477.9: 24VDC 50W, supports remote expansion rack 3EX350

(2) Backplane Base (Module Carrier)

3BP155.4 / 3BP155.41: 6-slot backplane (41 version with battery compartment)

3BP152.4 / 3BP152.41: 9-slot backplane

3BP151.4 / 3BP151.41: 12-slot backplane

3BP150.4 / 3BP150.41: 15-slot backplane

(3) CPU Controller Modules

3CP260.60-1

3CP340.60-2

3CP360.60-1

3CP380.60-1

3CP382.60-1

2. Series Digital I/O Modules (Directly Mixable with 3DI476.6)

الإدخال الرقمي (من)

3DI475.6: 16DI 24VDC, 12ms filter

3DI476.6: 16DI 24VDC, 1.2ms high-speed version

3DI477.6: 32من

3DI486.6 / 3DI486.6-1: 32DI high-speed

الإخراج الرقمي (يفعل)

3DO476.6: 16-channel transistor output 24VDC

3DO760.6: 8-channel relay output

Mixed DI+DO Module

3DM476.6: 8من + 8يفعل, same hardware dimension (2 فتحات) as 3DI476.6

3. Analog Expansion Modules

3AI755.6: 8-مدخلات القناة التناظرية

3AO755.6: 8-channel analog output

3AM050.6 / 3AM051.6 / 3AM374.6: Mixed AI/AO modules

4. تواصل / Interface Modules (aPCI slot, mounted on CPU)

3IF681.86: إيثرنت + RS232

3IF686.9: POWERLINK

3IF761.9: بروفيبوس-DP

3IF722.9: CAN + RS485

3IF672.9: CAN + RS232

5. Motion Control Modules (Servo & التشفير)

3NC150.6: Pulse positioning / encoder counter module

3EX350.9: Remote I/O expansion master (multi-rack expansion)

6. Key Matching Accessories

Plug-in spring-cage terminal block: Matching terminal assembly for 3DI476.6

0AC201.9: Backplane backup lithium battery (prevents data loss during power failure)

7. Quick Selection Comparison
8. 3DI475.6 vs 3DI476.6

Same channel quantity; the only difference lies in input filter time:

3DI475.6: 12آنسة (for general signals)

3DI476.6: 1.2آنسة (for high-speed counting & high-frequency proximity sensor signals)

2. Slot Occupancy: 3DI476.6 occupies 2 backplane slots, reserve sufficient slots when selecting backplanes.
