ZCKL1H7 is a metal housing limit switch body from Schneider Electric (Telemecanique Sensors) OsiSense XC / XCKL series, featuring 2 أقطاب, 1NO+1NC, snap action, and IP65 protection rating.
- Model Breakdown
ZCK: Limit switch body series (شنايدر)
ل: XCKL standard body
1: Body type (fixed)
H7: 1/2″ NPT cable entry, silver contacts, screw terminals
- Key Specifications
| غرض | مواصفة |
| تكوين الاتصال | 1 لا + 1 نورث كارولاينا (القطب المزدوج) |
| Operating Type | Snap Action |
| Contact Material | Silver-plated |
| التصنيف الحالي | AC 240V / 10أ; DC 250V / 0.27أ |
| درجة الحماية | IP65 (dustproof & waterproof) |
| مواد الإسكان | Metal (Zamak) |
| طريقة الأسلاك | Screw clamp terminals |
| Cable Entry | 1/2″ NPT thread |
| درجة حرارة التشغيل | -25°C ~ +70°C |
| أبعاد | 73 × 30 × 30 مم |
| وزن | تقريبا. 0.21 كجم |
| شهادة | RoHS compliant |
- Compatible Heads
Can be combined with ZCKD series heads to form a complete limit switch. Common head models:
ZCKD02, ZCKD05, ZCKD06, ZCKD08, ZCKD10, ZCKD15, ZCKD16, ZCKD17, ZCKD21, ZCKD41, ZCKD81, ZCKD91, إلخ.
- Comparison of Same-Series Bodies (Selection Reference)
ZCKL1H7: 1/2″ NPT, metal, 1NO+1NC, IP65 (most common)
ZCKL5H7: Same specs, different mounting holes
ZCKL7H7: Same specs, different cable entry
ZCKLD31H7 / ZCKLD35H7: Pre-wired cable type
- التطبيقات
معدات الأتمتة الصناعية, machine tools, الناقلات, packaging machinery
Position detection, travel limit, safety interlock
Mechanical position feedback in harsh environments (dust, light water splashing)
- Replacement Options
Schneider same series: ZCKL5H7, ZCKL7H7 (direct replacement)
سيمنز: 3SE5 series (e.g. 3SE5112-0CH01)
ايه بي بي: LS series (e.g. LS31P11B11)
Chinese brands: Chint YBLX-CK, Delixi LXJM1 series (contact and mounting verification required)
