Pepperl+Fuchs (P+F) Encoder RVI50N-09BK0A3TN-01000-052412

Pepperl+Fuchs (P+F) Encoder RVI50N-09BK0A3TN-01000-052412

Das ist ein Pepperl+Fuchs (P+F) Encoder, kein Beckhoff-Produkt.

Vollständiges Modell: RVI50N-09BK0A3TN-01000

Bestell-Nr.: 052412 (Die nachgestellten Ziffern geben die Bestellnummer an).

1. Modellcode-Definition

2. Wichtigste technische Spezifikationen

3. Vollständige Modellliste der Serie (RVI50N-09BAT Series)

4. Alternative & Querverweis

4.1 Same Brand Replacement (P+F)

4.2 Markenübergreifender Ersatz

5. Anwendungsumgebungen & Branchenfälle

Anwendbare Szenarien

1. Werkzeugmaschinen: Spindle/feed shaft speed & position monitoring for CNC machines and machining centers; precise tool control for precision parts & mold manufacturing.
2. Verpackung & Druckmaschinen: Speed synchronization and positioning control for packaging machines, printing machines and laminators; ensures color registration accuracy.
3. Automation Production Lines: Speed detection of conveyor drive motors; precise material speed and position control.
4. Plastik & Gummimaschinen: Screw position and speed feedback for injection molding and extrusion machines; stable product consistency.
5. Logistik & Lagerung: Lifting and horizontal positioning for stackers and sorting lines; improves warehouse efficiency.

Nicht empfohlene Szenarien

1. Underwater or high-humidity environments: Only IP50, not suitable for long-term damp conditions.
2. Strong corrosive environments: No special anti-corrosion coating, vulnerable to chemical erosion.
3. Ultra-high-speed operation: Höchstgeschwindigkeit 10,000 U/min, not for ultra-high-speed motor monitoring.
4. Explosionsgeschützte Bereiche: No ATEX/IECEx certification; not allowed in flammable & explosive zones.

Typischer Anwendungsfall

Produktionslinie für Autoteile:

Model RVI50N-09BK0A3TN-01000 is installed on the Z-axis drive motor of machining centers. It feeds real-time speed and position signals to the PLC system for precise tool feed control. Machining accuracy reaches ±0.01mm, reducing defective rate by 30%.

6. Auswahlformel & Memorization Rules

Auswahlformel

50mm Gehäuse, Blindhohlwelle

M23 interface, Push-Pull output

1000 pulses for standard precision

IP50 for general industrial use

Bestell-Nr. 052412

Discontinued replace with RVI58N

Memorization Rules

1. RVI50N：50mm incremental encoder, Standardtyp
2. 09B：6mm blind hollow shaft mounting
3. K0：M23 12-pin connector
4. A3：Push-Pull, großer Spannungsbereich
5. TN：Built-in protection circuit
6. 01000：1000 pulses per revolution
7. 052412：Eindeutige Bestellnummer
8. Luftfracht-Compliance & CE-Zertifizierung

Luftfrachtbewertung

1. Built-in Battery: Keine Lithiumbatterie / Superkondensator; Ungefährliche Güter. No special air freight formalities required.
2. Transportklassifizierung: Ordinary industrial electronic product, konform mit der IATA-DGR-Klasse 9 unrestricted goods.
3. Packaging Suggestion: Antistatische Verpackung, avoid heavy vibration; Transporttemperatur: -40~70℃.

CE-Zertifizierung

1. Standards: Compliant with LVD 2014/35/EU and EMC 2014/30/EU.
2. Status: CE-zertifiziert, legal for EU market circulation.
3. Markierung: CE logo marked on product and package; Declaration of Conformity (DOC) provided with shipment.
4. Beschaffung & Replacement Reminders
5. Stock Status: RVI50N series discontinued; available goods are mostly stock inventory or replacement models.
6. Ersatzvorschlag: Prefer P+F RVI58N series; mechanical mounting compatible with upgraded electrical performance.
7. Order Info: Provide full model RVI50N-09BK0A3TN-01000 and Order No. 052412 for accurate procurement.
8. Technische Unterstützung: Official Pepperl+Fuchs provides discontinued model replacement consulting service.

Zusammenfassung der Kernanwendung

RVI50N-09BK0A3TN-01000-052412 is Pepperl+Fuchs incremental hollow-shaft encoder, 1000PPR, Push-Pull output, IP50.

Main Industries

1. Verpackung & Drucken

Horizontal/vertical packaging machines, Etikettiermaschinen, Abfüllmaschinen, rewinders, Schneidemaschinen: fixed-length cutting, feeding synchronization, Spannung & speed closed-loop control.

2. Logistik & Conveying

Bandförderer, Rollenlinien, sorting machines, Stapler, shuttles: motor speed measurement, Positionierung, start-stop synchronization, line rhythm matching.

3. Holzbearbeitung / Plastik & Gummimaschinen

Edge banding machines, panel saws, sanders; Extruder, film blowers, Spritzgießmaschinen: feed speed, Positionierung, screw speed & line speed synchronization.

4. General Machine Tools & Leichtindustrie

Drehmaschinen, Fräsmaschinen, Schleifmaschinen, small machining centers: spindle speed detection, feed axis low-speed positioning. Textilmaschinen: roller speed synchronization and line linkage.

5. Lüfter & Pump Inverter Control

Centrifugal fans, Wasserpumpen, Luftkompressoren: variable frequency speed closed-loop, constant speed control, over-speed protection monitoring.

Unsuitable Application Limits

1. Outdoor rainy / hohe Luftfeuchtigkeit: IP50 not waterproof
2. Severe dust (mine, Zement): Easy dust ingress damages code disc
3. Chemical corrosive & explosionsgefährdete Bereiche: No anti-corrosion / no explosion-proof certification
4. Speed over 10000rpm & micron high precision: 1000PPR insufficient resolution
5. Unterwasser, steam high-temperature closed humid environment
