Schneider REXL2TMBD is a compact plug-in Zeitrelais belonging to the Zelio Time product series.
Detaillierte Spezifikationen:
Verzögerungstyp: Einschaltverzögerungstyp. Die Relaiskontakte werden erst aktiviert, nachdem die voreingestellte Zeit seit dem Anlegen der Spannung verstrichen ist.
Nennversorgungsspannung: 24In DC, mit einem Spannungsbereich von 0.9-1.2 mal der Nennspannung.
Verzögerungsbereich: 0.1s-100h, adjustable via control knobs with multiple time ranges (z.B., 0.1s-1s, 1s-10s, 10s-100s, usw.).
Kontakttyp & Konfiguration: 2C/O (2 Wechselkontakte), consisting of 2 Sätze von normalerweise offen (NEIN) contacts and 2 Sätze von normalerweise geschlossenen (NC) Kontakte, with a rated contact current of 5A.
Genauigkeit: Repeat accuracy of ±0.5%; delay accuracy of ±10% at full scale under 25℃.
Zeit zurücksetzen: 50ms during power-off delay; time delay discharge voltage deviation of ±0.2%/V.
Montagemethode: Miniature plug-in mounting, compatible with RXM bases (universal base design) for easy installation and replacement.
Weitere Funktionen: Local signal indication (1 yellow LED for power-on status, 1 red LED for operating status); cadmium-free contact materials (compliant with environmental standards); elektrische Lebensdauer von 100,000 Operationen; mechanical life of 10,000,000 Operationen.
How to Set the Delay Time of Schneider Time Relay REXL2TMBD
- Vorbereitung
- Ensure the relay is correctly installed on the RXM base and powered by 24V DC.
- Locate the two control knobs: the side knob (for selecting time range) and the front knob (for fine-tuning time).
- Setting Steps
- Select Time Range (Side Knob)
Rotate the side knob to the desired time range:
| Gear | Zeitbereich |
| 1 | 0.1-1 Zweite |
| 2 | 1-10 Sekunden |
| 3 | 0.1-1 Minute |
| 4 | 1-10 Minutes |
| 5 | 0.1-1 Stunde |
| 6 | 1-10 Hours |
| 7 | 10-100 Hours |
Beispiel: Setting 5-second delay → Select Gear 2 (1-10 Sekunden)
- Fine-Tune Exact Time (Front Knob)
Based on the selected time range, rotate the front knob to the desired exact time:
– The front knob scale is evenly distributed from 0 to the maximum value within the selected range.
– Beispiel: With the side knob at Gear 2 (1-10 Sekunden), turning the front knob to “5” zeigt an 5 Sekunden.
III. Setting Examples
Beispiel 1: Setting 30-Second Delay
- Rotate the side knob to Gear 4 (1-10 Minutes).
- Rotate the front knob to “0.5” (repräsentieren 0.5 minutes = 30 Sekunden).
Beispiel 2: Setting 2-Hour Delay
- Rotate the side knob to Gear 6 (1-10 Hours).
- Rotate the front knob to “2” (repräsentieren 2 Std.).
- Notizen
Genauigkeit: Delay accuracy is ±10% of full scale (bei 25℃); repeat accuracy is ±0.5%.
Voltage Impact: Power supply fluctuations may affect delay accuracy. It is recommended to use within 0.9-1.1 mal der Nennspannung (24In DC).
LED-Anzeige: After setup, the yellow LED lights up when powered on, and the red LED lights up during delay operation.
Power-Off Reset: The relay restarts the delay cycle when power is reapplied after a power outage.
- Verify the Setting
After setup, power on the relay:
– Instant power-on: Yellow LED on, red LED off.
– Upon reaching the preset delay time: Red LED on, contact state switches.
– Nach dem Ausschalten: Both LEDs turn off, contacts return to their initial state.
Setting the delay time for the REXL2TMBD time relay requires only two steps: select the range with the side knob, and fine-tune with the front knob. The operation is simple and intuitive, requiring no additional tools or programming, making it suitable for various industrial automation delay control scenarios.
