ABB 1SDA064868R1 MCCB

1SDA064868R1 is the official order code for the ABB Tmax XT Series Molded Case Circuit Breaker (MCCB), corresponding to the full model:

XT4H 250 Ekip LS/I 4p F F

Key Parameters

Item	Specification
Series	Tmax XT4 Series
Rated Current	In = 250A
Poles	4-Pole
Breaking Capacity	H type: 50kA at 415V
Release Unit	Ekip LS/I electronic release
Protection Functions	L (overload) + S (short delay) + I (instant)
Mounting	Fixed / Front connection
Rated Voltage	400/415V AC

Product Positioning

Industrial-grade power distribution protection for power distribution panels, motor circuits, industrial equipment, and building power distribution

Mid-to-high end ABB MCCB with high reliability, suitable for automated power distribution systems

Standard English Description (for tender / inquiry)

ABB Circuit Breaker MCCB Tmax XT4H250, 250A, 4P, 50kA, Ekip LS/I, Fixed, 1SDA064868R1

Common Alternative / Similar Models in the Same Series (XT4 250A 4P)

1SDA064867R1: XT4H250 3P

1SDA064898R1: XT4L250 4P (lower breaking 36kA)

1SDA064878R1: XT4S250 4P (medium breaking 42kA)

Complete Model List, Brand Cross‑Reference & Order Code Manual

for ABB Tmax XT Series MCCBs

Core Model System

1.1 Frame Specifications & Basic Parameters

The Tmax XT series covers frame currents from 160A to 1600A across 7 frame sizes, suitable for various power‑rating distribution protections:

Frame	Frame Current	Breaking Class	Poles	Rated Voltage	Application
XT1	160A	S/L/N/H	3P/4P	690V AC/500V DC	Small distribution, lighting circuits
XT2	160A	S/L/N/H/V	3P/4P	690V AC/500V DC	Industrial equipment, motor protection
XT3	250A	S/L/N/H	3P/4P	690V AC/500V DC	Building distribution, small‑medium factories
XT4	250A	S/L/N/H/V	3P/4P	690V AC/500V DC	Large motors, industrial automation
XT5	630A	L/N/H	3P/4P	690V AC/500V DC	Distribution rooms, large factories
XT6	1000A	L/N/H	3P/4P	690V AC/500V DC	Large power stations, heavy industry
XT7/XT7M	1250A/1600A	L/N/H/M	3P/4P	690V AC/500V DC	Extra‑large industry, power grid support

1.2 Model Coding Rule

XT[Frame][Breaking Class][Frame Current] [Release Type] [Rated Current] [Poles] [Mounting]

Example: XT4H 250 Ekip LS/I 4p F F (Order code: 1SDA064868R1)

1.3 Breaking Capacity Classes

Class	Breaking Capacity (415V)	Application
S	36kA	Standard industrial environment
L	42kA	General industrial loads
N	50kA	Heavy industry, large motors
H	85kA	High short‑circuit risk areas
V	120kA/150kA	Extra‑large factories, grid side
M	200kA	Extra‑high voltage distribution, special industry

Complete Model List by Frame

XT1 160A Series (Basic Type)

Full Model	Order Code	Release	Rated Current	Features
XT1S 160 TMF 16-160 3P FF	1SDA074621R1	Thermal‑Magnetic Fixed	16-160A	Economic, 36kA
XT1L 160 TMD 16-160 4P FF	1SDA074658R1	Thermal‑Magnetic Adjustable	16-160A	Adjustable overload, 42kA
XT1N 160 Ekip LS 100 3P FF	1SDA074725R1	Electronic LS	100A	Electronic protection, 50kA

XT2 160A Series (High Performance)

Full Model	Order Code	Release	Rated Current	Features
XT2L 160 TMD 32-320 4P FF	1SDA067662R1	Thermal‑Magnetic Adjustable	32-320A	120kA, motor protection
XT2V 160 Ekip LSIG 160 3P FF	1SDA067721R1	Electronic LSIG	160A	150kA, full protection
XT2N 160 Ekip C LSIG R63 FF 3P	10152869	Electronic LSIG + Comms	63A	With communication, smart distribution

XT3 250A Series

Full Model	Order Code	Release	Rated Current	Features
XT3L 250 TMD 32-250 3P FF	1SDA064821R1	Thermal‑Magnetic Adjustable	32-250A	42kA, building distribution
XT3N 250 Ekip LS 200 4P FF	1SDA064845R1	Electronic LS	200A	50kA, industrial automation
XT3H 250 Ekip LSIG 250 3P FF	1SDA064872R1	Electronic LSIG	250A	85kA, heavy‑duty protection

XT4 250A Series (Key Reference)

Full Model	Order Code	Release	Rated Current	Features
XT4H 250 Ekip LS/I 4p FF	1SDA064868R1	Electronic LS/I	250A	50kA
XT4L 250 TMD 32-250 3P FF	1SDA064867R1	Thermal‑Magnetic Adjustable	32-250A	42kA, 3P
XT4V 250 Ekip LSIG 250 4P FF	1SDA064898R1	Electronic LSIG	250A	120kA

XT5‑XT7 Series (High Power)

Frame	Full Model	Order Code	Rated Current	Breaking Capacity	Application
XT5	XT5N 630 Ekip LSIG 630 3P FF	1SDA100491R1	630A	50kA	Distribution room, large factory
XT6	XT6H 1000 Ekip LSIG 1000 4P FF	1SDA100628R1	1000A	85kA	Heavy industry, power station
XT7	XT7M 1250 Ekip LSIG 1250 3P FF	1SDA100755R1	1250A	100kA	Extra‑large industry

Release Unit Types & Functions

Release	English	Protection	Application	Accuracy
TMF	Thermal-Magnetic Fixed	L + I	Lighting, small motors	±15%
TMD	Thermal-Magnetic Adjustable	L (adj) + I (adj)	Industrial equipment, pumps	±10%
Ekip LS	Electronic LS	L + S	Distribution, transformers	±5%
Ekip LS/I	Electronic LS/I	L + S + I	Motor circuits, industrial loads	±5%
Ekip LSIG	Electronic LSIG	L + S + I + G (ground)	Sensitive loads, data centers	±3%
Ekip Touch	Digital Touch	Full + Communication	Smart distribution	±2%

Main Brand Cross‑Reference

4.1 XT1/XT2 (160A)

ABB	Schneider (NSX)	Siemens (3VA)	Eaton (IZM)	Chint (NXM)	Breaking
XT2N 160 Ekip LS 100 3P	NSX160N Micrologic 5.2E 100A	3VA2160-5EF32-0AA0	IZM91H160 TM-D 100A	NXM160S 100A	50kA
XT2V 160 Ekip LSIG 160 4P	NSX160H Micrologic 6.3E 160A	3VA2160-5FF32-0AA0	IZM91V160 LSIG 160A	NXM160H 160A	120kA

4.2 XT3/XT4 (250A)

ABB	Schneider (NSX)	Siemens (3VA)	Eaton (IZM)	Chint (NXM)	Order Code
XT4H 250 Ekip LS/I 4P	NSX250N Micrologic 5.3E 250A	3VA3250-5EF32-0AA0	IZM92H250 LS/I 250A	NXM250H 250A	1SDA064868R1
XT4L 250 TMD 250 3P	NSX250S Micrologic 2.3 250A	3VA3250-5DF32-0AA0	IZM92L250 TM-D 250A	NXM250S 250A	1SDA064867R1

4.3 XT5‑XT7 (630A~1600A)

ABB	Schneider (MTZ)	Siemens (3VA)	Eaton (IZM)	Breaking
XT5N 630 Ekip LSIG 630 3P	MTZ630N Micrologic 5.3E 630A	3VA5630-5EF32-0AA0	IZM93N630 LSIG 630A	50kA
XT7M 1250 Ekip LSIG 1250 3P	MTZ1250H Micrologic 6.3E 1250A	3VA61250-5FF32-0AA0	IZM96M1250 LSIG 1250A	100kA

Order Code Rules & Examples

5.1 Standard Format

1SDA[6 digits]R1 (R1 = standard version)

5.2 Common Order Codes

Application	ABB Full Model	Order Code
Motor Control	XT4H 250 Ekip LS/I 4P FF	1SDA064868R1
Distribution	XT2N 160 Ekip LS 100 3P FF	1SDA074725R1
Building	XT3L 250 TMD 200 3P FF	1SDA064821R1
Data Center	XT2V 160 Ekip LSIG 160 4P FF	1SDA067721R1

Selection & Replacement Guide

6.1 Core Selection Principles

Current matching: In ≥ 1.2 × load current; frame current ≥ 1.5 × In
Breaking capacity: Icu ≥ expected short‑circuit current (≥50kA recommended for industry)
Protection: LS/I for motors; LS for distribution; LSIG for sensitive loads
Mounting: F = Fixed, D = Plug‑in, W = Drawout (FF = Fixed Front)

6.2 Replacement Steps
