Core Basic Information
| Parameter | Value | Notes |
| Model | ACS580-01-106A-4 | Wall-mounted general-purpose inverter |
| Order No. | 3AUA0000080503 | ABB official global product code |
| Suitable Motor Power | 55 kW (75 HP) @ 400 V | Standard duty / Light overload |
| Rated Output Current | 106 A | Standard duty |
| Light Overload Current | 100 A | Light overload (110%/60s) |
| Heavy Duty Current | 87 A | Heavy duty (150%/60s) |
| Power Supply | Three-phase 380–480 V AC | Voltage tolerance ±10% |
| Input Frequency | 50/60 Hz | Frequency tolerance ±5% |
| Mounting | Wall-mounted | IP21 (standard) |
| Weight | 28.3 kg | Including packaging |
| Dimensions | 203 × 732 × 295 mm (W×H×D) | Excluding mounting bracket |
- Detailed Technical Data
2.1 Electrical Parameters
| Parameter | Value |
| Output frequency range | 0–500 Hz |
| Switching frequency | 2–16 kHz |
| Control mode | Scalar (V/f), Sensorless Vector Control (SVC) |
| Power factor | 0.98 (input) |
| Efficiency | 98.70% |
| Output voltage | 0–Input voltage |
| Max. output power | 55 kW |
| Digital I/O | 6月3日 |
| Analog I/O | 2/2 (0–10 V or 4–20 mA) |
| Communication | RS-485, USB |
| Protection | Overcurrent, overvoltage, undervoltage, overheat, short circuit, earth fault, motor overtemperature, etc. |
2.2 Mechanical & Environmental Parameters
| Parameter | Value |
| Protection class | IP21 (standard), IP55 optional |
| Operating temperature | -10°C to +40°C |
| Storage temperature | -40°C to +70°C |
| Relative humidity | 0–95% non-condensing |
| Vibration | IEC 60068-2-6: 10–58 Hz, 0.1 g |
| Shock | IEC 60068-2-27: 15 g, 11 ms |
| Cooling | Forced air cooling |
- Cross-Brand Replacement Order Numbers (55 kW, 380–480 V, Wall-mounted)
| Brand | Series | Model | Notes |
| Schneider Electric | ATV610 | ATV610D55N4 | General-purpose, built-in EMC filter |
| Schneider Electric | ATV930 | ATV930D55N4 | High-performance, PROFINET supported |
| Siemens | SINAMICS G120 | 6SL3224-0BE35-5AA0 | Built-in filter, no braking unit |
| Siemens | SINAMICS G120 | 6SL3224-0BE35-5AA3 | Built-in filter, with braking unit |
| Danfoss | FC302 | FC302P55KT4E20H2XGCXXXSXXXXAXXX | For fans & pumps |
| Danfoss | FC111 | FC111P55KT4E20H3BXCXXXXSXXXXAXXX | General-purpose |
| Delta | VFD-C2000 | VFD055C43A | Built-in PLC |
| Delta | VFD-E | VFD055E43A | Economy general-purpose |
| Inovance | MD280 | MD280T55G | Cost-effective domestic alternative |
| Inovance | MD480 | MD480T55G | High-performance vector control |
| INVT | CHV100 | CHV100-055G-4 | Domestic general-purpose |
- Selection Guidelines
- Load Matching
Standard duty (106 A): Fans, pumps, variable torque loads
Light overload (100 A): Conveyors, mixers, constant torque loads
Heavy duty (87 A): Compressors, cranes, impact loads
- Replacement Notes
Ensure rated current ≥ 106 A
Verify control mode (vector/SVC)
Check communication compatibility
Confirm IP rating, dimensions, cooling
- Options
Braking unit: External required for ACS580-01-106A-4
EMC filter: Recommended for low interference
Encoder interface: For closed-loop control
Complete ABB ACS580 Series Models & Order Numbers
- ACS580 Series Overview
ABB ACS580 is a general-purpose low-voltage AC drive series covering 0.75 kW-500 kW.
| Sub-series | Type | Power Range | Protection | Mounting |
| ACS580-01 | Wall-mounted | 0.75–250 kW | IP21/IP55 | Wall |
| ACS580-04 | Compact module | 250–500 kW | IP00 | Cabinet |
| ACS580-07 | Cabinet-built | 75–500 kW | IP21/IP54 | Floor-standing |
- ACS580-01 Series (Wall-mounted, 400V 3-phase)
2.1 Standard Models (IP21)
| Model | Order No. | Rated Power | Rated Current | Motor Power |
| ACS580-01-02A7-4 | 3AUA0000080511 | 0.75 kW | 2.7 A | 0.75 kW |
| ACS580-01-03A4-4 | 3AUA0000080512 | 1.1 kW | 3.4 A | 1.1 kW |
| ACS580-01-04A1-4 | 3AUA0000080513 | 1.5 kW | 4.1 A | 1.5 kW |
| ACS580-01-05A7-4 | 3AUA0000080514 | 2.2 kW | 5.7 A | 2.2 kW |
| ACS580-01-07A3-4 | 3AUA0000080515 | 3.0 kW | 7.3 A | 3.0 kW |
| ACS580-01-09A5-4 | 3AUA0000080516 | 4.0 kW | 9.5 A | 4.0 kW |
| ACS580-01-12A7-4 | 3AUA0000080517 | 5.5 kW | 12.7 A | 5.5 kW |
| ACS580-01-018A-4 | 3AUA0000080518 | 7.5 kW | 18 A | 7.5 kW |
| ACS580-01-026A-4 | 3AUA0000080519 | 11 kW | 26 A | 11 kW |
| ACS580-01-033A-4 | 3AUA0000080520 | 15 kW | 33 A | 15 kW |
| ACS580-01-039A-4 | 3AUA0000080521 | 18.5 kW | 39 A | 18.5 kW |
| ACS580-01-046A-4 | 3AUA0000080522 | 22 kW | 46 A | 22 kW |
| ACS580-01-062A-4 | 3AUA0000080523 | 30 kW | 62 A | 30 kW |
| ACS580-01-073A-4 | 3AUA0000080524 | 37 kW | 73 A | 37 kW |
| ACS580-01-096A-4 | 3AUA0000204819 | 45 kW | 96 A | 45 kW |
| ACS580-01-106A-4 | 3AUA0000080503 | 55 kW | 106 A | 55 kW |
| ACS580-01-130A-4 | 3AUA0000080504 | 75 kW | 130 A | 75 kW |
| ACS580-01-169A-4 | 3AUA0000080505 | 90 kW | 169 A | 90 kW |
| ACS580-01-180A-4 | 3AUA0000080506 | 110 kW | 180 A | 110 kW |
| ACS580-01-240A-4 | 3AUA0000080507 | 132 kW | 240 A | 132 kW |
| ACS580-01-293A-4 | 3AUA0000080508 | 160 kW | 293 A | 160 kW |
| ACS580-01-363A-4 | 3AUA0000080509 | 200 kW | 363 A | 200 kW |
| ACS580-01-430A-4 | 3AUA0000080510 | 250 kW | 430 A | 250 kW |
2.2 IP55 Versions (+B056)
| Model | Order No. | Description |
| ACS580-01-018A-4+B056 | 3AXD50000038976 | 7.5 kW, 17 A, IP55, EMC C2 |
| ACS580-01-026A-4+B056 | 3AUA0000083563 | 11 kW, 25 A, IP55, EMC C2 |
| ACS580-01-033A-4+B056 | 3AUA0000083564 | 15 kW, 32 A, IP55, EMC C2 |
- ACS580-04 Series (Compact Module, 400V 3-phase)
| Model | Order No. | Rated Power | Rated Current | Motor Power |
| ACS580-04-250A-4 | 3AUA0000080530 | 250 kW | 250 A | 250 kW |
| ACS580-04-310A-4 | 3AUA0000080531 | 315 kW | 310 A | 315 kW |
| ACS580-04-363A-4 | 3AUA0000080532 | 400 kW | 363 A | 400 kW |
| ACS580-04-430A-4 | 3AUA0000080533 | 500 kW | 430 A | 500 kW |
- ACS580-07 Series (Cabinet-built, 400V 3-phase)
| Model | Order No. | Rated Power | Rated Current | Motor Power | Cabinet |
| ACS580-07-130A-4 | 3AUA0000080540 | 75 kW | 130 A | 75 kW | Standard |
| ACS580-07-169A-4 | 3AUA0000080541 | 90 kW | 169 A | 90 kW | Standard |
| ACS580-07-180A-4 | 3AUA0000080542 | 110 kW | 180 A | 110 kW | Standard |
| ACS580-07-240A-4 | 3AUA0000080543 | 132 kW | 240 A | 132 kW | Standard |
| ACS580-07-293A-4 | 3AUA0000080544 | 160 kW | 293 A | 160 kW | Standard |
| ACS580-07-363A-4 | 3AUA0000080545 | 200 kW | 363 A | 200 kW | Standard |
| ACS580-07-430A-4 | 3AUA0000080546 | 250 kW | 430 A | 250 kW | Standard |
| ACS580-07-500A-4 | 3AUA0000080547 | 315 kW | 500 A | 315 kW | Large |
- Model Naming Convention
ACS580-XX-YYYA-Z
| Field | Meaning | Example |
| XX | Series type | 01=Wall, 04=Module, 07=Cabinet |
| YYY | Rated output current | 106 = 106 A |
| A | Unit | Ampere |
| Z | Voltage class | 4=380–480V, 6=500–600V |
- Common Options
| Code | Description |
| 0 | IP55, EMC filter class C2 |
| 0 | Bluetooth control panel |
| 0 | Auxiliary control panel |
| 0 | Braking unit |
| 0 | PROFIBUS DP |
| 0 | PROFINET |
| 0 | EtherNet/IP |
- Cross-Brand Alternatives (ACS580-01-106A-4, 55 kW/106 A)
| Brand | Series | Model | Order No. | Notes |
| Schneider | ATV610 | ATV610D55N4 | 150A1297 | General-purpose, built-in EMC filter |
| Schneider | ATV930 | ATV930D55N4 | 152A2997 | High-performance |
| Siemens | SINAMICS G120 | 6SL3224-0BE35-5AA0 | – | Standard |
| Danfoss | FC302 | FC302P55KT4E20H2XGCXXXSXXXXAXXX | 132F0021 | Fan/pump |
| Delta | VFD-C2000 | VFD055C43A | – | Built-in PLC |
| Inovance | MD280 | MD280T55G | – | Domestic alternative |
