Б&R Модуль ЦП X20-CP-1484

X20-CP-1484 is a compact CPU module of B&Р X20 series. Он оснащен процессором, совместимым с Intel Celeron., оснащен 1 слот расширения, POWERLINK Ethernet в реальном времени, Ethernet, RS232, Интерфейсы связи USB и X2X Link. Безвентиляторный дизайн, подходит для сценариев управления промышленной автоматизацией средней сложности.

1. Определение сегмента модели (Precise Decoding)

Full Model Definition:

X20 series CPU module, Celeron-compatible processor, 1 interface module expansion slot, RJ45 shielded interface (с -1 суффикс), компактный дизайн.

2. Core Specification List (Official Data)

3. Список аксессуаров (Стандартный & Optional Parts)

4. Competitive & Cross-Brand Replacement (Direct Substitution)

5. Рекомендации по выбору & Альтернативные решения (Quick Reference)

Формула выбора

Three key factors for X20 selection: Processor performance, Расширяемость, Communication requirements

Processor performance: 1484=Celeron compatible; 1382=100MHz x86; 3484=Same performance with 3 slots

Расширяемость: 1/3 slots determine the quantity of expandable interface modules

Communication requirements: Select appropriate interface module according to fieldbus type

Quick Alternative Solutions

1. Обновление той же серии: X20CP3484 (3 expansion slots, ideal for systems requiring more communication interfaces)
2. Обновление производительности: X20CP1585 (Intel Atom processor, higher performance for complex algorithm application)
3. Functional Replacement:

Small System: X20CP1382 (100MHz x86 processor, 1 slot, более низкая стоимость)

Large System: X20CP4785 (Multi-core processor, 4 slots, top-level performance)

Сценарии применения

Packaging Machinery: Medium-complexity control, POWERLINK real-time synchronization, 1 expansion slot is sufficient

Printing Equipment: Requires high-speed data processing; fanless design adapts to dusty environments

Logistics Automation: Multi-axis motion control, servo system connection, ACOPOS performance supported

Еда & Beverage: Wide operating temperature range, защита IP20, suitable for workshop environments

Автоматизация зданий: Rich communication interfaces, compatible with various sensors and actuators

6. Air Freight Compliance & Сертификация
7. Air Freight Compliance: Built-in CR2032 lithium battery (Lithium content ≤2g), classified as UN3481. Compliant with IATA DGR Section II, allowed for carry-on or cargo shipment without special approval.
8. Сертификаты:

CE: Compliant with EN 61131-2, В 61010-1

UL: Compliant with UL 508 industrial control equipment standard

РоХС: Eco-friendly materials complying with EU directives

Marine Certification: Compliant with DNV GL, LR and other classification society standards

7. X20 CPU Full Series Core Model List

X20-CP-1484 is a cost-effective compact CPU module. With its Celeron-compatible processor, 1 слот расширения, rich communication interfaces and fanless design, it serves as an ideal choice for medium-complexity industrial automation. The built-in lithium battery supports SRAM data backup, and POWERLINK Real-Time Ethernet ensures high-speed synchronous control. It is widely applied in packaging, printing, logistics and other industries. Model selection shall be precisely matched according to system complexity, expansion demands and communication protocols.

The B&R X20-CP-1484 is a mid-range compact PLC integrated with POWERLINK real-time Ethernet. It is optimized for small and medium-scale motion control, distributed I/O, and real-time communication applications. Its core industries cover packaging, printing, plastics, текстиль, логистика, еда & напиток, water treatment, electronics manufacturing, and general mechanical equipment.

1. Core Application Industries & Scenarios
2. Packaging Machinery (Most Mainstream)

Horizontal / Vertical packaging machines, heat shrink wrapping machines, этикетировочные машины, запечатщики картонных коробок, strapping machines

Функции: Multi-axis synchronization via POWERLINK, high-speed cutting/positioning, short cycle time (≈800μs), пыль & humid environment adaptability, fanless high reliability

2. Печать & Paper Making

Digital printing machines, flexo / gravure printing machines, slitting machines, rewinding machines, pulping & paper production lines

Функции: Tension control, color registration synchronization, high-speed web processing, high-precision positioning control

3. Plastic & Rubber Machinery

Машины для литья под давлением, экструдеры, blow molding machines, hollow forming machines, rubber vulcanizing machines

Функции: Hydraulic / servo hybrid control, temperature closed-loop control, high-pressure mold clamping / injection, multi-stage process control

4. Textile Machinery

Knitting machines, weaving machines, winding machines, printing and dyeing equipment

Функции: High-speed multi-axis synchronization, stable tension, low vibration, long-term continuous operation

5. Логистика & Warehouse Automation

Сортировочные линии, conveyor lines, stackers, AGV/AMR, automated warehouses

Функции: Distributed I/O, POWERLINK real-time bus, координация нескольких станций, long-span equipment networking

6. Еда & Beverage

Filling lines, стерилизаторы, homogenizers, sorting & упаковочное оборудование, bakery machinery

Функции: Sanitary design, широкий температурный диапазон (0…55℃), dust and moisture resistance, recipe management, batch traceability

7. Очистка воды & Охрана окружающей среды

Очистные сооружения (grilles / водяные насосы / blowers / dewatering machines), water purification plants, reclaimed water reuse, pump station monitoring

Функции: Analog closed-loop control (pH / dissolved oxygen / liquid level), distributed control, сильная защита от помех, long-term stable operation

8. Производство электроники (SMT / PCB)

SMT placement machines, PCB inspection machines, solder paste printers, automatic insertion lines

Функции: High-precision positioning, high-speed motion control, multi-axis synchronization, hybrid communication of Ethernet/IP + POWERLINK

9. General Mechanical Equipment

CNC machine tools, laser cutting machines, plasma cutting machines, woodworking machinery, special-purpose machine tools

Функции: Integrated motion & логическое управление, безвентиляторный дизайн, compact installation, экономически эффективный

10. Process Industry (Химическая / Фармацевтический / Энергия)

Small reaction kettles, mixing & stirring equipment, filtration & separation units, pharmaceutical production lines, photovoltaic equipment

Функции: Температура / давление / flow closed-loop control, batch control, hazardous area compatibility, data acquisition and monitoring

1. Выбор & Adaptation Key Points (Why Choose X20-CP-1484)

✅ Medium-scale control: 32MB DRAM, 1MB SRAM, single expansion slot; suitable for 100–500 I/O points, 8–16 motion axes

✅ Mandatory real-time communication: Integrated POWERLINK (hard real-time) + Ethernet + RS232 + USB, meeting multi-device synchronization requirements

✅ Strong environmental adaptability: защита IP20, 0…55℃ operating temperature, безвентиляторный дизайн, 5g vibration resistance, suitable for harsh workshop conditions

✅ Distributed architecture: Remote I/O expansion via X2X bus, ideal for long production lines and multi-station collaborative systems

III. Typical Application Cases

📦 Packaging Line: X20-CP-1484 controls 6-axis labeling and conveying with POWERLINK synchronization; capacity up to 300 packages per minute

🚰 Sewage Treatment: Main CPU manages 12 I/O stations to control water pumps, blowers and chemical dosing; stable continuous operation over 5 годы

🚚 Logistics Sorting: Drives 4 sets of high-speed sorting lines with POWERLINK linkage; sorting capacity up to 1000 pieces per hour

🍶 Refined Oil Loading: Distributed control for 14 loading arms via Ethernet + CAN bus; annual throughput up to 3 million tons

1. Not Recommended Application Scenarios

❌ Large process plants (redundancy / hot backup required; choose X20CP3484 or higher model)

❌ Ultra-high-speed multi-axis systems (over 16 axes; choose X20CP1585 / X20CP4785)

❌ Zone 0 explosive hazardous areas (special explosion-proof model required)
