A9F18325-IC65N-3P-C25A Schneider Circuit Breaker
QuickVigi iC60 Residual Current Add-on Module
Overview of Key Specifications
A9Q41225 is a QuickVigi iC60 residual current add-on module (RCD add-on device) from Schneider Electric’s Acti9 range, specially designed for iC60 miniature circuit breakers (MCBs), providing 2P 25A 30mA Type AC earth leakage protection.
| Item | Specification |
| Product Type | QuickVigi iC60 Residual Current Add-on Module |
| Number of Poles | 2P (Two-wire system) |
| Rated Current (In) | 25A |
| Rated Residual Operating Current (I) | 30mA (Personal safety level) |
| Residual Current Type | Type AC (Detects sinusoidal AC residual current) |
| Dimensions | 1.5 modules (27mm width), 91mm height, 73.5mm depth |
| Mounting | DIN rail mounting |
| Degree of Protection | IP20 |
| Operating Voltage | 230/240V AC |
| Frequency | 50/60Hz |
| Trip Indication | Local mechanical indicator (red) |
| Applicable Standards | IEC 61009-1 |
Product Features & Functions
- Plug-and-play design: Installs quickly onto iC60 MCBs without extra wiring
- Voltage-independent technology: Ensures reliable operation even with voltage fluctuations
- VisiTrip window: Red mechanical indicator shows fault trip status for fast troubleshooting
- Comprehensive protection: Prevents indirect electric shock and fire hazards caused by earth leakage
- Full compatibility with iC60 MCBs: Does not alter the original short-circuit and overload protection characteristics of the MCB when combined
Differences from Similar Models
| Model | Product Type | Main Differences |
| A9Q41225 | QuickVigi iC60 Add-on Module | 1.5 modules, QuickVigi series, market-specific version |
| A9V41225 | Vigi iC60 Standard Add-on Module | 3 modules (63mm width), standard Vigi series |
| A9R41225 | iID Standalone RCCB | Independent installation, no MCB required, built-in overload and short-circuit protection |
Applications
Suitable for residual current protection in final distribution systems, especially for:
Socket circuits in residential, commercial and small industrial buildings
Areas with high personal safety requirements (30mA sensitivity provides direct contact protection)
Installations needing space saving in distribution boards (1.5-module design saves 50% space vs. standard 3-module units)
Combination with iC60 miniature circuit breakers for a complete solution against overload, short-circuit and earth leakage
Key Installation & Operating Instructions
- Must be used together with Schneider iC60 series miniature circuit breakers
- Mounted on the right side of the iC60 MCB and fixed with dedicated clips
- Operating temperature range: -25°C to +40°C
- Pollution degree: 3
- Rated impulse withstand voltage (Uimp): 6kV
A9Q41225 is a compact earth leakage protection solution launched by Schneider for specific markets. With its space-saving 1.5-module design, it delivers the same 2P 25A 30mA Type AC earth leakage protection as standard 3-module products, making it an ideal choice for space-efficient final distribution systems in residential and commercial buildings.
