Hirschmann RS20-0800M2TDN5
Hirschmann RS20-0800M2TDN5 is an industrial Ethernet switch model.
- Scomposizione del codice modello (OpenRail Series Naming Convention)
| Campo | Senso | Descrizione |
| RS20 | Switch Series | Integrated industrial Ethernet switch with Fast Ethernet uplink, DIN‑rail mountable, design senza ventola |
| -800 | Total Ports | 8 Fast Ethernet ports (massimo. 100 Mbit/s) |
| M2 | Uplink Port 1 | 100Base‑FX multimode fiber (MM), SC connector, transmission distance 2 km |
| T | Uplink Port 2 | 10/100Base‑TX twisted pair, Connettore RJ45 |
| D | Versione del software | Layer 2 Enhanced managed software, supporting VLAN, IGMP snooping, ecc. |
| N5 | Special Configuration | Likely indicates extended temperature range (-40°C fino a +70°C) or other custom options (subject to official specifications) |
- Specifiche tecniche principali (RS20-0800 Series Standard)
| Parametro | Dettagli |
| Configurazione della porta | 6 × 10/100Base‑TX RJ45 copper ports + 2 uplink ports (1 × multimode SC fiber port + 1 × RJ45 port) |
| Modalità di commutazione | Store and Forward |
| Supporto per la ridondanza | HIPER‑Ring (recovery time < 50 SM), MRP, RSTP and other industrial ring protocols |
| Gestione | Web interface, SNMP, CLI |
| Alimentazione elettrica | 9.6–60 VDC / 18–30 VAC (redundant power input) |
| Temperatura operativa | Standard: 0°C fino a +60°C; Extended: -40°C fino a +70°C |
| Classe di protezione | IP30 (pannello frontale), alloggiamento in metallo, shock and vibration resistant |
| Montaggio | Guida DIN (IN 50022 standard) |
III. Standard Reference Models & Numeri d'ordine
The model RS200800M2TDN5 you referenced is likely a custom version. The closest standard models are:
- RS20-0800M2TSDAE (Ordine n.: 943434-XXX)
6 ×RJ45 + 1 × MM SC fiber port + 1 × RJ45 port, Layer 2 Enhanced software
- RS20-0800M2M2TDAE (Ordine n.: 961455-94)
6 ×RJ45 + 2 × MM SC fiber ports, Layer 2 Enhanced software, standard temperature
- Applicazioni & Vantaggi
- Automazione industriale: Production lines, robot control, PLC networking
- Controllo del processo: Reliable communication in harsh environments such as chemical, energia, trattamento dell'acqua
- Hybrid Networks: Supports fiber-twisted pair hybrid topology, extending transmission distance and improving anti-interference performance
- Key Benefits:
Industrial-grade reliability: senza ventola, wide temperature range, EMC resistance
Fast network recovery: HIPER-Ring ensures uninterrupted critical services
Flexible management: supports multiple industrial protocols for easy system integration
- Modelli alternativi & Compatibilità
| Modello alternativo | Differenza |
| RS20‑0800S2TSDAE | Single‑mode fiber (SM) instead of multimode, transmission distance up to 20 km |
| RS20‑0800T1T1SDAE | Dual RJ45 uplinks, no fiber ports |
| RSB20‑0800M2T | Unmanaged version, configurazione semplificata, costo inferiore |
- Note & Informazioni supplementari
- Verifica del modello: It is recommended to confirm the full model (including hyphens and suffixes), as order numbers vary significantly by configuration.
- Official Documentation: Specific details are subject to the official Hirschmann documentation.
- Supporto tecnico: For detailed parameters or custom configurations, contact Hirschmann China technical support or authorized distributors.
Vii. Quick Purchasing Information
Common order number for the standard model RS20-0800M2TSDAE: 943434-0XX (XX = configuration code). Latest pricing and lead times are available via the Belden website, authorized agents, or industrial automation platforms.
Complete Model List of Hirschmann Industrial Ethernet Switches
Hirschmann’s industrial Ethernet switch portfolio includes unmanaged, light managed, fully managed, and modular platforms. Below is a complete categorized model list for selection and replacement reference.
- OpenRail Compact Series (RS20 / RS22 / RS30 / RS32 / RS40)
Caratteristiche principali: Montaggio su guida DIN, senza ventola, redundant power input, HIPER-Ring redundancy (recovery < 50 SM)
1.1 RS20 Series (Fast Ethernet uplink, 4–24 ports)
| Modello base | Configurazione della porta | Typical Suffixes | Descrizione |
| RS20‑0400 | 3×RJ45 + 1×uplink | M2T1 / M2M2 / S2T1 / S2S2 / T1T1 | 4‑port entry model, multimode / single‑mode / copper uplink options |
| RS20‑0800 | 6×RJ45 + 2×uplink | M2T1 / M2M2 / S2T1 / S2S2 / T1T1 | 8‑port standard model, per esempio., RS20‑0800M2TDN5 |
| RS20‑1600 | 14×RJ45 + 2×uplink | M2T1 / M2M2 / S2T1 / S2S2 / T1T1 | 16‑port expanded model |
| RS20‑2400 | 22×RJ45 + 2×uplink | M2T1 / M2M2 / S2T1 / S2S2 / T1T1 | 24‑port high‑density model |
Spiegazione del suffisso:
M2 = Multimode SC fiber (100Base-FX, 2 km)
S2 = Single-mode SC fiber (100Base-FX, 20 km)
T1 = RJ45 copper (10/100Base-TX)
D = Layer 2 Migliorato
P = Layer 3 Professionale
E = Standard temperature (0°C~+60°C)
U = Extended temperature (-40°C~+70°C)
HC = Enhanced immunity / power industry certification
Typical Complete Models:
RS20-0800M2TSDAE (943434-XXX) – 6×RJ45 + 1×MM SC + 1×RJ45, enhanced management, standard temp
RS20-1600T1T1SDAPHC – 14×RJ45 + 2×RJ45, professional management, wide temp, power certification
1.2 RS30 Series (Fast Ethernet + 2 Gigabit uplinks, 8–24 ports)
| Modello base | Configurazione della porta | Typical Suffixes | Descrizione |
| RS30‑0802 | 6×RJ45 + 2×Gigabit uplink | T1T1 / SFP / SFP | 8 porti + 2 Gigabit copper/SFP uplinks |
| RS30‑1602 | 14×RJ45 + 2×Gigabit uplink | T1T1 / SFP / SFP | 16 porti + 2 Gigabit uplinks |
| RS30‑2402 | 22×RJ45 + 2×Gigabit uplink | T1T1 / SFP / SFP | 24 porti + 2 Gigabit uplinks |
1.3 RS40 Series (Full Gigabit, 9 porti)
| Modello base | Configurazione della porta | Typical Suffixes | Descrizione |
| RS40‑0900 | 8×RJ45 + 1×SFP uplink | T1SFP | 9‑port full Gigabit with one SFP slot |
1.4 Modelli speciali (RS22 / RS32)
RS22: Enhanced RS20 with PoE (IEEE 802.3af/at)
RS32: Enhanced RS30 with PoE (fino a 4 PoE ports)
- OpenRail Modular Series (MS20 / MS30 / MS40)
Caratteristiche principali: Hot-swappable media modules, flexible port type/quantity, expandable backplane
| Serie | Modello base | Module Slots | Espandibilità | Descrizione |
| MS20 | MS20‑0800 | 2 Fast Ethernet modules | Fixed backplane | 8‑port modular entry model |
| MS20 | MS20‑1600 | 4 Fast Ethernet modules | Expandable backplane | 16‑port modular expanded model |
| MS30 | MS30‑0802 | 2 FE + 2 Gigabit modules | Expandable backplane | 8 porti + 2 Gigabit uplinks |
| MS40 | MS40‑0900 | 8 Gigabit modules + 1 uplink | Expandable backplane | Full Gigabit modular platform |
| MS4128 | PowerMICE | 16×FE + 4×Gigabit | Expandable to 24 porti | Layer 3 routing switch |
III. Unmanaged Switch Series
3.1 SPIDER Series (Compact DIN-rail)
| Serie | Esempio di modello | Configurazione della porta | Caratteristiche |
| SPIDER | SPIDER‑8TX/8T1 | 8×RJ45 | Fast Ethernet unmanaged, plug-and-play |
| SPIDER‑SL | SPIDER‑SL‑24‑04T1M2 | 20×RJ45 + 4×uplink | Light managed, basic VLAN support |
| SPIDER III | SPIDER III‑16TX | 16×RJ45 | Gigabit unmanaged, high density |
3.2 GECKO Series (Ultra-compact)
| Modello | Configurazione della porta | Caratteristiche |
| GECKO‑4TX | 4×RJ45 | Compact size 75×55×105 mm, ideal for confined spaces |
| GECKO‑4FX‑MM | 4×MM SC fiber ports | Fiber‑only, transmission distance 2 km |
- Light Managed Switch Series
4.1 LEMUR Series (Conveniente)
| Modello | Configurazione della porta | Management Features |
| LEMUR‑8TX | 8×RJ45 | Gestione web, basic VLAN, QoS |
| LEMUR‑16TX | 16×RJ45 | Lightweight configuration for small‑to‑medium industrial networks |
4.2 BOBCAT / BRS Series (Entry-level managed)
| Serie | Modello | Caratteristiche |
| BOBCAT | BOBCAT‑8TX | HIPER‑Ring support, recovery < 50 SM |
| BRS | BRS‑16TX | Redundant power input, alarm relay output |
- Fully Managed Rack-mount Switch Series
5.1 MACH Series (Nucleo / Distribution Layer)
| Serie | Esempio di modello | Configurazione della porta | Caratteristiche |
| MACH 1000 | MACH 1020 / 1030 / 1040 | 24×FE + 4×Gigabit | Designed for substations, IEC61850‑3 certified |
| MACH 4000 | MACH 4024 / 4048 | 48×Gigabit + 4×10G | Data center‑class redundancy, MPLS‑TP support |
| MACH 104‑28 | 24×FE + 4×Gigabit | Layer 3 routing, IPv6 support |
5.2 MSP Series (Modular Rack-mount)
| Modello | Slot Count | Espandibilità | Caratteristiche |
| MSP 3000 | 6 slot | FE / Gigabit / 10G module support | Highly scalable for large industrial networks |
- Serie di applicazioni speciali
6.1 Ruggedized Switches (RSR / RSP Series)
| Serie | Modello | Caratteristiche | Applicazioni |
| RSR | RSR20 / RSR30 | -40°C~+70°C, Protezione IP40 | Rail transit, harsh outdoor environments |
| RSP | RSPL / RSPM / RSPE | Ampia temperatura + PoE | Integrated industrial automation + video surveillance |
6.2 IP67-rated Switches
| Serie | Modello | Configurazione della porta | Classe di protezione |
| OCTOPUS | OCTOPUS‑10TX | 10×RJ45 | IP67 dust‑ and waterproof, outdoor installation |
| OCTOPUS PoE | OCTOPUS‑8TX‑PoE | 8×RJ45 PoE+ | IEEE 802.3af/at, power for outdoor devices |
6.3 Power Industry Special Series
| Modello | Certificazione | Caratteristiche |
| RS20‑0800M2TSDAEHC | IEC61850‑3 / IEEE1613 | Enhanced immunity, ampia temperatura |
| MACH 1040‑28HC | IEC61850‑3 | Layer 3 routing, GOOSE messaging support |
Vii. General Model Naming Convention
Hirschmann switch models follow a standardized structure, using RS20-0800M2TDN5 as an example:
| Campo | Senso | Opzioni |
| RS20 | Serie di prodotti | RS20 / RS30 / RS40 / MS20 / MACH, ecc. |
| -800 | Total Ports | 0400(4) / 0800(8) / 1600(16) / 2400(24) |
| M2 | Uplink Port 1 | M2 (MM SC) / S2 (SM SC) / T1 (RJ45) |
| T | Uplink Port 2 | Come sopra; omitted if not present |
| D | Livello software | D (Migliorato) / P (Professionale) / Nessuno (Unmanaged) |
| N5 | Special Config | E (Standard Temp) / U (Wide Temp) / HC (Power Cert) |
VIII. Selezione & Guida alla sostituzione
- Management Level:
Basic connectivity: Unmanaged SPIDER / GECKO
Automazione industriale: Fully managed RS20 / RS30 (HIPER-Ring supported)
Core network: Layer 3 MACH series
- Port Type Matching:
Lunga distanza: S2 single-mode fiber uplink (fino a 20 km)
Short distance + anti-interference: M2 multimode fiber (2 km)
Pure copper network: T1 copper uplink
- Temperatura & Ambiente:
Standard industrial: Suffix E (0°C~+60°C)
All'aperto / wide temp: Suffix U (-40°C~+70°C)
Power industry: Suffix HC (IEC61850-3 certified)
