Quick Overview of Core Specifications
製品タイプ: Standard Managed 産業用イーサネットスイッチ of Schneider Modicon series
メーカー: シュナイダーエレクトリック, headquartered in France
Primary Production Location: ドイツ (site for final critical assembly processes)
製品のポジショニング: Industrial automation networking device as replacement for legacy TCSESM043F2CU0
ポート構成: 4×RJ45 Copper Ports (10/100Mbps) + 2×SC Multi-mode Fiber Ports (100Mbps), DINレール取付可能
- Model Code Definition Table
| コードセグメント | コード | 意味 |
| MCS | MCS | Modicon Connectivity System, Schneider Modicon networking product line |
| ESM | ESM | Ethernet Standard Managed, standard managed Ethernet switch |
| 63 | 63 | Port layout: 合計 6 ports consisting of two types (4 銅 + 2 fiber) |
| F2 | F2 | Fiber interface: 2 multi-mode fiber ports (100BASE-FX) |
| CU | CU | Copper interface: RJ45 copper ports (10/100BASE-TX), 標準構成 |
| 0 | 0 | リビジョン: standard base version |
Ⅲ. Core Specification List
| カテゴリ | Technical Parameter | 備考 |
| ポート構成 | ||
| 合計ポート数 | 6 | 4 銅 + 2 fiber |
| Copper Ports | 4×RJ45 (10/100BASE-TX) | STP cable, CAT5E or higher grade |
| Fiber Ports | 2×SC Duplex (100BASE-FX) | Multi-mode fiber; 伝送距離: 4km / 5km |
| Performance Specs | ||
| Switching Capacity | 1.2Gbps | Non-blocking wire-speed forwarding |
| 管理機能 | Standard Managed | Port Security, IP/MAC Binding, RADIUS Authentication supported |
| Redundancy Protocol | MRP Ring supported | Ring recovery time <20MS |
| 力 & 環境データ | ||
| 動作電圧 | 9.6–32VDC | Wide-range input for industrial power supply |
| 消費電力 | 7W | 低消費電力設計 |
| 動作温度. | 0℃～+60℃ | Designed for harsh industrial ambient conditions |
| 侵入保護 | IP30 | 防塵, キャビネットの設置に適しています |
| 取り付け | 標準35mm DINレール | EN準拠 50022 |
| 認証 | CE, UL, RCM, EAC, UKCA, DNV | Conforms to UL 61010 & EN/IEC 61131 |
- Full Series Cross Reference (MCS ESM 6-Port Family)
| 部品番号 | Port Layout | Fiber Type | Copper Interface | Special Feature |
| MCSESM063F2CU0 | 4Cu+2Fiber | マルチモード (SC) | Standard RJ45 | 基本マネージド |
| MCSESM063F2CS0 | 4Cu+2Fiber | マルチモード (SC) | Standard RJ45 | Enhanced Security Function |
| MCSESM063F2LU0 | 4Cu+2Fiber | シングルモード (SC) | Standard RJ45 | Long-distance Transmission |
| MCSESM063F2LS0 | 4Cu+2Fiber | シングルモード (SC) | Standard RJ45 | シングルモード + Security Option |
- 応用分野 & Project Cases
- 該当するシナリオ
Factory Automation: PLC-HMI interconnection, sensor data collection, production line equipment networking
プロセス制御: DCS network for chemical, petrochemical and water treatment industries
Smart Manufacturing: 業界 4.0 IIoT deployment with OPC UA protocol support
重要なインフラストラクチャ: Backbone networking for power, railway transit and building automation
Harsh Working Conditions: Replaces commercial switches in dusty, vibratory and temperature-fluctuating industrial sites
- 代表的な応用例
場合: Auto Component Production Line Networking
Field Devices: 20 Robots, 10 センサー, 5 HMIs
解決: 3 units of MCSESM063F2CU0 forming MRP redundant ring to connect field equipment to central PLC
利点: 産業グレードの信頼性, high EMC immunity, fast ring recovery, stable under workshop vibration
- 推奨されないアプリケーション
Ambient temperature exceeding >60°C or below <0℃ (Wide-temperature variant required)
Heavy corrosive gas environment (Sealed industrial switch needed)
Data rate over 100Mbps (Gigabit model such as MCSESM203 series required)
- 航空輸送のコンプライアンス & 認証
Shipping Classification: Non-dangerous goods without built-in lithium battery, compliant with IATA DGR
CE証明書: ENに準拠 60947-4-1, Cert No.: CE 0123
UL証明書: Complies with UL 508, File No.: E249461
RoHS準拠: Meets Directive 2011/65/EU, free of restricted hazardous substances
Ⅶ. Order Information
注文コード: MCSESM063F2CU0
Minimum Pack Quantity: 1 unit per carton
保証期間: 12 月
推奨アクセサリ: SC multi-mode fiber patch cord, DIN rail mounting clip, DC power adapter
Full Detailed Technical Datasheet for Schneider MCSESM063F2CU0 Industrial Switch
- 主要な概要
モデル: MCSESM063F2CU0
Product Line: Schneider Modicon MCS (Modicon Connectivity System) Standard Managed Industrial Ethernet Switch
メーカー: シュナイダーエレクトリック (HQ in France, major production in Germany)
ポート構成: 4×10/100M RJ45 + 2×100M SC Multi-mode Fiber, 合計 6 ポート
Product Position: Industrial automation networking replacement for obsolete TCSESM043F2CU0
取り付け: Standard 35mm DIN rail per EN 50022
- Complete Model Code Explanation
| コードセグメント | コード | Full Description |
| MCS | MCS | Modicon Connectivity System, dedicated for industrial automation networking |
| ESM | ESM | Ethernet Standard Managed, basic full-function managed switch |
| 63 | 63 | 合計 6 ports in two categories: 4 銅 + 2 fiber |
| F2 | F2 | Two multi-mode 100BASE-FX ports with SC duplex connector |
| CU | CU | RJ45 copper 10/100BASE-TX, STP CAT5E & above cabling |
| 0 | 0 | Standard base revision without extra customized options |
Ⅲ. Itemized Detailed Technical Specifications
- Physical Layer & Port Parameters
| アイテム | 評価 | 仕様 |
| Copper Ports | ||
| 量 | 4 | Shielded RJ45 socket |
| スピード | 10/100Mbps auto-negotiation | Full/Half duplex auto-sensing |
| 標準 | IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX | Auto MDI/MDI-X crossover |
| Cabling | STP CAT5E or higher | マックス. 100m transmission |
| Port Surge Protection | 内蔵 | Compliant with IEC61000-4-5 for industrial EMC |
| Fiber Ports | ||
| 量 | 2 | SC Duplex multi-mode fiber receptacle |
| Rate | Fixed 100Mbps | Full-duplex per 100BASE-FX |
| Operating Wavelength | 850nm | Standard for multi-mode fiber |
| Transmission Distance | 4km(50/125μm),5km(62.5/125μm) | IEEE802.3u compliant |
| Fiber Spec | MMF 62.5/125μm & 50/125μm | Compatible with SC/ST connectors |
- Switching & Network Performance
| アイテム | 価値 | 詳細 |
| Switching Capacity | 1.2Gbps | Store-and-forward non-blocking wire-speed |
| Packet Forwarding Rate | 0.89Mpps | Calculated under 64-byte frame for full wire-speed |
| Port Buffer | 16KB | Independent buffer per port for traffic optimization |
| MAC Address Table | 8K entries | Auto-learning & aging, static MAC configurable |
| VLAN Capacity | まで 64 VLAN | IEEE802.1Q tagged & port-based VLAN |
| 冗長性 | MRP | Recovery <20ms for high network availability |
| QoS | 4 priority queues | IEEE802.1p & DSCP based traffic prioritization |
| サポートされているプロトコル | イーサネット/IP, TCP/IP, UDP, ICMP, ARP, DHCP, DNS, SNMPv1/v2c/v3, HTTP/HTTPS, Telnet/SSH, LLDP, SNTP, RSTP, MRP | Full industrial protocol compatibility |
- 電気 & Power Specifications
| アイテム | パラメータ | 説明 |
| 入力電圧 | 9.6~32VDC (Nominal 12/24VDC) | Wide-range industrial DC input |
| Power Terminal | 6-pin pluggable terminal | Reverse polarity protection for easy wiring |
| Max Power Draw | 7W | Low energy consumption |
| 過電流保護 | Built-in short-circuit safeguard | Prevents damage from abnormal power supply |
| Alarm Relay Output | 1 Form-C dry contact (1A@250VAC /1A@30VDC) | Alarms for power fail, link down, device fault, over-temp & MRP ring failure |
- 機械式 & Physical Dimension
| アイテム | Spec | 述べる |
| 寸法(幅×奥行き×高さ) | 57mm×104mm×138mm (142.8mm in partial datasheet) | Compact cabinet-saving design |
| 正味重量 | ~0.4kg | 軽量で設置が簡単 |
| マウント | 35mm DIN rail EN50022 | Snap-on fast installation |
| Enclosure Rating | IP30 | Dust-proof for indoor cabinet |
| ハウジング | Metal casing | Improved heat dissipation & EMC耐性 |
| LED Indicators | 力, Link/Activity, スピード, 故障, MRP Ring | Real-time operating status visualization |
- 環境 & Reliability Index
| アイテム | 評価 | 標準 |
| 動作温度. | 0℃～+60℃ | Tolerates factory ambient fluctuation |
| Storage Temp. | -40℃～+85℃ | Suitable for harsh logistics & ストレージ |
| 相対湿度 | 10%~95% non-condensing | High-humidity workshop applicable |
| 耐振動性 | 5–150Hz,1g | IEC60068-2-6 |
| 耐衝撃性 | 15g,11MS | IEC60068-2-27 against transport impact |
| EMC | EN61000-6-2(Immunity), EN61000-6-4(Emission) | Robust anti-interference for industrial automation |
| MTBF | >100,000 営業時間 | Long service life to reduce maintenance cost |
- 管理 & Security Functions
| カテゴリ | Feature List | |
| Management Access | WebGUI, Telnet, SSH, SNMPv1/v2c/v3, Modbus TCP | Multi-channel flexible configuration |
| Security Features | Port Security, IP/MAC Binding, RADIUS, HTTPS/SSH Encryption, ACL | Unauthorized access prevention |
| 診断 | Port statistics, error counter, cable test, internal temperature monitoring | Fast troubleshooting |
| Firmware Upgrade | Remote upgrade via Web or TFTP | Convenient function expansion & bug fix |
| Configuration Management | Config backup/restore, auto-save | Simplify site maintenance |
- コンプライアンス & 認証
| Certificate | 標準 | 注記 |
| Safety Cert | CE, UL, CSA, RCM, EAC, UKCA, DNV | UL61010, EN/IEC61131, EN/IEC62368-1 |
| Ethernet Standard | IEEE802.3/3u/1Q/1p/3ad | Global mainstream Ethernet compliance |
| Industrial Standard | IEC61000-6-2, IEC61000-6-4, IEC61850-3 | Approved for power & 鉄道輸送 |
| 環境 | RoHS 2011/65/EU | Lead-free eco-friendly construction |
| ロジスティクス | Non-hazardous per IATA DGR | Safe for global air freight |
- Industry Application Matching
- 推奨アプリケーション
Automated Production Line: PLC-HMI communication, センサー & robot control networking
Process Industries: DCS backbone for chemical, 油 & 水処理
スマートファクトリー: IIoT & Industry4.0 deployment supporting OPC UA
インフラストラクチャー: Power plant, railway & building automation core network
Rugged Sites: Replace consumer-grade switches in dusty, vibratory workshops
- 推奨されないシナリオ
動作温度 >60°C or <0℃ (Wide-temperature model required)
Heavy corrosive vapor environment (Hermetically sealed switch required)
Requirement over 100Mbps throughput (Gigabit MCSESM203 series needed)
Ultra-long fiber transmission (Single-mode variant MCSESM063F2LU0 recommended)
- 注文 & Spare Parts Info
| アイテム | 詳細 |
| 部品番号. | MCSESM063F2CU0 |
| Minimum Pack | 1pc |
| 保証 | 12 月 |
| 推奨アクセサリ | SC MM fiber cord (62.5/125μm &50/125μm), DINレールクリップ, 12/24VDC power adapter |
| 代替機種 | Legacy TCSESM043F2CU0; upgraded 8-port MCSESM083F2CU0 |
- Selection Summary Tips
- Core Spec: 4Cu+2Multi-mode Fiber, standard managed, 1.2Gbps switching, MRP ring redundancy
- 力: 9.6~32VDC wide input universally matching industrial field power supply
- マウント: 標準35mm DINレール, IP30 metal casing with superior heat dissipation
- 安全: Port lock, IP/MAC bind & RADIUS; MTBF>100,000h for stable operation
- Target Industry: General manufacturing, 水処理, 発電 & rail automation
