야스카와 인버터 CIMR-HB4A0009FBC

야스카와 인버터 CIMR-HB4A0009FBC (Marked as 15kW)

Yaskawa inverter model CIMR-HB4A0009FBC is actually a 2.2kW unit of the H1000 series for 3-phase 400V supply, not a 15kW model. The corresponding 15kW models are CIMR-HB4A0039FBC (헤비 듀티) and CIMR-HB4A0031FBC (standard duty). Below are the core parameters, functional features and key selection points of the CIMR-HB4A0009FBC model:

핵심 기술 매개변수

기능적 특징

1. Heavy Duty Adaptation: Specifically designed for heavy-duty working conditions such as cranes, crushers and belt conveyors, with high overload and impact resistance.
2. 정밀한 제어: 센서리스 벡터 제어 지원, featuring stable high torque output at low speed, fast torque response and vibration/over-shoot suppression.
3. 안전하고 신뢰할 수 있는: Equipped with comprehensive protection functions including overcurrent, 과전압, 저전압, overheating and ground fault protection, 혹독한 산업 환경에 적합.
4. 유연한 확장: Supports optional accessories such as PG cards and I/O expansion cards, and is compatible with a variety of fieldbuses to meet complex control requirements.

Corresponding 15kW Models & 선택 팁

15kW Heavy Duty: CIMR-HB4A0039FBC (suitable for continuous high-load scenarios)

15kW Standard Duty: CIMR-HB4A0031FBC (suitable for normal working conditions)

모델을 선택할 때, verify the load type, 정격 전류, power supply specifications and communication/expansion requirements to avoid mismatch between power and working conditions.

Common Application Scenarios

Applicable to heavy machinery in mining, 야금, building materials and other industries, such as hoists, mixers and calenders that require high torque output and frequent start-stop operations.

The following is a complete parameter comparison between Yaskawa CIMR-HB4A0009FBC and its corresponding 15kW models, as well as recommended direct replacement models of the same power from ABB, Siemens and Schneider.

1. 핵심 매개변수 비교표 (Yaskawa H1000 Series)

1. Cross-brand Direct Replacement Models for 15kW Heavy Duty Inverters

All the following models are adapted to 3-phase 380-480V power supply, 15kW heavy duty working conditions (150% overload for 60s), and support vector control and mainstream communication protocols:

III. Key Tips for Model Selection & 대사

1. Load Matching as Priority

Confirm the load type (constant torque/variable torque), overload requirement (120%/150%) and duty type (S1/S3), and prioritize models rated for the corresponding type.

For heavy-duty scenarios (예를 들어. 크레인, 파쇄기), CIMR-HB4A0039FBC or equivalent heavy-duty models from other brands must be selected to avoid damage caused by long-term overload.

2. Key Parameter Verification

정격전류: ≥34A required for 15kW heavy duty, ≥27A for standard duty.

Control functions: 벡터 제어, PG feedback (encoder interface) and communication protocols (Modbus/Profinet, 등.) must be compatible with the original system.

Safety functions: STO (세이프 토크 오프), EDM (외부 장치 모니터링) and other functions must match the safety grade requirements of the equipment.

3. 설치 & 확장

Installation dimensions: The 15kW model of Yaskawa H1000 series is about 260×550×190mm; verify the cabinet space before replacement.

액세서리 호환성: PG cards, I/O expansion cards, braking resistors and other accessories must be compatible with the new model to avoid function loss.

1. Replacement Implementation Suggestions
2. Record the parameters of the original inverter (motor nameplate, V/f curve, acceleration/deceleration time, protection thresholds, 등.) before replacement for quick commissioning of the new model.
3. Perform motor auto-tuning (static/dynamic) on the new model to ensure the accuracy of vector control and stability of torque output.
4. Verify the pin definitions for communication and I/O wiring to avoid equipment abnormalities caused by signal errors.
5. Monitor key indicators such as current, voltage and temperature during the test phase to verify the replacement effect and adjust parameters accordingly.
