- Model Segment Definition
Meaning of each part of TS1070SI:
| Segment | Description |
| TS | Product series code, stands for Fuji Monitouch TECHNOSHOT HMI series |
| 1070 | Base model number; 7 = 7-inch display, 10 = 1000 series, 70 = specific specification code |
| S | Standard version with basic functions |
| I | Network enhanced version with built-in Ethernet port (core difference from TS1070S without “I”) |
Core Difference:
TS1070SI is equipped with one additional RJ-45 Ethernet port compared with TS1070S, supporting advanced functions such as VNC remote operation, FTP file management and IP camera display.
- Core Specifications
| Category | Specifications |
| Display System | • Screen Size: 7.0-inch widescreen (16:9) |
| • Display Type: Color TFT LCD | |
| • Resolution: 800×480 pixels (WVGA) | |
| • Display Colors: 65,536 colors (64K) | |
| • Backlight: Long-life LED | |
| • Touch Type: Analog resistive touch screen | |
| Memory & Storage | • FROM (Flash): 26MB (2.2 times larger than previous generation) |
| • SRAM: 128KB | |
| • Supports data storage, recipe management and historical logging | |
| Communication Interfaces | • COM1 (D-Sub 9-pin Female): RS-422/RS-485 (4-wire/2-wire), up to 187500bps (Siemens MPI/PPI only) |
| • COM2 (D-Sub 9-pin Male): RS-232C | |
| • COM3 (D-Sub 9-pin Male): RS-422/RS-485 (2-wire) | |
| • LAN (RJ-45): 100BASE-TX/10BASE-T (TS1070SI only) | |
| • USB-A: 1 port for external device connection | |
| • USB mini-B: 1 port for programming & data transfer | |
| Power Supply | • Rated Voltage: 24VDC (allowable tolerance ±10%) |
| • Max Power Consumption: ≤11W | |
| • Instant Power Failure Resistance: ≤1ms | |
| • Inrush Current: ≤7A (6ms, 25°C) | |
| Physical Dimensions | • Panel Dimension: 198.8×141.8×38.0mm |
| • Cutout Dimension: 189.0×134.0mm (Tolerance +0.5/-0mm) | |
| • Mounting: Embedded panel mount | |
| Protection Grade | • Front Panel: IP65 (with waterproof gasket), IP40 (without gasket) |
| • Rear Housing: IP20 | |
| Environmental Ratings | • Operating Temperature: 0~50°C (Wet bulb ≤39°C) |
| • Operating Humidity: ≤85%RH (Non-condensing) | |
| • Storage Temperature: -10~60°C | |
| • Pollution Degree: Level 2 | |
| • Max Altitude: 2000m | |
| • Vibration Resistance: 5~9Hz amplitude 3.5mm; 9~150Hz acceleration 1G (10 cycles each for X/Y/Z axis) | |
| • Shock Resistance: 10G (3 impacts each for X/Y/Z axis) | |
| Certifications | CE, KC, UL, cUL, UKCA |
- Accessory List
3.1 Standard Accessories
Main Unit TS1070SI ×1
Mounting Waterproof Gasket ×1
Mounting Clips ×4
Operation Manual (CD / Electronic Version) ×1
Programming Cable (USB mini-B) ×1
Power Terminal Block ×1
3.2 Optional Accessories
| Accessory | Purpose |
| Spare LED Backlight | Screen backlight replacement |
| Touch Screen Protective Film | Extend touch panel service life |
| Mounting Bracket | Special installation requirements |
| Communication Expansion Module | Expand communication ports |
| Data Memory Card | Expand storage capacity |
| Remote Access Software | VNC client & FTP management tool |
- Competitor & Cross-Brand Equivalent Comparison
| Brand | Model | Screen | Resolution | Ethernet | Price Range | Main Advantages |
| Fuji | TS1070SI | 7″ | 800×480 | Yes | Medium | Cost-effective, 3 COM ports, VNC remote |
| Mitsubishi | GT2307-VTBA | 7″ | 800×480 | Yes | Medium-High | Seamless integration with Mitsubishi PLC |
| Siemens | KTP700 Basic | 7″ | 800×480 | Yes | High | Fully integrated automation, Profinet |
| Omron | NB7W-TW00B | 7″ | 800×480 | Yes | Medium | User-friendly interface, easy programming |
| Weinview | TK6071IP | 7″ | 800×480 | Yes | Low | Affordable price, wide compatibility |
| Fuji | TS1070S | 7″ | 800×480 | No | Medium-Low | Basic version without network function |
- Selection Guidelines & Replacement Solutions
5.1 Core Selection Criteria
Network Required: Remote monitoring, FTP transfer or IP camera → Choose TS1070SI (with Ethernet)
Basic Local Use: Local operation only, no network → Choose TS1070S (higher cost performance)
Multi-PLC Connection: Simultaneously connect up to 8 different PLC brands → Both models supported (3 COM ports)
Mounting Space: Panel cutout 189×134mm, depth 38mm, suitable for compact installation
5.2 Recommended Replacement Models
| Application Scenario | Recommended Model | Reason |
| Small equipment, budget limited | TS1070S | Full basic functions, better price |
| Production line monitoring & remote access | TS1070SI | Ethernet + VNC, supports remote maintenance |
| Large system & multi-HMI linkage | TS1100SI (10.2″) | Larger screen with identical network functions |
| Replace old legacy HMI | TS1070SI | Standard cutout, software compatible, fast upgrade |
| Mitsubishi PLC dedicated | Mitsubishi GT2307-VTBA | Optimized bus, faster data exchange |
| Siemens system | Siemens KTP700 | Full integration, seamless Step7 connection |
5.3 Key Technical Advantages
- Multi-Protocol Support: Connect up to 8 PLC brands simultaneously, including Fuji, Mitsubishi, Siemens, Omron, etc.
- Remote Capability: Built-in VNC server for remote device operation and monitoring over network
- Large Storage: 26MB FROM memory for massive screens, recipes and historical data
- Rugged Design: IP65 front panel for harsh industrial environments
- Global Certifications: CE/KC/UL/cUL for worldwide market deployment
Fuji TS1070SI is a 7-inch WVGA industrial HMI belonging to the TECHNOSHOT TS1000 Smart series. Its core strengths are built-in Ethernet and triple serial port design, supporting VNC remote operation, FTP file management and multi-PLC connection.
It is ideal for industrial automation scenarios requiring remote monitoring and multi-device integration, especially for small and medium production lines and machinery control. Select between TS1070SI and TS1070S according to network demand and budget, or choose HMI of the same PLC brand for optimal compatibility.
Full Complete Model List of Fuji MONITOUCH HMI (Latest 2026 Version)
Classified into Active Standard Series, High-End Flagship, IoT Intelligent, Economy Entry, Discontinued Legacy Models. Includes full part numbers, key specs, suffix definition and cross-reference replacement table, covering all Fuji HMI product lines.
- TS1000 Smart Series (Active Mainstream · General Economy Grade)
New TECHNOSHOT cost-effective series, triple COM ports, wide temperature & IP65 front panel, direct drop-in replacement for legacy UG series; TS1070SI belongs to this series.
| Full Model | Screen Size | Resolution | Touch Type | LAN Port | Widescreen / 4:3 | Key Features |
| TS1057S | 5.7″ | 320×240 QVGA | Analog Resistive | No | 4:3 Standard | Basic control for small machines |
| TS1057SI | 5.7″ | 320×240 QVGA | Analog Resistive | Built-in RJ45 | 4:3 Standard | Small device + remote monitoring |
| TS1070S | 7″ | 800×480 WVGA | Analog Resistive | No | 16:9 Widescreen | 7″ basic local control |
| TS1070SI | 7″ | 800×480 WVGA | Analog Resistive | Built-in RJ45 | 16:9 Widescreen | 7″ + VNC remote + FTP |
| TS1070CI | 7″ | 800×480 WVGA | Capacitive | Built-in RJ45 | 16:9 Widescreen | Industrial cleanroom capacitive screen |
| TS1100S | 10.2″ | 1280×800 WXGA | Analog Resistive | No | 16:9 Widescreen | Mid-large production line monitoring |
| TS1100SI | 10.2″ | 1280×800 WXGA | Analog Resistive | Built-in RJ45 | 16:9 Widescreen | Mid-large screen + remote maintenance |
| TS1100CI | 10.2″ | 1280×800 WXGA | Capacitive | Built-in RJ45 | 16:9 Widescreen | Mid-large capacitive touch |
| TS1120S | 12.1″ | 800×600 SVGA | Analog Resistive | No | 4:3 Standard | Large machine operation panel |
| TS1120SI | 12.1″ | 800×600 SVGA | Analog Resistive | Built-in RJ45 | 4:3 Standard | Large machine + remote monitoring |
| TS1150S | 15″ | 1024×768 XGA | Analog Resistive | No | 4:3 Standard | Workshop main control large screen |
| TS1150SI | 15″ | 1024×768 XGA | Analog Resistive | Built-in RJ45 | 4:3 Standard | Workshop main control + remote management |
General Specs: 24VDC power supply, 3×RS232/422/485 serial ports, dual USB (A + mini-B), IP65 front panel, supports up to 8 PLC brands simultaneously.
- TS4000 Series (2026 New · Widescreen High-Enhanced Series)
Upgraded from TS1000 with higher resolution, stronger performance, Ethernet standard on all models.
| Full Model | Screen Size | Resolution | Touch Type | Ethernet | Key Features |
| TS4070i | 7″ | 1024×600 WSVGA | Capacitive | Dual Gigabit | HD display, capacitive multi-touch |
| TS4100i | 10.1″ | 1280×800 WXGA | Capacitive | Dual Gigabit | Widescreen HD, multi-touch |
| TS4120i | 12.1″ | 1280×800 WXGA | Capacitive | Dual Gigabit | Large HD screen, industrial protection |
| TS4156i | 15.6″ | 1920×1080 FHD | Capacitive | Dual Gigabit | Full HD, edge computing |
- V Series (High-End Flagship · Large Factory Automation / High-Speed Bus System)
3.1 V8 Series (Classic High-End · Stock Available)
| Model Prefix | Size | Resolution | Base Model | Suffix Definition | Key Features |
| V806 | 5.7″ | 320×240 | V806i / V806CD | i=Ethernet, CD=Color Display | Small high-end, multi-channel video input |
| V808 | 8.4″ | 800×600 | V808i / V808CDN | N=Network enhanced | Mid-size mainstream, large historical recipe storage |
| V810 | 10.4″ | 800×600 | V810i / V810iT | T=Wide Temp (-20~60°C) | Large screen monitoring, multi-bus high-speed communication |
| V812 | 12.1″ | 800×600 | V812i / V812iT | — | Extra large screen, marine certified |
| V815 | 15″ | 1024×768 | V815i / V815iT | — | Flagship large screen, redundant communication |
3.2 V9 Series (V8 Upgrade · Full Capacitive Touch)
Divided into Lite / Standard / Advanced grades; Ethernet standard, supports VPN remote access.
| Full Model | Size | Resolution | Grade | Key Features |
| V9060iSD | 5.7″ | 320×240 | Lite | Entry high-end, capacitive touch |
| V9080iSD / V9080iC | 8.4″ | 800×600 | Standard | Mid mainstream, dual LAN ports |
| V9100iSD / V9100iC | 10″ | 1024×768 | Standard | Large screen monitoring, multi-touch |
| V9120iSD / V9120iC | 12.1″ | 800×600 | Advanced | Extra large screen, wide temp anti-interference |
| V9150iSD / V9150iC | 15″ | 1024×768 | Advanced | Flagship large screen, Industry 4.0 compatible |
3.3 V10 Series (2026 Top Flagship · Quad-Core CPU)
Quad-core processor, Gigabit Ethernet, IoT connection, edge computing, full compatibility with Profinet / CC-Link bus.
| Full Model | Size | Resolution | Key Features |
| V1006 | 5.7″ | 320×240 | Quad-core entry, fast response |
| V1008 | 8.4″ | 800×600 | Quad-core mid screen, edge computing |
| V1010 | 10″ | 1024×768 | Quad-core large screen, cloud platform connection |
| V1012 | 12.1″ | 800×600 | Quad-core extra large screen, MES integration |
| V1015 | 15″ | 1024×768 | Quad-core flagship, full bus compatibility |
- X1 Series (Industrial IoT Smart HMI · Smart Factory / Cloud Platform Connection)
Windows-based system, quad-core CPU, dual Gigabit Ethernet, edge computing, cloud data upload, seamless MES connection.
| Full Model | Size | Resolution | Touch Type | Key Features |
| X1071iSD | 7″ | 1024×600 | Capacitive | Compact IoT terminal, cloud docking |
| X1101iSD | 10″ | 1280×800 | Capacitive | Mid IoT terminal, edge computing |
| X1121iSD / X1121iSRD | 12.1″ | 1280×800 | Capacitive | Large IoT terminal, MES integration |
| X1151iSD / X1151iSRD | 15.6″ | 1920×1080 | Capacitive | Flagship IoT terminal, 4K display |
- SK Series (Ultra-Low Cost Entry HMI · Standalone Small Machinery)
| Full Model | Size | Resolution | Ethernet | Key Features |
| SK070-WST | 7″ | 800×480 | No | Single RS485, no complex recipe / history log |
| SK100-WST | 10″ | 1024×768 | No | Single RS485, minimalist interface |
| SK100i-WST | 10″ | 1024×768 | Yes | Single RS485 + Ethernet, basic remote function |
Positioning: Low-cost standalone matching, non-network, one-to-one control for single-brand PLC.
- UG Series (Classic Legacy · Fully Discontinued · For Maintenance Replacement Only)
Large installed base in domestic market; 1:1 cutout & software compatible replacement with TS1000 series.
| Full Model | Size | Resolution | Power Supply | Original LAN | Recommended Replacement |
| UG221H-LR4 | 5.7″ 4:3 | 320×240 | 24VDC | No | TS1057SI |
| UG330H-VS4 | 7″ Widescreen | 800×480 | 24VDC | No | TS1070SI |
| UG330H-TS4 | 7″ 4:3 | 640×480 | 24VDC | No | TS1070SI |
| UG430H-TH1/TS4 | 10.4″ 4:3 | 800×600 | 24VDC | No | TS1100SI |
| UG530H-VH4 | 12.1″ 4:3 | 800×600 | 24VDC/AC220V | No | TS1120SI |
| UG530H-TH4 | 15″ 4:3 | 1024×768 | 24VDC/AC220V | No | TS1150SI |
- Universal Fuji HMI Suffix Naming Rule (Applicable to All Series)
| Suffix | Meaning | Application Scenario |
| S | Standard version with basic functions | Base model of all series |
| I | Built-in RJ45 Ethernet | Mandatory for VNC remote, FTP & IP camera monitoring |
| C | Capacitive touch screen | Industrial cleanroom & frequent operation |
| R | Analog resistive touch | General industrial environment, glove operation supported |
| T | Wide temperature enhanced type | Extreme temperature -20~60°C |
| W | 16:9 widescreen | Video display & multi-screen monitoring |
| Q | 4:3 standard screen | Legacy equipment upgrade & text-oriented interface |
| H | High brightness sunlight readable | Outdoor equipment without shading |
| L | Low brightness energy saving | Long-time running & low power demand |
| D | Enhanced data storage | Mass recipe & historical data logging |
| N | Enhanced network function | Multi-protocol network & VPN support |
- Full Series Upgrade & Replacement Guide (For Maintenance & Retrofit)
- All old UG models → Direct drop-in replacement by TS1000 SI Series (same cutout, same wiring, software compatible)
- Legacy V8 high-end → Upgrade to V9 / V10 Series (capacitive touch, higher performance, enhanced network)
- Basic SK standalone → Budget upgrade to TS1070S (3 COM ports, richer functions)
- Remote monitoring required → Choose models with suffix I (TS1070SI / V9xxi / V10xxi / X1xxi)
- Smart factory digital transformation → Choose X1 Series (edge computing, cloud platform & MES integration)
- Quick Selection Guide
| Application Scenario | Recommended Series | Core Model | Key Selection Reason |
| Small standalone machine | SK / TS1000 S | SK070-WST / TS1070S | Low cost, local control |
| Small & medium production line | TS1000 SI | TS1070SI / TS1100SI | 3 COM ports, remote monitoring |
| Large automation system | V9 / V10 | V9100iSD / V1010 | High-speed bus & multi-HMI linkage |
| Smart digital factory | X1 | X1121iSD / X1151iSD | Edge computing & cloud connection |
| Outdoor / wide temperature environment | V9 T-version / TS1000 T | V9100iSD-T / TS1070SI-T | -20~60°C wide temperature resistance |
| Clean workshop | TS1000 C / V9 C | TS1070CI / V9100iC | Capacitive touch, easy cleaning |
