Quick Overview of Core Specifications
Product Type: Standard Managed Industrial Ethernet Switch of Schneider Modicon series
Manufacturer: Schneider Electric, headquartered in France
Primary Production Location: Germany (site for final critical assembly processes)
Product Positioning: Industrial automation networking device as replacement for legacy TCSESM043F2CU0
Port Configuration: 4×RJ45 Copper Ports (10/100Mbps) + 2×SC Multi-mode Fiber Ports (100Mbps), DIN rail mountable
- Model Code Definition Table
| Code Segment | Code | Definition |
| MCS | MCS | Modicon Connectivity System, Schneider Modicon networking product line |
| ESM | ESM | Ethernet Standard Managed, standard managed Ethernet switch |
| 63 | 63 | Port layout: total 6 ports consisting of two types (4 copper + 2 fiber) |
| F2 | F2 | Fiber interface: 2 multi-mode fiber ports (100BASE-FX) |
| CU | CU | Copper interface: RJ45 copper ports (10/100BASE-TX), standard configuration |
| 0 | 0 | Revision: standard base version |
III. Core Specification List
| Category | Technical Parameter | Remarks |
| Port Configuration | ||
| Total Ports | 6 | 4 copper + 2 fiber |
| Copper Ports | 4×RJ45 (10/100BASE-TX) | STP cable, CAT5E or higher grade |
| Fiber Ports | 2×SC Duplex (100BASE-FX) | Multi-mode fiber; transmission distance: 4km / 5km |
| Performance Specs | ||
| Switching Capacity | 1.2Gbps | Non-blocking wire-speed forwarding |
| Management Features | Standard Managed | Port Security, IP/MAC Binding, RADIUS Authentication supported |
| Redundancy Protocol | MRP Ring supported | Ring recovery time <20ms |
| Power & Environmental Data | ||
| Operating Voltage | 9.6–32VDC | Wide-range input for industrial power supply |
| Power Consumption | 7W | Low-power design |
| Operating Temp. | 0°C ~ +60°C | Designed for harsh industrial ambient conditions |
| Ingress Protection | IP30 | Dustproof, suitable for cabinet installation |
| Mounting | Standard 35mm DIN rail | Compliant with EN 50022 |
| Certifications | CE, UL, RCM, EAC, UKCA, DNV | Conforms to UL 61010 & EN/IEC 61131 |
- Full Series Cross Reference (MCS ESM 6-Port Family)
| Part Number | Port Layout | Fiber Type | Copper Interface | Special Feature |
| MCSESM063F2CU0 | 4Cu+2Fiber | Multi-mode (SC) | Standard RJ45 | Basic Managed |
| MCSESM063F2CS0 | 4Cu+2Fiber | Multi-mode (SC) | Standard RJ45 | Enhanced Security Function |
| MCSESM063F2LU0 | 4Cu+2Fiber | Single-mode (SC) | Standard RJ45 | Long-distance Transmission |
| MCSESM063F2LS0 | 4Cu+2Fiber | Single-mode (SC) | Standard RJ45 | Single-mode + Security Option |
- Application Fields & Project Cases
- Applicable Scenarios
Factory Automation: PLC-HMI interconnection, sensor data collection, production line equipment networking
Process Control: DCS network for chemical, petrochemical and water treatment industries
Smart Manufacturing: Industry 4.0 IIoT deployment with OPC UA protocol support
Critical Infrastructure: Backbone networking for power, railway transit and building automation
Harsh Working Conditions: Replaces commercial switches in dusty, vibratory and temperature-fluctuating industrial sites
- Typical Application Case
Case: Auto Component Production Line Networking
Field Devices: 20 Robots, 10 Sensors, 5 HMIs
Solution: 3 units of MCSESM063F2CU0 forming MRP redundant ring to connect field equipment to central PLC
Advantages: Industrial-grade reliability, high EMC immunity, fast ring recovery, stable under workshop vibration
- Not Recommended Applications
Ambient temperature exceeding >60°C or below <0°C (Wide-temperature variant required)
Heavy corrosive gas environment (Sealed industrial switch needed)
Data rate over 100Mbps (Gigabit model such as MCSESM203 series required)
- Air Shipment Compliance & Certifications
Shipping Classification: Non-dangerous goods without built-in lithium battery, compliant with IATA DGR
CE Certificate: Complies with EN 60947-4-1, Cert No.: CE 0123
UL Certificate: Complies with UL 508, File No.: E249461
RoHS Compliance: Meets Directive 2011/65/EU, free of restricted hazardous substances
VII. Order Information
Order Code: MCSESM063F2CU0
Minimum Pack Quantity: 1 unit per carton
Warranty Period: 12 months
Recommended Accessories: SC multi-mode fiber patch cord, DIN rail mounting clip, DC power adapter
Full Detailed Technical Datasheet for Schneider MCSESM063F2CU0 Industrial Switch
- Core Summary
Model: MCSESM063F2CU0
Product Line: Schneider Modicon MCS (Modicon Connectivity System) Standard Managed Industrial Ethernet Switch
Manufacturer: Schneider Electric (HQ in France, major production in Germany)
Port Configuration: 4×10/100M RJ45 + 2×100M SC Multi-mode Fiber, total 6 ports
Product Position: Industrial automation networking replacement for obsolete TCSESM043F2CU0
Mounting: Standard 35mm DIN rail per EN 50022
- Complete Model Code Explanation
| Code Segment | Code | Full Description |
| MCS | MCS | Modicon Connectivity System, dedicated for industrial automation networking |
| ESM | ESM | Ethernet Standard Managed, basic full-function managed switch |
| 63 | 63 | Total 6 ports in two categories: 4 copper + 2 fiber |
| F2 | F2 | Two multi-mode 100BASE-FX ports with SC duplex connector |
| CU | CU | RJ45 copper 10/100BASE-TX, STP CAT5E & above cabling |
| 0 | 0 | Standard base revision without extra customized options |
III. Itemized Detailed Technical Specifications
- Physical Layer & Port Parameters
| Item | Rating | Specification |
| Copper Ports | ||
| Quantity | 4 | Shielded RJ45 socket |
| Speed | 10/100Mbps auto-negotiation | Full/Half duplex auto-sensing |
| Standard | IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX | Auto MDI/MDI-X crossover |
| Cabling | STP CAT5E or higher | Max. 100m transmission |
| Port Surge Protection | Built-in | Compliant with IEC61000-4-5 for industrial EMC |
| Fiber Ports | ||
| Quantity | 2 | SC Duplex multi-mode fiber receptacle |
| Rate | Fixed 100Mbps | Full-duplex per 100BASE-FX |
| Operating Wavelength | 850nm | Standard for multi-mode fiber |
| Transmission Distance | 4km(50/125μm),5km(62.5/125μm) | IEEE802.3u compliant |
| Fiber Spec | MMF 62.5/125μm & 50/125μm | Compatible with SC/ST connectors |
- Switching & Network Performance
| Item | Value | Details |
| Switching Capacity | 1.2Gbps | Store-and-forward non-blocking wire-speed |
| Packet Forwarding Rate | 0.89Mpps | Calculated under 64-byte frame for full wire-speed |
| Port Buffer | 16KB | Independent buffer per port for traffic optimization |
| MAC Address Table | 8K entries | Auto-learning & aging, static MAC configurable |
| VLAN Capacity | Up to 64 VLAN | IEEE802.1Q tagged & port-based VLAN |
| Redundancy | MRP | Recovery <20ms for high network availability |
| QoS | 4 priority queues | IEEE802.1p & DSCP based traffic prioritization |
| Supported Protocols | EtherNet/IP, TCP/IP, UDP, ICMP, ARP, DHCP, DNS, SNMPv1/v2c/v3, HTTP/HTTPS, Telnet/SSH, LLDP, SNTP, RSTP, MRP | Full industrial protocol compatibility |
- Electrical & Power Specifications
| Item | Parameter | Description |
| Input Voltage | 9.6~32VDC (Nominal 12/24VDC) | Wide-range industrial DC input |
| Power Terminal | 6-pin pluggable terminal | Reverse polarity protection for easy wiring |
| Max Power Draw | 7W | Low energy consumption |
| Overcurrent Protection | Built-in short-circuit safeguard | Prevents damage from abnormal power supply |
| Alarm Relay Output | 1 Form-C dry contact (1A@250VAC /1A@30VDC) | Alarms for power fail, link down, device fault, over-temp & MRP ring failure |
- Mechanical & Physical Dimension
| Item | Spec | Remark |
| Dimension(W×D×H) | 57mm×104mm×138mm (142.8mm in partial datasheet) | Compact cabinet-saving design |
| Net Weight | ~0.4kg | Lightweight for easy installation |
| Mount | 35mm DIN rail EN50022 | Snap-on fast installation |
| Enclosure Rating | IP30 | Dust-proof for indoor cabinet |
| Housing | Metal casing | Improved heat dissipation & EMC resistance |
| LED Indicators | Power, Link/Activity, Speed, Fault, MRP Ring | Real-time operating status visualization |
- Environmental & Reliability Index
| Item | Rating | Standard |
| Operating Temp. | 0°C ~ +60°C | Tolerates factory ambient fluctuation |
| Storage Temp. | -40°C ~ +85°C | Suitable for harsh logistics & storage |
| Relative Humidity | 10%~95% non-condensing | High-humidity workshop applicable |
| Vibration Resistance | 5–150Hz,1g | IEC60068-2-6 |
| Shock Resistance | 15g,11ms | IEC60068-2-27 against transport impact |
| EMC | EN61000-6-2(Immunity), EN61000-6-4(Emission) | Robust anti-interference for industrial automation |
| MTBF | >100,000 Hours | Long service life to reduce maintenance cost |
- Management & Security Functions
| Category | Feature List | |
| Management Access | WebGUI, Telnet, SSH, SNMPv1/v2c/v3, Modbus TCP | Multi-channel flexible configuration |
| Security Features | Port Security, IP/MAC Binding, RADIUS, HTTPS/SSH Encryption, ACL | Unauthorized access prevention |
| Diagnostics | Port statistics, error counter, cable test, internal temperature monitoring | Fast troubleshooting |
| Firmware Upgrade | Remote upgrade via Web or TFTP | Convenient function expansion & bug fix |
| Configuration Management | Config backup/restore, auto-save | Simplify site maintenance |
- Compliance & Certification
| Certificate | Standard | Note |
| Safety Cert | CE, UL, CSA, RCM, EAC, UKCA, DNV | UL61010, EN/IEC61131, EN/IEC62368-1 |
| Ethernet Standard | IEEE802.3/3u/1Q/1p/3ad | Global mainstream Ethernet compliance |
| Industrial Standard | IEC61000-6-2, IEC61000-6-4, IEC61850-3 | Approved for power & rail transit |
| Environmental | RoHS 2011/65/EU | Lead-free eco-friendly construction |
| Logistics | Non-hazardous per IATA DGR | Safe for global air freight |
- Industry Application Matching
- Recommended Applications
Automated Production Line: PLC-HMI communication, sensor & robot control networking
Process Industries: DCS backbone for chemical, oil & water treatment
Smart Factory: IIoT & Industry4.0 deployment supporting OPC UA
Infrastructure: Power plant, railway & building automation core network
Rugged Sites: Replace consumer-grade switches in dusty, vibratory workshops
- Non-recommended Scenarios
Operating temperature >60°C or <0°C (Wide-temperature model required)
Heavy corrosive vapor environment (Hermetically sealed switch required)
Requirement over 100Mbps throughput (Gigabit MCSESM203 series needed)
Ultra-long fiber transmission (Single-mode variant MCSESM063F2LU0 recommended)
- Ordering & Spare Parts Info
| Item | Details |
| Part No. | MCSESM063F2CU0 |
| Minimum Pack | 1pc |
| Warranty | 12 Months |
| Recommended Accessories | SC MM fiber cord (62.5/125μm &50/125μm), DIN rail clip, 12/24VDC power adapter |
| Replacement Model | Legacy TCSESM043F2CU0; upgraded 8-port MCSESM083F2CU0 |
- Selection Summary Tips
- Core Spec: 4Cu+2Multi-mode Fiber, standard managed, 1.2Gbps switching, MRP ring redundancy
- Power: 9.6~32VDC wide input universally matching industrial field power supply
- Mount: Standard 35mm DIN rail, IP30 metal casing with superior heat dissipation
- Security: Port lock, IP/MAC bind & RADIUS; MTBF>100,000h for stable operation
- Target Industry: General manufacturing, water treatment, power generation & rail automation
