Общие решения для индивидуальных решений Schneider Electrical

1. Preliminary Requirements & Compliance Scope
2. Define Core Parameters

Власть: System voltage (230/400V AC single-phase/three-phase), total capacity, number of circuits, branch current, short-circuit breaking capacity (Icu/Ics);

Среда: Indoor/outdoor, IP-рейтинг (IP30 for indoor, IP54 for outdoor splash-proof, IP66 for corrosion-resistant), material (cold-rolled steel sheet / 304 / 316 stainless steel), метод установки (wall-mounted / floor-standing / flush-mounted);

Функции: Измерение (multi-function electricity meter), surge protection (СПД), dual-power ATS switching, удаленный мониторинг (Modbus/485), fire protection interlock.

2. Mandatory Standards: МЭК 61439, ГБ 7251.1, low-voltage switchgear assembly standards; components must be original Schneider (например, MCCB NSX/XT, MCB EA9/A9, ATS WATSN, и т. д.); equipped with CCC and CE certifications; the manufacturer must hold low-voltage assembly qualification.
3. Customization Process Steps
4. Requirement communication → Quotation & proposal (including single-line/control diagrams, BOM list);
5. Contract & drawing confirmation → Enclosure fabrication (drilling, bending, spraying, protection treatment);
6. Component assembly & проводка (separation of strong and weak current, clear wire marking);
7. Factory testing (withstand voltage, изоляция, on/off operation, protection setting, IP test);
8. On-site installation, ввод в эксплуатацию, and delivery of as-built documents (drawings, certificates, test reports).

III. Core Selection & Конфигурация

1. Корпус & Защита

Размеры: Common wall-mounted enclosures 400×500×200, 600×800×250; floor-standing cabinets XL21, BlokSeT, PanelSeT;

Coating: RAL7035 (telecommunication gray); outdoor models with sealing gaskets and rain hoods; 304 stainless steel for humid environments, 316 for coastal corrosive environments.

2. Component Combination (Mainstream Schneider Models)

3. Control Circuits & Дополнительные функции: Control buttons, индикаторные лампы, реле, PLC modules; remote monitoring connectable to Schneider EcoStruxure system.
4. Key Quality Control & Acceptance
5. Factory Testing: Power frequency withstand voltage 2500V/1min without breakdown, insulation resistance ≥1000MΩ, temperature rise test, protection operation verification;
6. On-site Acceptance: Consistency check between drawings and physical product, IP sealing inspection, energized load test, protection setting review;
7. Document Delivery: Electrical schematic diagrams, layout drawings, component certificates, test reports, operation manuals.
8. Examples of Common Customized Solutions

General Lighting Panel: Wall-mounted IP30, 1P+N main breaker + 12-way 1P EA9 MCB + Vigi earth leakage;

Outdoor Power Panel: 304 stainless steel IP54, 3P 100A XT MCCB main breaker, 3-way 3P 32A branches, equipped with SPD and ATS;

Data Center Dual Power Panel: BlokSeT enclosure, WATSN ATS switching, UPS interlock, удаленный мониторинг.

1. Quotation, Время выполнения & Avoidance Tips
2. Price Factors: Component configuration, enclosure material and dimensions, functional complexity, certification requirements, order quantity;
3. Время выполнения: 7–10 days for standard wall-mounted panels, 2–4 weeks for complex floor-standing cabinets;
4. Avoidance Tips: Original Schneider components must be confirmed in writing; specify IP rating, test items, and warranty period (generally 1–2 years) in the contract; avoid assembly from unqualified small manufacturers to prevent safety hazards.

VII. Supplier Selection

Prioritize Schneider Authorized Panel Builders (verifiable via official website certification);

Require provision of: factory qualification certificates, samples, factory testing procedures, after-sales response mechanism.
