Relé Chint JZX-22F/3Z

El Relé Chint JZX-22F/3Z is a small electromagnetic relay specifically designed for industrial control applications, featuring high reliability and broad applicability.

Parámetros técnicos básicos
Sistema de contacto

Configuración de contacto: 3z (three sets of changeover contacts), supporting a resistive load of 5A (220VAC/28VDC), suitable for multi-circuit control scenarios.

Material and Service Life: Silver alloy contacts ensure low contact resistance (≤100mΩ), con un eléctrico service life of up to 100,000 operations and a mechanical service life of up to 10,000,000 operaciones.

Insulation Performance: The withstand voltage between the coil and contacts is 1500VAC, and the withstand voltage between open contacts is 500VAC, meeting industrial-grade safety standards.

Características de la bobina

Rango de voltaje: Comprehensive specifications for DC (5-220V) and AC (6-380V). Power consumption is 0.9W (para CC) or 1.8VA (para aire acondicionado). The pull-in voltage is ≤75% of the rated voltage (para CC) or ≤80% of the rated voltage (para aire acondicionado).

Velocidad de respuesta: The operate time is ≤25ms, and the release time is ≤25ms, making it suitable for high-frequency and rapid switching requirements.

Adaptabilidad ambiental

Temperatura de funcionamiento: -25℃ to +55℃, with a humidity of ≤95% (a 25 ℃). It can work stably in high-dust or vibrating environments (double amplitude: 1.0milímetros, frecuencia: 10-55Hz).

Métodos de montaje: Supports plug-in, soldadura de PCB, and DIN rail mounting. Matching socket models include CZY11A-E (dimensiones: 72×30×31mm).

Campos de aplicación
Automatización Industrial

– Used for motor control and the start-stop of production line equipment, capable of switching multiple signal circuits simultaneously.

– Aplicación típica: Used as an intermediate relay in PLC control systems to achieve logical signal amplification and isolation.

Energy and Power

– Suitable for protection circuits in low-voltage distribution cabinets, capable of monitoring current/voltage abnormalities and triggering circuit breaks.

– Supports high-voltage scenarios of 240VAC (model compatibility needs to be confirmed).

Smart Buildings

– Controls the zoned power supply of lighting and air conditioning systems, and achieves automated energy conservation in combination with sensors.

III. Market Adaptability

Cumplimiento de la certificación

– Certificado por UL, CE, and CQC, complying with North American and EU safety standards, and can be directly used in the U.S. mercado.

Soluciones alternativas

– Compatible with similar models such as MY3(norte) and HH53P(-l), with consistent pin definitions and mounting dimensions, facilitating equipment upgrades.

Adquisiciones Internacionales

Precio Nacional: Aproximadamente 10-20 RMB por unidad (including value-added tax). Para compras al por mayor, orders can be placed via WhatsApp: 0086-13811255435.

A NOSOTROS. Canales: It is recommended to contact Chint North America via WhatsApp: 0086-13811255435 to obtain authorized distributor information, or purchase through the WhatsApp platform: 0086-13811255435 (stock availability needs to be confirmed).

Notas: If a 120VAC model is required, it must be customized through official channels or used with a step-down module to avoid damage caused by direct connection.

Recomendaciones de selección e instalación.
Identificación del modelo

– Example of a complete model: JZX-22F(D)/3Z AC220V, dónde “D” indicates with a status indicator light, “3z” represents three sets of contacts, y “CA 220 V.” is the coil voltage.

Especificaciones de cableado

– Ensure tight contact for plug-in terminals. When soldering to PCB, pay attention to the pin polarity to avoid poor contact caused by cold soldering.

– It is recommended to use the matching CZY11A-E socket, whose screw-type terminals support quick wiring and feature an anti-misinsertion design.

Protección ambiental

– In humid environments, a sealed type (such as a model with a cover) debe ser seleccionado. Regularly check the contact oxidation status, and use contact cleaner for maintenance if necessary.
