| Pièce du modèle | Signification | Explication détaillée |
| VFD | Delta Inverter Identifier | Abbreviation for Variable Frequency Drive, the universal prefix for Delta’s industrial automation inverters. |
| 55 | Puissance moteur applicable | For 5.5kW (7.5HP) moteurs; this is the rated output power of the drive. |
| C | Code de série | C2000/C2000+ Series – Delta high-performance general-purpose vector inverter, supporting induction motors and permanent magnet synchronous motors. |
| 43 | Classe de tension & Phase | 4 = 3-phase 400V class (380~480V); 3 = 3-phase input (vs. 1 pour monophasé). |
| UN | Mode de contrôle & Caractéristiques | Supports Vector Control (FOC), Contrôle du couple (TRQ), high-performance algorithm, 200% starting torque at 0.5Hz. |
| -21 | Version & Configuration | Version standard: built-in braking unit (selected power ratings), pas de filtre CEM intégré (external available), compliant with international standards. |
- Spécifications techniques de base (Officiel 2026 Data)
| Catégorie | Article | Valeur | Remarques |
| Basic Specs | Puissance nominale | 5.5kW (7.5HP) | For 5.5kW 3-phase induction motors |
| Tension d'entrée | 3-phase 380~480V (+10%/-20%) | 47~63Hz, large plage de tension | |
| Courant de sortie nominal | 12UN (robuste) / 10.8UN (light duty) | Continuous operation in heavy-duty mode | |
| Plage de fréquence de sortie | 0.1~600Hz | For both low‑ and high‑speed applications | |
| Performances de contrôle | Mode de contrôle | Sensorless Vector, Closed-loop Vector, Contrôle V/F | Switchable closed/open loop |
| Couple de démarrage | 200% rated torque at 0.5Hz | Ideal for heavy starting loads | |
| Capacité de surcharge | 150% for 60s; 200% pendant 3s | Pour les charges de choc | |
| Speed Accuracy | ±0,5% (open-loop) / ±0.02% (closed-loop) | High precision speed control | |
| Torque Response Time | ≤10ms | Fast dynamic response | |
| Hardware | Degré de protection | IP20 (cabinet mount) | Finger‑safe; clean environment recommended |
| Refroidissement | Forced air (removable fan) | Entretien facile, longue durée de vie | |
| Built-in Functions | Braking unit (≤7,5 kW), API (5,000 mesures) | Haute intégration, fewer external parts | |
| Communication | RS-485 (Modbus RTU) standard | PROFINET/EtherNet/IP/CANopen optional | |
| Environnement | Température de fonctionnement | -10~40°C (derate 40~50°C) | Déclasser 1% per °C above 40°C |
| Température de stockage | -20~60°C | Avoid moisture & gaz corrosif | |
| Humidité | 5~95 % (non‑condensing) | Suitable for industrial environments |
III. Fonctionnalités principales & Avantages
3.1 High‑Performance Control
Contrôle vectoriel: Precise independent torque & speed control for complex loads.
API intégré: 5,000-step logic programming for simple automation, reducing external PLC dependency.
Auto energy saving: Dynamically adjusts output voltage; saves 20~50% at light load.
Motor auto-tuning: Completes matching in <10s, simplifies commissioning.
3.2 Conception haute fiabilité
Modular structure: Hot-swappable keypad, expandable I/O and communication cards for easy maintenance.
Protection complète: Surintensité, surtension, sous-tension, surchauffer, surcharge, perte de phase, défaut à la terre, etc..
Safe stop: Supports STO (Coupure sûre du couple), SIL 2 agréé.
Wide grid tolerance: Withstands ±15% voltage fluctuation for harsh grids.
3.3 Communication flexible & Expansion
Standard RS-485 Modbus RTU for multi-drive network control.
Optional modules: PROFINET, EtherNet/IP, PROFIBUS-DP, CANopen.
Compatible with Siemens, Mitsubishi, Rockwell PLCs via standard telegrams and process objects.
Surveillance à distance & diagnostics via Delta DIAStudio or TIA Portal.
- Applications & Conseils de sélection
4.1 Applications recommandées
| Industrie | Applications typiques | Caractéristiques |
| General Machinery | Pompes, les fans, compresseurs, mélangeurs | Économie d'énergie, stable operation, longer equipment life |
| Manutention des matériaux | Convoyeurs, grues, palans, machines d'emballage | High precision speed control, heavy start, quick stop |
| Metal Processing | Tours, milling, grinding, punching machines | High response, positionnement précis, contrôle du couple |
| Textile & Dyeing | Textile machines, dyeing machines, stenter frames | Constant tension, synchronous operation, wide speed range |
| Plastique & Rubber | Injection molding, extrusion, blow molding | Significant energy saving (20~60%), stable pressure control |
4.2 Points clés de la sélection
- Correspondance de puissance: Use VFD055C43A-21 for 5.5kW motors; avoid undersizing.
- Type de charge:
Constant torque (convoyeurs, mélangeurs): use heavy-duty mode (12UN).
Variable torque (les fans, pompes): light-duty mode (10.8UN) for better efficiency.
- Exigences de contrôle:
Positionnement de haute précision: use encoder (PG card) vecteur en boucle fermée.
Network control: add communication module (par ex., PROFINET).
- Environnement:
Haute température: extra cooling or derating required.
Dusty environment: dust cover + regular fan cleaning.
- Modèles de remplacement & Upgrade Path
5.3 Suggestions de mise à niveau
- Basic upgrade: VFD‑M/GD10 → C2000+ for better precision & fonctions.
- Communication upgrade: Add PROFINET card for Industry 4.0 connectivity.
- System upgrade: Combine with Delta PLC (DVP series) & HMI for full automation solution.
Buying Notes
- Confirm suffix -21 (version standard), avoid old versions (par ex., -00).
- Verify power & actuel: 5.5kW → 12A rated.
- Buy from authorized Delta channels for genuine product & service.
- Order accessories as needed: communication card, clavier, braking resistor.
VII. Installation & Entretien
7.1 Règles d'installation
- Montage: Wall/cabinet mount, installation verticale; ≥150mm clearance top & bottom for ventilation.
- Câblage:
Separate power & control cables to avoid interference.
Shielded cable for signals, single‑end grounding.
Braking resistor matched to power (≤7.5kW internal; external ≈100Ω/500W).
- Mise à la terre: Ground resistance ≤4Ω for safety & noise immunity.
Delta VFD055C43A-21 is a high‑performance 5.5kW vector inverter from the C2000+ series, featuring high precision, fiabilité, and expandability for diverse industrial applications. With built-in PLC, wide voltage tolerance, and complete protection, it is an excellent choice for general industrial drive solutions. Select based on motor power, type de charge, control requirements, and environment for optimal performance and cost-effectiveness.
Complete Replacement Guide for Delta VFD055C43A-21
- Delta Internal Replacements (Série C2000+, Seamless Compatibility)
1.1 Direct Same‑Series Replacements
| Code d'erreur | Cause | Solution |
| OC | Surintensité | Check motor short, surcharge, acceleration time |
| VO | Surtension | Vérifier la tension secteur, temps de décélération, braking resistor |
| UV | Sous-tension | Check input phase, tension, cable size |
| OH | Surchauffer | Check fan, ventilation, température ambiante |
| PH | Phase loss | Check input/output wiring, motor winding |
1.2 Near‑Power Replacements
| Modèle | Pouvoir | Courant nominal | Principales fonctionnalités | Application |
| VFD055C43A-21 (Original) | 5.5kW | 12UN / 10.8UN | C2000+, vector, built-in brake, RS-485 | Industrie générale |
| VFD055C43A-21 (Mise à niveau) | 5.5kW | 12UN | Better cooling, 10,000-step PLC, more protocols | Nouveaux projets |
| VFD055CH43A-21 | 5.5kW | 12UN | CH2000, fan/pump specialized | Ventilateurs, pompes |
| VFD055CP43B-21 | 5.5kW | 12UN | CP2000, hoist/crane dedicated | Grues, palans |
- Global Brand Replacements (5.5kW / 400V Vector)
2.1 Premium Brands
| Marque | Modèle | Série | Contrôle | Avantage |
| Siemens | 6SL3210-1KE21-3UF1 (G120C PN) | SINAMICS G120C | Vector/V/F | PROFINET, Filtre CEM |
| Mitsubishi | FR-A840-00720-2-60 | FREQROL A840 | Vector | High response, API intégré |
| Yaskawa | CIMR-AB4A0018FBA | A1000 | Vector | Low noise, écurie |
| Schneider | ATV320U75N4 | Altivar 320 | Vector/V/F | Compact, multi-protocol |
| ABB | ACS550-01-012A-4 | ACS550 | DTC | High torque accuracy |
2.2 Cost‑Effective Brands
| Marque | Modèle | Série | Contrôle | Avantage |
| Innovation | MD280NT5.5GB | MD280 | Vector | PROFINET supported |
| Veichi | AC70-T3-055G | AC70 | Vector | Complet, faible coût |
| INVT | CHF100A-5R5G/7R5P-4 | CHF100A | Vector | Built-in brake un |
III. Critical Replacement Rules (Must Follow)
- Pouvoir & actuel: Rated power ≥5.5kW, current ≥12A (robuste).
- Tension: 400Classe V (380~480V) seulement; do NOT use 200V directly.
- Contrôle: Prefer vector control for matching dynamics.
- Surcharge: At least 150% for 60s.
- Communication: RS-485 standard; PROFINET/EtherNet/IP optional.
Mechanical Compatibility
Dimensions: ~90×180×150mm – use same or smaller size.
Refroidissement: Forced air – keep airflow direction.
Unité de freinage: Internal for ≤7.5kW; match external if needed.
Clavier: Use Delta standard keypad or compatible.
Best Replacement by Application
General machinery: VFD055C43A-21 upgraded or Siemens G120C PN.
Ventilateurs & pompes: VFD055CH43A-21 or Schneider ATV320U75N4.
Cranes/hoists: VFD055CP43B-21 or Mitsubishi FR-A840.
Budget projects: Inovance MD280NT5.5GB or Veichi AC70-T3-055G.
- Upgrade Paths
4.1 Delta Internal Upgrade
- C2000 → C2000+ (performance & function improvement).
- Add PROFINET module (VFD-CM-PN01) for industrial networking.
- Pair with Delta PLC + HMI for full automation system.
4.2 Cross‑Brand Upgrade
- Communication: RS-485 → PROFINET / EtherNet/IP.
- Contrôle: Open-loop vector → closed-loop vector with encoder.
- Sécurité: Choose models with STO (SIL 2).
The Delta VFD055C43A-21 has a wide range of replacements.
Same‑brand (C2000+ upgraded) offers seamless compatibility.
Cross‑brand (Siemens G120C PN, Mitsubishi FR-A840) provides higher performance.
Always follow core parameter matching to ensure stable, reliable replacement without performance loss or equipment damage.
