Yaskawa CIMR-AB4A0018FBA Inverter

Application Summary of CIMR‑AB4A0018FBA (A1000, HD 5.5kW / ND 7.5kW, 380V) Onduleur

Unit Specification: Heavy-Duty(HD) 5.5kW, Normal-Duty(ND) 7.5kW, PG/PG-less vector control, high starting torque. Mainly applied to two categories: high-precision variable speed regulation & constant-torque loads, and energy saving for fans & pompes.

1. Définition du code modèle

2. Spécifications techniques de base

3. Liste complète des séries (400Classe V, BA with Keypad)

Note: Full series covers 0.4kW~355kW; above is frequently used models only

4. Cross Model & Guide de remplacement multi-marques

4.1 Internal Yaskawa Model Upgrade

4.2 Comparaison équivalente entre marques

5. Environnement d'application & Cas industriels

5.1 Scénarios d'application recommandés

5.2 Not Recommended Installation Conditions

Explosif & flammable atmosphere (explosion-proof inverter required instead)

Severe EMI environment (external EMC filter mandatory)

Altitude over 1000m with no power derating (consult manufacturer for derating specs)

Locations with vibration exceeding 0.6G (special mounting structure required)

5.3 Practical Retrofit Cases

Case1: Energy Saving Retrofit on Food Packaging Conveyor

Charger: Biscuit packaging conveyor system

Before upgrade: Direct-on-line startup with heavy mechanical impact & high power waste

After upgrade: CIMR-AB4A0018FBA realizes soft start/stop & speed auto-adjustment following production cycle

Résultat: 30% longer equipment service life, 35% power reduction, 5% higher finished product rate

Case2: Central Air-conditioning Chilled Water Pump Retrofit

Charger:5.5kW cooling circulation pump

Before upgrade: Constant-speed running with flow throttled by valve leading to huge energy loss

After upgrade: Inverter adjusts pump speed automatically based on return water temperature

Résultat: Approx.28,000 kWh annual power saving, payback period:6 mois

6. Conformité des expéditions aériennes & Certification Manual

6.1 Air Transport Compliance Judgment

Built-in battery: No lithium cell equipped, only passive capacitors installed; excluded from UN3480/UN3481 lithium battery transport regulation

Shipping classification: General electrical goods, no UN38.3 test report or air identification certificate needed

Emballage: Original factory carton or ISTA-certified packaging with anti-static & moisture-proof protection

6.2 Key Product Certifications

7. Conseils de sélection & Règles de référence rapide

7.1 A1000 Selection Mnemonic

AB4A for three-phase 400V, capacity code links output ampere,

switch HD/ND duty freely, BA=with keypad, AA=without spare,

robust vector performance, fits most general industry drives.

7.2 Quick Calculation Rules

400V model prefix: CIMR-AB4A (with keypad) / CIMR-AA4A (keypad-less)

Environ. ND kW ≈ Capacity Code ×0.1; Environ. HD kW ≈ Capacity Code ×0.06

Code 0018 = HD5.5kW / ND7.5kW, rated output 17.5A

Detailed Field Application Breakdown

7. General Fluid Energy Saving (Ventilateurs & Pompes, prefer ND7.5kW rating)
8. HVAC Central Air Conditioning

Chilled water pumps, ventilateurs de tour de refroidissement, AHU supply fans

Working principle: Variable speed regulated by water temperature & differential pressure instead of valve throttling; 30~50% power saved

Application: Single pump ≤7.5kW for shopping malls, immeubles de bureaux & factory central air systems

2. Approvisionnement en eau & Drainage System

Plant service water pumps, booster pumps for secondary water supply, sewage & rainwater lift pumps

Constant pressure control: Closed-loop regulation with pressure transducer; low-speed running at night to cut idle loss

Suitable for residential pump rooms & small factory wastewater treatment stations

3. Boiler Auxiliary Equipment

Induced draft fan, forced draft fan & boiler feed pump with auto speed adjustment by furnace negative pressure.

5. Conveyor & Bulk Material Handling (Constant-torque, select HD5.5kW)
6. Light Industry Assembly Conveyors

Food processing lines, carton packing conveyors, bottle filling & small roller bed lines

Avantage: Soft start/stop prevents belt rupture; multi-speed switching matches production tact time

2. Small Mining & Aggregate Feeding Equipment

Light-duty belt feeders, spiral screw conveyors for grain, powder and sand transportation

Fonctionnalité: 150% low-frequency starting torque suits heavy inrush load at startup

3. Warehouse Sorting Equipment

Small sorting conveyors and pallet roller conveyors.

III. CNC & Machining Tools (High-precision speed control via vector drive)

1. Spindle drive for conventional lathe, bench milling & surface grinder: 0~400Hz wide frequency range enables stepless speed change to replace traditional gearbox and improve surface finish; ±0.2% speed accuracy for PG-less vector mode
2. Bench grinders, polishing machines & small wire drawing machines.
3. Machines textiles (Primary constant tension control application)

Twisting frames, small looms, cone winding machines, fabric setting pull rollers

Demande: Low-speed high torque & stable tension to avoid yarn breakage; A1000 vector drive perfectly matches 5.5kW rated load

1. Light Lifting & Hoisting Applications

Only for light-duty lifting; heavy crane uses H1000 series instead

Small cargo lifting platforms, fixed compact freight elevators, miniature electric hoists

Avantage: Smooth start/stop prevents load slipping with zero-speed holding torque to eliminate mechanical impact

1. Rubber, Plastique & Machines d'emballage
2. Auxiliary feed screw for plastic extruder & small pelletizer;
3. Horizontal flow wrappers, machines à sceller & film winding machines with constant winding tension control.

VII. Grain & Feed Processing Equipment

Auxiliary drives for grinders, feed mixers, grain elevators and separator fans.

Prohibited & Unadvisable Installation Conditions

1. Explosion-prone chemical workshops: Standard IP20 design without explosion-proof certification; EX-type inverter required;
2. Altitude over 1000m: Minimum 10% power derating mandatory otherwise overheat alarm occurs;
3. Equipment with severe cyclic shock & vibration (impact crushers, forging hammers): Loose terminals and PCB damage caused by continuous vibration;
4. Direct driving of large shock loads (heavy gantry cranes, large air compressors): Insufficient rated power, select high-power H1000 series;
5. Outdoor open-air mounting without control cabinet: No ingress protection; rain & dust damage internal power modules.

Verified On-site Application Cases

1. Cas 1: ND rated 7.5kW Chilled Water Pump

Injection molding plant pump retrofit: Original valve throttling at fixed speed; variable frequency control by coolant temperature saves around 26,000 kWh yearly.

2. Cas 2: HD rated 5.5kW Packaging Line Conveyor

Biscuit production main transport with frequent start-stop; full-load startup at 0.5Hz without slip; equipment failure rate cut by 70%.

Quick Selection Tip

Ventilateurs & Water Pumps → apply ND 7.5kW rating

Convoyeurs, Machines-outils, Textile Equipment → apply HD 5.5kW rating
