Schneider NSYCVF165M230PF Filter Fan

Model Code Definition

Breakdown of NSYCVF165M230PF

Code Segment	Meaning	Description
NSY	Product series prefix	General mark for Schneider ClimaSys cabinet cooling products
CV	Sub-series	ClimaSys CV series standard cabinet filter fan
F	Product type	Fan
165	Air flow rate	Rated airflow 165m鲁/h at 50Hz, 193m鲁/h at 60Hz
M	Mounting type	Side mounting on cabinet
230	Rated voltage	230V AC
P	Protection configuration	Equipped with pre-filter
F	Air outlet configuration	Fitted with front grille

Category	Technical Index	Remarks
Basic Parameters
Product Type	Cabinet Filter Fan	ClimaSys CV series, IP54 protection
Air Flow	165m³/h (50Hz) / 193m³/h (60Hz)	Measured with standard G2 filter
Voltage Range	175~253V AC	Compatible with most 230V power grids worldwide
Rated Voltage	230V 50/60Hz	Dual frequency compatibility
Electrical Parameters
Power	16.3W (50Hz) / 14.3W (60Hz)	High energy efficiency
Current	0.12A (50Hz) / 0.94A (60Hz)	Low power consumption design
Connection	Faston terminal + power cable	Easy installation
Physical Parameters
External Dimension	268×248×104mm	Height×Width×Depth
Cutout Size	223×223mm	Standard cabinet mounting hole
Material	Air outlet grille: ASA+PC thermoplastic	Anti-aging, grey RAL 7035
Weight	1.14kg	Stable installation, low resonance
Performance Parameters
Protection Class	IP54	Dustproof and splashproof, suitable for outdoor cabinets
Bearing Type	Ball bearing	Long service life, low noise
Noise Level	50~51dB	Quiet operation, applicable near office areas
Max Static Pressure	50Pa (0m³/h)	Resists certain air resistance
Environmental Parameters
Operating Temperature	-20℃~60℃	Wide temperature range for harsh environments
Storage Temperature	-40℃~70℃	Reliable transportation and storage
Certification	REACH, RoHS	Compliant with environmental standards

Brand	Model	Air Flow(m³/h)	Voltage	Protection Class	Cutout Size(mm)	Replacement Advantages
Rittal	3239200	74/87	230V AC	IP54	148×148	Tool-free quick installation
Rittal	3241700	160/190	230V AC	IP54	223×223	High-efficiency energy saving series
Stego	FK 66230	165/193	230V AC	IP54	223×223	Integrated temperature control, intelligent start-stop
Pfannenberg	1041230	160/190	230V AC	IP54	223×223	Long filter service life, low maintenance frequency
RS PRO	130-853	165/193	115V AC	IP54	223×223	Cost-effective, sufficient stock

Fault Phenomenon	Possible Causes	Inspection Steps	Maintenance Solution
Fan not running	1. Power disconnected	1. Test power voltage	1. Reconnect power supply
	2. Motor burnout	2. Check motor winding resistance	2. Replace identical motor
	3. Stuck bearing	3. Manually rotate fan blade	3. Clean and lubricate bearing
	4. Control circuit failure	4. Inspect loose Faston connector	4. Reconnect or replace connector
Reduced airflow	1. Clogged filter	1. Check filter blockage	1. Clean or replace G2 filter
	2. Dust accumulated on blades	2. Inspect blade cleanliness	2. Clean blades with soft brush
	3. Undervoltage	3. Measure operating voltage	3. Adjust voltage to rated value
	4. Reverse rotation	4. Verify mounting direction	4. Reinstall fan outward air discharge
Abnormal noise	1. Worn bearing	1. Locate noise source	1. Replace bearing or whole fan
	2. Unbalanced fan blade	2. Check blade deformation and attachments	2. Correct balance and clear debris
	3. Loose mounting	3. Tighten mounting screws	3. Fasten all screws
	4. Vibration resonance	4. Observe cabinet vibration	4. Add shock pad or adjust position
Overcurrent protection	1. Motor short circuit	1. Test insulation resistance	1. Replace motor
	2. Excessive bearing friction	2. Check bearing flexibility	2. Lubricate or replace bearing
	3. Overvoltage	3. Measure operating voltage	3. Restore normal voltage

Applicable Scenarios

Industrial Automation: Cooling for PLC, inverter and servo drive cabinets
Power System: Heat dissipation for outdoor ring main units, box substations and charging pile control boxes
Telecommunication: Ventilation for base station cabinets, optical distribution boxes and data center server cabinets
Rail Transit: Temperature control for signal boxes and converter cabinets
New Energy: Cooling for photovoltaic inverters and energy storage control cabinets

Non-recommended Scenarios

Corrosive atmosphere such as chemical and marine environment (anti-corrosion model required)
Heavy dust sites like mines and cement plants (extra pre-filter needed)
Submerged or long-term rain exposure (IP54 only splash-proof)
Fully sealed space without air inlet circulation

Typical Cases

Automobile Factory: Installed on welding robot cabinets, failure rate reduced by 70% against high temperature

Power Grid Company: Eliminated switch misoperation, equipment service life extended 3 times

Data Center: Hierarchical cooling with air conditioner, energy consumption cut by 20%

Quick Calculation Rule

Airflow demand = Cabinet volume × (8~10) m³/h, suitable for 16~20m³ cabinet
Voltage selection: 230V for general industry, 115V for North America, 24V for DC system
Mounting mark: M=side, MF=top, FB=bottom

Operation Warnings

Inspect and replace G2 filter every 3 months to avoid airflow drop and motor overload
Keep air outlet outward and match air inlet for effective ventilation
Adopt cabinet air conditioner when external temperature is 5℃ higher than internal temperature
Restrict voltage fluctuation within ±10% to guarantee service life
Confirm UL, CE and other certifications for export use
Order Information

Model: NSYCVF165M230PF

Order No.: NSYCVF165M230PF (Global unified)

Package Contents: 1 axial fan motor, 1 cutting template, 1 pre-filter, 1 air outlet grille, 1 power cable, 2 protective grilles

Delivery Lead Time: 3-5 working days for standard stock items
