Medidor de electricidad Chint DTS634

The Chint DTS634 medidor de electricidad is an electronic active energy meter suitable for three-phase power grids, featuring high-precision measurement, intelligent management, and flexible configuration.

1. Technical Specifications and Model Classification
2. Rangos de voltaje y corrienteMedidor multifuncional con pantalla digital Chint PD666-3S3

– Supports multiple voltage specifications: 220/380V (trifásico de cuatro hilos), 57.7/100V (trifásico de tres hilos).

– Covers a wide range of current specifications, como 0.2-0.5(60)A, 10(40)A, 20(80)A, etc., adapting to different load scenarios.

– Accuracy classes are divided into Class 1 y clase 2, complying with national standards such as GB/T17215.321-2008.

2. Entorno operativo

– Specified operating temperature range: -25℃ to +55℃; extreme range: -40℃ a +70℃, adecuado para entornos hostiles.

– The protection level is usually IP65, with dustproof and waterproof capabilities.

3. Display and Interfaces

– Display methods include a meter counter, CONDUJO, or LCD screen, which can display parameters such as voltage, actual, and power in real-time.

– Supports RS-485 communication interface and infrared communication, compatible with protocols such as DL/T645, facilitating remote meter reading and data management.

1. Core Functions and Application Scenarios
2. Intelligent Measurement and Management

– Supports forward and reverse active energy measurement, with reverse energy accumulated as forward, suitable for scenarios with bidirectional power flow (such as distributed energy access).

– Equipped with functions such as prepaid control, step electricity price calculation, and load curve analysis, meeting the refined electricity management needs of commercial and industrial users.

– Can store historical data and generate reports, supporting USB export or remote query, facilitating energy consumption analysis and energy-saving optimization.

2. Reliability Design

– Adopts industrial-grade components and SMT technology, with strong anti-electromagnetic interference capability and stable long-term operation.

– Built-in fault detection mechanism, which can automatically identify problems such as wiring errors and voltage abnormalities, and prompt through LED indicators or remote alarms.

3. Campos de aplicación

– Widely applicable to three-phase four-wire or three-wire power grids, covering industrial, comercial, and residential users, especially suitable for scenarios requiring remote monitoring and prepaid management.

III. Notas de instalación y uso

1. Requisitos de instalación

– Must be operated by professional electricians; the recommended installation height is about 1.8 metros, ensuring firm wiring and compliance with terminal box markings.

– The ambient temperature should be between -25℃ and +55℃, evitando la humedad, alta temperatura, or strong electromagnetic interference environments.

2. Wiring and Debugging

– Strictly connect the three-phase voltage and current circuits according to the wiring diagram, paying attention to the phase sequence and neutral line access (para sistemas trifásicos de cuatro hilos).

– Before first use, check the integrity of the lead seal; if damaged, contact the supplier for re-verification.

3. Data Reading and Maintenance

– Real-time data can be read through the local display screen or communication interface; the blinking frequency of the pulse indicator is proportional to the electrical load.

– Clean the shell regularly to avoid dust accumulation affecting heat dissipation; it is recommended to conduct a comprehensive verification by the manufacturer every 18 meses.

1. International Applicability and Certifications
2. Adaptabilidad al mercado norteamericano

Voltaje y frecuencia: The standard model is 50Hz and 220/380V, which needs to be adapted to the US 120/240V, 60Hz power grid through a transformer, which may affect measurement accuracy.

Certification Status: Actualmente, public information does not explicitly mention UL certification or special models for the North American market; users need to bear compliance risks on their own.

2. Compatibility with International Standards

– Cumple con estándares internacionales como IEC 62053-21, supports general protocols such as MODBUS and DL/T645, facilitating access to global energy management systems.

1. Purchase and Support
2. Canales y Precios

– Users in the United States can consult the import process via Whatsapp: 0086-13811255435, but attention should be paid to voltage adaptation and certification issues.

2. Apoyo técnico

– The Chinese installation manual can be downloaded from the Chint official website; English materials need to be applied for through international customer service.

– The product warranty period is 18 meses; purchase vouchers and intact lead seals must be retained to enjoy after-sales service.

Resumen

The Chint DTS634 electricity meter has become a mainstream choice for three-phase power grid measurement due to its high reliability, funciones inteligentes, and flexible configuration. For domestic users, its specifications and functions fully meet conventional needs; if planning to use it in North America, it is recommended to directly contact via Whatsapp: 0086-13811255435 for customized solutions or alternative models.
