B&Module CPU R X20-CP-1484

X20-CP-1484 is a compact CPU module of B&R. X20 series. Il adopte un processeur compatible Intel Celeron, équipé de 1 emplacement d'extension, Ethernet temps réel POWERLINK, Ethernet, RS232, Interfaces de communication USB et X2X Link. Doté d'une conception sans ventilateur, il convient aux scénarios de contrôle d'automatisation industrielle de complexité moyenne.

1. Définition du segment du modèle (Precise Decoding)

Définition complète du modèle:

X20 series CPU module, Celeron-compatible processor, 1 interface module expansion slot, RJ45 shielded interface (avec -1 suffixe), conception compacte.

2. Core Specification List (Official Data)

3. Liste des accessoires (Standard & Optional Parts)

4. Competitive & Remplacement entre marques (Direct Substitution)

5. Lignes directrices de sélection & Solutions alternatives (Référence rapide)

Formule de sélection

Three key factors for X20 selection: Processor performance, Extensibilité, Communication requirements

Processor performance: 1484=Celeron compatible; 1382=100MHz x86; 3484=Same performance with 3 machines à sous

Extensibilité: 1/3 slots determine the quantity of expandable interface modules

Communication requirements: Select appropriate interface module according to fieldbus type

Quick Alternative Solutions

1. Mise à niveau de la même série: X20CP3484 (3 expansion slots, ideal for systems requiring more communication interfaces)
2. Mise à niveau des performances: X20CP1585 (Intel Atom processor, higher performance for complex algorithm application)
3. Functional Replacement:

Small System: X20CP1382 (100MHz x86 processor, 1 slot, moindre coût)

Large System: X20CP4785 (Multi-core processor, 4 machines à sous, top-level performance)

Scénarios d'application

Machines d'emballage: Medium-complexity control, POWERLINK real-time synchronization, 1 expansion slot is sufficient

Printing Equipment: Requires high-speed data processing; fanless design adapts to dusty environments

Logistics Automation: Multi-axis motion control, servo system connection, ACOPOS performance supported

Nourriture & Boisson: Large plage de températures de fonctionnement, Protection IP20, suitable for workshop environments

Automatisation des bâtiments: Rich communication interfaces, compatible with various sensors and actuators

6. Conformité du fret aérien & Attestation
7. Conformité du fret aérien: Built-in CR2032 lithium battery (Lithium content ≤2g), classified as UN3481. Compliant with IATA DGR Section II, allowed for carry-on or cargo shipment without special approval.
8. Certifications:

CE: Conforme à la norme EN 61131-2, DANS 61010-1

UL: Conforme à UL 508 industrial control equipment standard

RoHS: Eco-friendly materials complying with EU directives

Marine Certification: Compliant with DNV GL, LR and other classification society standards

7. X20 CPU Full Series Core Model List

X20-CP-1484 is a cost-effective compact CPU module. With its Celeron-compatible processor, 1 emplacement d'extension, rich communication interfaces and fanless design, it serves as an ideal choice for medium-complexity industrial automation. The built-in lithium battery supports SRAM data backup, and POWERLINK Real-Time Ethernet ensures high-speed synchronous control. It is widely applied in packaging, impression, logistics and other industries. Model selection shall be precisely matched according to system complexity, expansion demands and communication protocols.

The B&R X20-CP-1484 is a mid-range compact PLC integrated with POWERLINK real-time Ethernet. It is optimized for small and medium-scale motion control, distributed I/O, and real-time communication applications. Its core industries cover packaging, impression, plastics, textile, logistique, nourriture & boisson, traitement de l'eau, fabrication de produits électroniques, and general mechanical equipment.

1. Core Application Industries & Scenarios
2. Machines d'emballage (Le plus grand public)

Horizontal / Vertical packaging machines, heat shrink wrapping machines, labeling machines, soudeuses de cartons, strapping machines

Caractéristiques: Multi-axis synchronization via POWERLINK, high-speed cutting/positioning, short cycle time (≈800μs), poussière & humid environment adaptability, fanless high reliability

2. Impression & Paper Making

Digital printing machines, flexo / gravure printing machines, slitting machines, rewinding machines, pulping & paper production lines

Caractéristiques: Tension control, color registration synchronization, high-speed web processing, high-precision positioning control

3. Plastique & Machines en caoutchouc

Presses à injecter, extrudeuses, blow molding machines, hollow forming machines, rubber vulcanizing machines

Caractéristiques: Hydraulique / servo hybrid control, temperature closed-loop control, high-pressure mold clamping / injection, multi-stage process control

4. Machines textiles

Knitting machines, weaving machines, winding machines, printing and dyeing equipment

Caractéristiques: High-speed multi-axis synchronization, stable tension, low vibration, long-term continuous operation

5. Logistique & Warehouse Automation

Lignes de tri, conveyor lines, stackers, AGV/AMR, automated warehouses

Caractéristiques: E/S distribuées, POWERLINK real-time bus, multi-station coordination, long-span equipment networking

6. Nourriture & Boisson

Filling lines, stérilisateurs, homogenizers, tri & équipement d'emballage, bakery machinery

Caractéristiques: Conception sanitaire, large plage de température (0…55℃), dust and moisture resistance, recipe management, batch traceability

7. Traitement de l'eau & Protection de l'environnement

Stations d'épuration (grilles / pompes à eau / blowers / dewatering machines), water purification plants, reclaimed water reuse, pump station monitoring

Caractéristiques: Analog closed-loop control (pH / dissolved oxygen / liquid level), distributed control, forte anti-interférence, long-term stable operation

8. Fabrication d'électronique (CMS / PCB)

SMT placement machines, PCB inspection machines, solder paste printers, automatic insertion lines

Caractéristiques: Positionnement de haute précision, high-speed motion control, synchronisation multi-axes, hybrid communication of Ethernet/IP + POWERLINK

9. General Mechanical Equipment

Machines-outils à commande numérique, laser cutting machines, plasma cutting machines, machines à bois, special-purpose machine tools

Caractéristiques: Integrated motion & logic control, fanless design, compact installation, rentable

10. Process Industry (Chimique / Pharmaceutique / Énergie)

Small reaction kettles, mélange & stirring equipment, filtration & separation units, pharmaceutical production lines, photovoltaic equipment

Caractéristiques: Température / pression / flow closed-loop control, batch control, hazardous area compatibility, data acquisition and monitoring

1. Sélection & Adaptation Key Points (Why Choose X20-CP-1484)

✅ Medium-scale control: 32MB DRAM, 1MB SRAM, single expansion slot; suitable for 100–500 I/O points, 8–16 motion axes

✅ Mandatory real-time communication: Integrated POWERLINK (hard real-time) + Ethernet + RS232 + USB, meeting multi-device synchronization requirements

✅ Strong environmental adaptability: Protection IP20, 0…55℃ operating temperature, fanless design, 5g vibration resistance, suitable for harsh workshop conditions

✅ Distributed architecture: Remote I/O expansion via X2X bus, ideal for long production lines and multi-station collaborative systems

III. Cas d'application typiques

📦 Packaging Line: X20-CP-1484 controls 6-axis labeling and conveying with POWERLINK synchronization; capacity up to 300 packages per minute

🚰 Sewage Treatment: Main CPU manages 12 I/O stations to control water pumps, blowers and chemical dosing; stable continuous operation over 5 années

🚚 Logistics Sorting: Lecteurs 4 sets of high-speed sorting lines with POWERLINK linkage; sorting capacity up to 1000 pièces par heure

🍶 Refined Oil Loading: Distributed control for 14 loading arms via Ethernet + CAN bus; annual throughput up to 3 million tons

1. Not Recommended Application Scenarios

❌ Large process plants (redondance / hot backup required; choose X20CP3484 or higher model)

❌ Ultra-high-speed multi-axis systems (sur 16 axes; choose X20CP1585 / X20CP4785)

❌ Zone 0 explosive hazardous areas (special explosion-proof model required)
