Siemens 3RQ2000-1BW00 Coupling Relay

Industrial coupling relay of Siemens SIRIUS series, 装備されている 2 切替接点, wide voltage range 24-240V AC/DC and screw terminals. It serves as a replacement for 3TX7002-1CB00 and 3RS1800-1BW00, and is designed for PLC signal isolation and control circuit coupling.

1. モデルコードの解釈

フルネーム: Enclosed industrial coupling relay, 2 切替接点, 24-240V AC/DC wide voltage, screw terminal connection.

2. コア技術パラメータ

3. クロスブランド & Obsolete Model Replacement List

選択のヒント: Verify full consistency of contact quantity, 端子の種類, mounting dimensions and electrical parameters before replacement.

4. Full Model List of 3RQ2000 Series

5. 一般的な障害 & トラブルシューティング

6. 適用範囲 & 業界の事例

6.1 該当するシナリオ

PLC Signal Isolation: Couple signals between PLC outputs and field actuators to protect PLC modules.

Control Circuit Expansion: Increase available control signals to drive multiple loads via one signal.

Voltage Conversion: Connect control circuits with different voltage levels, 例えば. 24V DC PLC output for 220V AC contactors.

Interference Suppression: Isolate signals in high-interference environments such as inverters and welding equipment to avoid false triggering.

産業用オートメーションシステム: 生産ライン制御, 包装機械, 工作機械, コンベアシステム, 等.

6.2 推奨されないシナリオ

High-frequency switching: Not suitable for frequent switching over 10 cycles per second.

Inductive load without protection: Surge suppressors are mandatory when driving inductive loads such as motors and solenoid valves.

Corrosive environments: No special anti-corrosion treatment; not for strong acid, alkali or high salt mist conditions.

Explosive hazardous areas: Non-explosion-proof design; prohibited for flammable and explosive locations.

6.3 代表的な応用例

場合 1: Automotive Component Production Line

応用: PLC controls clamps and welding torches of robotic welding stations.

構成: 3RQ2000-1BW00 isolates PLC output signals from 220V AC solenoid coils.

Result: Resists welding current interference; failure rate reduced by 90%, maintenance cost cut by 50%.

場合 2: 食べ物 & Beverage Filling Line

応用: Connect HMI touch panel and filling valve control circuits.

構成: Two units of 3RQ2000-1BW00 control 4 filling valves (2 いいえ + 2 ノースカロライナ州) via one HMI signal.

Result: Simplified wiring, improved system reliability and fewer spare part types.

場合 3: Intelligent Warehousing System

応用: Isolate position sensor signals of stacker cranes and PLC inputs.

構成: 3RQ2000-1BW00 converts 24V DC sensor signals to PLC-compatible signals.

Result: Eliminates interference from long-distance signal transmission; positioning accuracy improved to ±1mm.

7. 選定ガイドライン & Quick Reference Rules
8. Contact quantity by letter: A = 1CO, B = 2CO, C = 3CO
9. Terminal type by digit: 1 = Screw terminal, 2 = Spring terminal
10. Contact material by suffix: W = Standard contact, CW01 = Gold-plated contact
11. Universal voltage: Full series supports 24-240V AC/DC
12. Priority for replacement: Directly replace 3TX7 / 3RS18 series with corresponding 3RQ2000 models

Ordering Notice: 標準パッケージ: 1 unit per box; Minimum order quantity: 1 ユニット. It is recommended to prepare 2~3 units as spare parts for general industrial automation control.

Common Faults and Troubleshooting of Siemens 3RQ2000-1BW00 Coupling Relay

1. Relay Fails to Operate Completely
2. No power supply to coil

Measure input voltage to confirm it is within 24~240V AC/DC. Check circuit breakers, fuses and continuity of upstream control circuits, and tighten loose terminals.

2. Loose / poor terminal connection

Retighten screw terminals. Check wire crimping, broken wires and wires trapped under terminal screws.

3. 焼けたコイル

Long-term overvoltage or frequent voltage surges will burn the coil. Replace the relay if burnt marks or abnormal odour are observed.

4. 機械的な妨害

Accumulated dust and continuous vibration cause internal armature sticking. Tap the housing gently for test; replace the relay if the issue persists.

2. Coil Pulls In but Contacts Open / 接触不良
3. Oxidation and dust accumulation on contacts

Commonly seen in humid and dusty environments, especially for low-power signal circuits. Clean contacts after power cut and test with repeated switching operations.

2. 接触溶接

Excessive load current or frequent inrush load leads to stuck contacts. Disconnect the load for verification. Replace the relay as welded contacts cannot be repaired.

3. Fault on load side circuit

Troubleshoot downstream contactors, solenoid valves and broken wires. Confirm relay fault only after excluding external failures.

3. Random Operation / Unexpected On & オフ
4. Electromagnetic interference

Easily affected when installed close to inverters, モーター, high-power contactors or long control cables. Route control cables away from power cables and apply shielded wires and surge absorbers.

2. 電圧変動 & electrical noise

Sudden voltage drop and voltage spikes cause false operation. Install voltage stabilizers and filters on the upstream side.

3. Abnormal ambient temperature

Operation above +60°C or condensation under low temperature leads to internal circuit malfunction. 換気を改善する, dehumidification and heat dissipation.

4. インジケーターランプの異常
5. Light off, relay works normally

Only the LED bulb is damaged. The relay can remain in service or be replaced.

2. Light always on / flickering, relay does not operate

Malfunction of internal voltage divider and indicator circuit, usually accompanied by coil failure. Replace the relay directly.

5. Overheated Wiring Terminals
6. 配線の緩み: Retighten terminals to specified torque.
7. Undersized wire gauge: Replace with cables with cross-section matching the load current.
8. Continuous overload: Actual load exceeds rated 5A contact current. Apply load sharing or use higher-capacity relay.
9. Frequent Failures under Inductive Load (Solenoid / コンタクタ)

Symptoms: Shortened contact service life, frequent contact welding and unexpected tripping

トラブルシューティング: The absence of surge suppressors causes reverse high voltage from inductive loads to damage contacts during power-off. Connect freewheeling diodes (DC用) or RC snubbers (交流用) in parallel across inductive loads.

7. On-site Quick Troubleshooting Procedure
8. Cut off power → Inspect appearance, wiring and terminal tightness
9. Switch on power → Measure input control voltage
10. Observe indicator light and listen to pull-in sound to judge coil status
11. Cut off power → Test NO/NC contacts with multimeter continuity mode
12. Distinguish faults among upstream control circuit, relay itself and downstream load circuit
