Yaskawa CIMR-AB4A0018FBA Inverter

Application Summary of CIMR‑AB4A0018FBA (A1000, HD 5.5kW / ND 7.5kW, 380V) Inversor

Unit Specification: Heavy-Duty(alta definição) 5.5kW, Normal-Duty(DE) 7.5kW, PG/PG-less vector control, high starting torque. Mainly applied to two categories: high-precision variable speed regulation & constant-torque loads, and energy saving for fans & bombas.

1. Definição de código de modelo

2. Especificações Técnicas Principais

3. Full Series List (400Classe V, BA with Keypad)

Observação: Full series covers 0.4kW~355kW; above is frequently used models only

4. Cross Model & Cross-Brand Replacement Guide

4.1 Internal Yaskawa Model Upgrade

4.2 Comparação equivalente entre marcas

5. Ambiente de aplicação & Casos da Indústria

5.1 Cenários de aplicação recomendados

5.2 Not Recommended Installation Conditions

Explosivo & flammable atmosphere (explosion-proof inverter required instead)

Severe EMI environment (external EMC filter mandatory)

Altitude over 1000m with no power derating (consult manufacturer for derating specs)

Locations with vibration exceeding 0.6G (special mounting structure required)

5.3 Practical Retrofit Cases

Case1: Energy Saving Retrofit on Food Packaging Conveyor

Carregar: Biscuit packaging conveyor system

Before upgrade: Direct-on-line startup with heavy mechanical impact & high power waste

After upgrade: CIMR-AB4A0018FBA realizes soft start/stop & speed auto-adjustment following production cycle

Resultado: 30% longer equipment service life, 35% power reduction, 5% higher finished product rate

Case2: Central Air-conditioning Chilled Water Pump Retrofit

Carregar:5.5kW cooling circulation pump

Before upgrade: Constant-speed running with flow throttled by valve leading to huge energy loss

After upgrade: Inverter adjusts pump speed automatically based on return water temperature

Resultado: Approx.28,000 kWh annual power saving, payback period:6 meses

6. Conformidade de Remessa Aérea & Certification Manual

6.1 Air Transport Compliance Judgment

Built-in battery: No lithium cell equipped, only passive capacitors installed; excluded from UN3480/UN3481 lithium battery transport regulation

Shipping classification: General electrical goods, no UN38.3 test report or air identification certificate needed

Embalagem: Original factory carton or ISTA-certified packaging with anti-static & moisture-proof protection

6.2 Key Product Certifications

7. Dicas de seleção & Regras de referência rápida

7.1 A1000 Selection Mnemonic

AB4A for three-phase 400V, capacity code links output ampere,

switch HD/ND duty freely, BA=with keypad, AA=without spare,

robust vector performance, fits most general industry drives.

7.2 Quick Calculation Rules

400V model prefix: CIMR-AB4A (with keypad) / CIMR-AA4A (keypad-less)

Aprox.. ND kW ≈ Capacity Code ×0.1; Aprox.. HD kW ≈ Capacity Code ×0.06

Código 0018 = HD5.5kW / ND7.5kW, rated output 17.5A

Detailed Field Application Breakdown

7. General Fluid Energy Saving (Fãs & Bombas, prefer ND7.5kW rating)
8. HVAC Central Air Conditioning

Chilled water pumps, cooling tower fans, AHU supply fans

Working principle: Variable speed regulated by water temperature & differential pressure instead of valve throttling; 30~50% power saved

Aplicativo: Single pump ≤7.5kW for shopping malls, edifícios de escritórios & factory central air systems

2. Water Supply & Drainage System

Plant service water pumps, booster pumps for secondary water supply, sewage & rainwater lift pumps

Constant pressure control: Closed-loop regulation with pressure transducer; low-speed running at night to cut idle loss

Suitable for residential pump rooms & small factory wastewater treatment stations

3. Boiler Auxiliary Equipment

Induced draft fan, forced draft fan & boiler feed pump with auto speed adjustment by furnace negative pressure.

5. Conveyor & Bulk Material Handling (Constant-torque, select HD5.5kW)
6. Light Industry Assembly Conveyors

Food processing lines, carton packing conveyors, bottle filling & small roller bed lines

Vantagem: Soft start/stop prevents belt rupture; multi-speed switching matches production tact time

2. Small Mining & Aggregate Feeding Equipment

Light-duty belt feeders, spiral screw conveyors for grain, powder and sand transportation

Recurso: 150% low-frequency starting torque suits heavy inrush load at startup

3. Warehouse Sorting Equipment

Small sorting conveyors and pallet roller conveyors.

III. CNC & Machining Tools (High-precision speed control via vector drive)

1. Spindle drive for conventional lathe, bench milling & surface grinder: 0~400Hz wide frequency range enables stepless speed change to replace traditional gearbox and improve surface finish; ±0.2% speed accuracy for PG-less vector mode
2. Bench grinders, polishing machines & small wire drawing machines.
3. Máquinas Têxteis (Primary constant tension control application)

Twisting frames, small looms, cone winding machines, fabric setting pull rollers

Demanda: Alto torque em baixa velocidade & stable tension to avoid yarn breakage; A1000 vector drive perfectly matches 5.5kW rated load

1. Light Lifting & Hoisting Applications

Only for light-duty lifting; heavy crane uses H1000 series instead

Small cargo lifting platforms, fixed compact freight elevators, miniature electric hoists

Vantagem: Smooth start/stop prevents load slipping with zero-speed holding torque to eliminate mechanical impact

1. Rubber, Plástico & Máquinas de embalagem
2. Auxiliary feed screw for plastic extruder & small pelletizer;
3. Horizontal flow wrappers, sealing machines & film winding machines with constant winding tension control.

VII. Grain & Feed Processing Equipment

Auxiliary drives for grinders, feed mixers, grain elevators and separator fans.

Prohibited & Unadvisable Installation Conditions

1. Explosion-prone chemical workshops: Standard IP20 design without explosion-proof certification; EX-type inverter required;
2. Altitude over 1000m: Minimum 10% power derating mandatory otherwise overheat alarm occurs;
3. Equipment with severe cyclic shock & vibração (impact crushers, forging hammers): Loose terminals and PCB damage caused by continuous vibration;
4. Direct driving of large shock loads (heavy gantry cranes, large air compressors): Insufficient rated power, select high-power H1000 series;
5. Outdoor open-air mounting without control cabinet: No ingress protection; rain & dust damage internal power modules.

Verified On-site Application Cases

1. Caso 1: ND rated 7.5kW Chilled Water Pump

Injection molding plant pump retrofit: Original valve throttling at fixed speed; variable frequency control by coolant temperature saves around 26,000 kWh yearly.

2. Caso 2: HD rated 5.5kW Packaging Line Conveyor

Biscuit production main transport with frequent start-stop; full-load startup at 0.5Hz without slip; equipment failure rate cut by 70%.

Quick Selection Tip

Fãs & Water Pumps → apply ND 7.5kW rating

Transportadores, Máquinas-ferramentas, Textile Equipment → apply HD 5.5kW rating
