パーティー 161360 Standard Square Tie-Rod Cylinder

Item No.: 161360

Model Name: DNC-40-80-PPV-A

製品カテゴリー: Standard square tie-rod cylinder (ISO 6431 compliant cylinder)

モデルコードの内訳

DNC: ISO standard tie-rod cylinder series

40: ボアサイズ 40 mm

80: Stroke length 80 mm

PPV-A: Adjustable end cushioning with pneumatic cushion pistons at both ends

2. 主要な技術仕様

2.1 Dimensional Specifications

穴径: 40 mm

Working stroke: 80 mm

Piston rod diameter: 16 mm

Mounting standard: ISO 6431 / VDMA 24562

2.2 プレッシャー & 中くらい

Operating pressure range: 0.6 ～ 10 バー

Maximum withstand pressure: 12 バー

中くらい: Dry compressed air (40 ろ過精度μm, oil-free or lightly lubricated air acceptable)

周囲温度: -20 ℃～ +80 ℃

2.3 Cushioning & シール

Cushioning type: Adjustable pneumatic cushioning at both ends (PPV)

Cushion travel: 約. 19 mm

シール材: Wear-resistant PU polyurethane seals, resistant to common contaminants in compressed air

2.4 Output Force (Theoretical Value @ 0.6MPa)

Extending thrust: 754 N

Retracting pull force: 634 N

3. 取り付け & Port Interfaces

Air tube ports: G1/4 (air ports at both cylinder ends)

取付タイプ: Basic tie-rod design, compatible with accessories (trunnion mounts, foot brackets, flanges, intermediate lugs)

Piston rod thread: M16×1.5 external thread

4. 重さ & 代表的な用途

Overall weight: 約. 1.35 kg

代表的な用途: Automated conveying, stamping positioning, machine tool clamping, 包装生産ライン, material sorting & pushing, automotive tooling fixtures

5. Matching Replacement & オプションのアクセサリ
6. Mounting accessories: SNCL-40 foot bracket, ZNCF-40 front flange, SNCB-40 trunnion support
7. Sensor accessories: Proximity sensor SMT-8M-A; built-in magnetic ring, no extra installation required
8. Consumable spare parts: Repair kit DNC-40-KP (complete seal set)
9. 代替モデルのリファレンス

New upgraded model with identical dimensions: DSBC-40-80-PPVA-N3 (new generation upgraded DNC cylinder, structurally compatible for direct replacement)

Short-stroke light-load alternative: ADN-40-80-P-A (compact flat cylinder with smaller footprint)

7. Key Differentiation Note

161360 corresponds to DNC-40-80-PPV-A, equipped with pneumatic cushioning at both ends.

Models without the PPV-A suffix have no cushioning, produce heavy impact, and are unsuitable for high-speed working conditions.

Complete Technical Data for パーティー CPV14-M1H-5LS-1/8

1. Basic Item Information

モデル: CPV14-M1H-5LS-1/8

Valve Terminal Series: Single solenoid valve for CPV14 compact valve terminals

Common Item Code: 162609

Segment-by-Segment Model Definition Table

2. Valve Function Definition – 5/2-Way Single Solenoid Spring Return
3. Air circuit layout: 5 air ports, 2 operating positions
4. Actuation principle: Solenoid energization triggers valve shift; spring automatically resets the valve when de-energized
5. Air Circuit Distribution

コイル通電: Supply port P → Working port A; Chamber B exhausts

コイルが非通電状態 (スプリングリターン): Supply port P → Working port B; Chamber A exhausts

4. 5LS Feature: Integrated one-way flow control on working outlets, independent speed adjustment for extend and retract strokes of chambers A and B
5. Core Electrical Specifications
6. Standard coil voltages (2 common variants)

DC24V: Standard industrial type, coil power 1.8W

AC230V: 交流式, power consumption 3.6VA

2. 電気インターフェース: Standard MIDC 8mm multi-pin socket, IP65 protection rating (with sealed plug)
3. Insulation class: クラスB; allowable voltage fluctuation ±10%
4. Valve body protection rating: IP65 (when plug and sealing ring are correctly assembled)
5. Pneumatic Specifications
6. Port Sizes

Supply P, exhaust R1/R2: G1/8

Working outputs A, B: G1/8

2. Operating medium: Filtered dry compressed air with 40 μm filter element; oil-free or lightly lubricated air acceptable
3. 使用圧力: 2 ～ 8 バー; maximum withstand pressure 10 バー
4. 流量 (@ ΔP=1bar)

Standard flow per channel: 約. 700 l/分

5. Flow control: Adjustable integrated one-way flow control needle valves on outlets A and B (unique to 5LS version)
6. 動作温度: -5℃～+50℃
7. 機械式 & 実装データ
8. Valve width: 14 mm (uniform width for all CPV14 series valves)
9. 取付方法: Snap-in installation onto CPV14 valve terminal manifold bases
10. 重さ: 約. 85 g per single valve module
11. Exhaust mode: Central exhaust or individual exhaust selectable (determined by valve terminal base)
12. Compatible Matching Valve Terminal Bases

CPV14-GE series manifolds for multi-station valve terminal assemblies:

CPV14-VI Valve terminal end plate

Multi-station bases including CPV14-GE-8, CPV14-GE-10

Bus-type bases: CPV14-GE-DI02, CPV14-GE-PNP and other digital input bus valve terminals

7. Distinction of Similar Alternative Models
8. CPV14-M1H-5JS-1/8: Basic version without integrated flow control, 低コスト
9. CPV14-M2H-5LS-1/8: Double solenoid latching valve that maintains position after power cut; cannot directly replace this model
10. Upgraded series alternative: OVEL-14 new generation compact valve, compatible mounting dimensions and higher flow capacity
11. 典型的なアプリケーションシナリオ

Small automated equipment, 包装機械, 3C tooling fixtures, conveying cylinder control, small clamping cylinders, 並べ替え & pushing mechanisms. Ideal for centralized control of multiple cylinders to save installation space.

9. Consumable Spare Parts
10. Solenoid plug: MSSD-EB (standard DC24V plug)
11. Repair kit: CPV14-KP valve spool seal kit
12. Silencer: U-1/8 matched exhaust silencer
