LUST-CM-DPV1.3.0: LUST PROFIBUS-DP Communication Module

Only stock and used units are available for this brand. Please note if you require Lenze replacement products.

LUST-CM-DPV1.3.0 (also written as CM-DPV1,3.0) is a PROFIBUS-DP Kommunikationsmodul manufactured by LUST (Deutschland, später von Lenze übernommen). It is specially designed for C-series drives to establish connection and data exchange between the drive and the PROFIBUS network.

Kernspezifikationen

Technische Merkmale

1. Unterstützung des DPV1-Protokolls: Provides cyclic data exchange (PZD) and acyclic data exchange (PKW) um komplexe Steuerungsanforderungen zu erfüllen.
2. Flexible Data Configuration: Customizable process data length and parameter access methods for various applications.
3. Diagnostic Function: Detailed network and module status diagnostics for easy maintenance and troubleshooting.
4. Industrial-Grade Design: Resistant to harsh industrial environments and electromagnetic interference.
5. Modular Integration: Seamless integration with C-series drives, easy installation without complex setup.

Anwendungen

Automatisierte Produktionslinien

Robot systems

Verpackungsmaschinen

Printing equipment

Material handling systems

Other industrial automation applications requiring PROFIBUS-DP connectivity

Kompatibilität & Ersatz

1. Kompatible Laufwerke:

CDA3000 series inverters (0.75 kW–132 kW)

CDD3000 series servo controllers

CDE/CDB3000 series position controllers

CTC3000 series direct drive controllers

2. Ersatzoptionen:

Newer version: CM-DPV1.3.1 (Hardwarekompatibel, softwareoptimiert)

Lenze replacement: Corresponding Lenze PROFIBUS module (z.B., EMF2177IB)

Alternative protocols: Modern industrial Ethernet modules such as PROFINET, EtherCAT

Wichtige elektrische Parameter

Eingangsspannung: 18-30 V Gleichstrom

Max. aktuell: 0.25 A

Communication interface: PROFIBUS-DP (IN 50170 compliant)

Transmission speed: Bis zu 12 Mbit/s

Slave address range: 1–125

Process data length: Bis zu 244 bytes input / 244 bytes output

1. Firmware Version: Normalerweise V2.25-00, upgradeable via dedicated software.
2. Installation: Must be installed in the communication slot of the drive; ensure secure connection.
3. Konfigurationstools: LUST DriveTop or Lenze Engineer software for parameter setup and diagnostics.
4. Unterstützung: Since LUST was acquired by Lenze, technical support and spare parts are provided by Lenze.

Anwendungswert

The CM-DPV1.3.0 module provides reliable PROFIBUS-DP connectivity for LUST C-series drives, enabling seamless integration into PROFIBUS-based automation systems for centralized control, Parametrisierung, and diagnostics, improving productivity and system reliability.
