Módulo de E/S remotas Mitsubishi NZ2GF2B1-32D

Desglose del código del modelo

Posicionamiento del producto: Gigabit Ethernet CC-Link IE Field intelligent remote station module with 32-point DC24V digital inputs, compatible with Q/L/R/FX5U series PLC master stations.

2. Core Electrical Specifications

2.1 Input Specifications

Points: 32-point DC24V digital input, all 32 points share one common COM terminal, compatible with both sink and source wiring (supports positive/negative common modes)

Tensión nominal: CC 24 V (rango permitido: 20.4~28.8V, ripple ≤5%)

Single-point Input Current: Typical 6mA @ 24V, input resistance 3.8kΩ

ON Threshold: ≥15V / ≥4mA; OFF Threshold: ≤5V / ≤1.5mA

Tiempo de respuesta (8 software-selectable gears, default 10ms): 0/0.2/1/1.5/5/10/20/70EM

Aislamiento: Optocoupler isolation; Withstand voltage AC510V for 1 minuto, insulation resistance ≥10MΩ (DC500V)

Simultaneous ON: 100% full-point simultaneous ON without voltage drop limitation

2. Module Power & Comunicación

Unit Power Supply: CC 24 V, total power consumption ≤120mA (all points ON)

Bus Type: CC-Link IE Field 1000BASE-T Gigabit Ethernet

Network Ports: Doble RJ45 (IN/OUT, daisy-chain topology). Cat5e or higher double-shielded STP straight-through cables are mandatory

Station Type: Intelligent device station, occupies 1 logical station

Communication Registers: RX/RY = 32 agujas; RWr/RWw = 20 words each

Clase de protección: IP2X (only internal terminal protection; outdoor bare installation prohibited)

2. Dimensiones mecánicas & Peso

Outline Size: H50 × W200 × D68 mm

Peso: 0.38 kilos

Montaje: Montaje en carril DIN estándar de 35 mm; extension units cannot be attached

Terminales: 34-position M3.5 screw I/O terminals; spring-clamp power & FG terminals

3. Especificaciones ambientales & Certificaciones

Temperatura de funcionamiento: 0~55°C; Temperatura de almacenamiento: -20~75°C

Humedad: 5~95%RH (sin condensación)

Resistencia a las vibraciones: Compliant with industrial standards JIS B3502, IEC61131-2

Certificaciones: CE, UL/cUL, RoHS, Marine Classification Societies (DNV/ABS/LR/KC)

4. Instrucciones de cableado
5. Communication Circuit

PLC master station RJ45 → Module P1(EN); Multi-module daisy-chain connection: P2(AFUERA) connects to P1 of the next module. No terminating resistor required at line ends.

2. Fuente de alimentación del módulo

Wire spring terminals to DC24V+, 0V and FG ground (all cable shields shall be connected to FG uniformly).

3. Input Circuit (Single Common COM)

Sink Wiring (NPN sensors): COM terminal connected to 0V, 24V+ sensor signal wired to input terminals

Source Wiring (PNP sensors): COM terminal connected to 24V+, 0V sensor signal wired to input terminals

Todo 32 points share one common COM, enabling simple wiring for mass collection of limit switches and proximity sensors.

5. Key Software Configuration Points (GX Obras3)
6. Supported Master Station Modules: QJ71GF11-T2 / LJ71GF11-T2 / FX5-CCLIEF
7. Add remote stations in network parameters, select model NZ2GF2B1-32D
8. Independently configurable filter response time per channel to suppress field signal chattering
9. Built-in wire break / circuit diagnosis function; PLC can read module fault codes
10. Escenarios de aplicación típicos

Centralized signal collection of mass photoelectric sensors, proximity switches and limit switches on assembly lines

Remote signal acquisition at multiple stations for automotive welding lines, packaging and logistics sorting systems

Distributed I/O for large-scale machinery to reduce cabinet wiring length and cut cable costs

Multi-machine interconnected production lines; Gigabit CC-Link IE ensures high-speed real-time signal transmission

7. Comparación de series & Referencia de selección

8. Precauciones & Common Pitfalls
9. Only double-shielded STP cables shall be used for communication; connect both ends of cable shield to PLC and module FG terminals to eliminate communication interference.
10. Separate independent DC24V power supplies are recommended for external sensors and module power to avoid signal false triggering caused by voltage drop.
11. 0ms response time is only applicable for high-speed pulse signals; 5~10ms filter is recommended for ordinary switches to prevent chattering.
12. European versions have been announced EOL (Fin de vida); domestic supply remains stable. New projects may select the new-generation NZ2GF3 series as alternative.

mitsubishi NZ2GF2B1-32D Installation Manual (Full English Version)

Applicable Standard Manual: CC-Link IE Field Network Remote I/O Module User Manual (Doc No. SH-081113 Chinese Version)

Table of Contents

1. Advertencias de seguridad (Warnings / Precauciones)
2. Product Specifications & External Structure
3. Installation Environmental Requirements
4. DIN Rail Installation & Removal Procedures
5. Station Number DIP Switch Setting
6. Complete Terminal Wiring Specifications (Fuerza, FG, 32DI Inputs, CC-Link IE Cables)
7. Mandatory Noise Reduction Wiring Specifications
8. Pre-power-on Inspection Checklist
9. PLC Software Network Configuration Guidelines
10. Common Post-installation Faults & Contramedidas

1 Advertencias de seguridad (Mandatory Compliance)

WARNING (Risk of Fatal or Severe Injury)

1. Cut off all DC24V power supplies of the system before all installation, alambrado, disassembly and assembly operations. Hot plugging/unplugging of Ethernet cables, terminal blocks and modules is strictly prohibited.
2. The FG grounding terminal must be independently grounded with grounding resistance ≤100Ω to prevent electric shock, communication interference and module burnout.
3. Never connect AC220V or high-voltage cables to I/O or power terminals; this will directly burn the module and cause fire hazards.
4. External fuses must be installed inside the control cabinet to protect the module DC24V power circuit.
5. Only certified electricians are allowed to perform installation and commissioning work.

CAUTION (Risk of Equipment Damage & Maloperation)

1. Tighten terminal screws strictly per standard torque; insufficient torque causes overheating and short circuits, while excessive torque strips threads and damages terminal bases.
2. Communication cables must adopt Cat5e or higher double-shielded STP straight-through cables. Unshielded UTP cables are forbidden.
3. Separate power cables from communication/I/O cables during routing with a minimum clearance of 100mm to avoid electromagnetic interference.
4. Direct installation in environments with heavy dust, condensation or corrosive gas is prohibited; sealed control cabinets are required for protection.
5. Prevent water, metal debris and wire copper scraps from entering the module interior, which will lead to short-circuit burnout.

2 Apariencia del producto & Especificaciones básicas

2.1 Definición del modelo

NZ2GF2B1-32D: Gigabit CC-Link IE Field intelligent remote station module with 32-point DC24V digital inputs

2.2 Outline Dimensions

Width 200mm × Height 50mm × Depth 68mm, peso 0,38 kg, Montaje en carril DIN estándar de 35 mm.

2. Front Panel Zones
3. Upper Section: Dual RJ45 ports P1(EN), P2(AFUERA) (for daisy-chain wiring)
4. Middle Section: 8-position DIP station number switch, operation LED indicators
5. Lower Left: Spring-type module power terminals (+24V, 0V, FG)
6. Lower Right: 34-position M3 screw I/O input terminals (32DE + 2 parallel COM terminals)

2.4 LED Indicator Definitions

CORRER: Steady green = Normal operation; Flashing = Communication fault; Off = No power supply

LINK: Port link indicator; Steady = Cable connected; Flashing = Data transmission/reception

ERR: Steady red = Duplicate station number / Cable break / Module failure / Input circuit short circuit

3 Mandatory Installation Environmental Requirements

3.1 Temperatura & Humedad

Temperatura de funcionamiento: 0℃ ~ +55 ℃ (ensure good ventilation inside cabinet; do not mount close to inverters or heat-generating contactors)

Almacenamiento & Transportation Temperature: -20℃ ~ +75℃

Humedad: 5%~95%RH, no condensation at all times

3. Installation Location Restrictions
4. Only vertical upright DIN rail mounting is allowed (module front facing forward); upside-down, side or horizontal flat mounting is prohibited.
5. Keep a minimum distance of 300mm from strong electromagnetic sources including inverters, servoaccionamientos, contactors and high-power motors.
6. Do not install under direct sunlight, water dripping, oil contamination or heavy dust conditions.
7. Reserve ≥50mm ventilation gaps above and below modules inside the cabinet; no gaps required for side-by-side multi-module installation.

4 DIN Rail Installation & Removal Steps

4.1 Procedimiento de instalación

1. Confirm the rail is standard 35mm steel DIN rail with firm fixed mounting without shaking.
2. Pry open the upper and lower latches on the module rear side downward.
3. Hook the upper latch onto the top edge of the rail, attach the module to the rail and push upward tightly.
4. Snap the lower latch upward to fully lock the module without looseness.
5. Install rail stoppers at both rail ends to prevent horizontal sliding of modules.

4.2 Removal Procedure

1. Cut off all DC24V power supplies and wait 3 minutes for capacitor discharge.
2. Press the lower latch to pry it downward, lift the module bottom upward to detach from the rail.
3. Remove the module; do not pull cables with brute force.

5 DIP Station Number Setting (Mandatory Adjustment Before Installation)

8-position DIP switch on module front panel for binary station number configuration (intelligent stations 1~120)

1. DIP ON = Binary 1, OFF = Binary 0; the 1st position is the least significant bit
2. Ejemplo: Station No.1 → DIP 1 EN, others OFF; Station No.5 → DIP 1 & 3 EN
3. Critical Rules:

All remote stations on one CC-Link IE network must have unique station numbers; duplicate numbers trigger ERR red light faults

Power cycle the module after setting to activate new station number

Factory default: All DIP OFF (Station No.0, communication disabled; modification mandatory)

6 Complete Terminal Wiring Specifications (Core Installation Content)

6.1 Spring Power Terminals (3-position Left Side)

Consumo de energía: ≤120mA with all points ON; recommended power capacity ≥300mA per single module

Forbidden: Share thin wires for external sensor 24V and module power to avoid input false triggering caused by voltage drop

6.2 I/O Input Terminals (34-position M3 Screws, Right Side)

Diseño de terminales (32 input points, two parallel COM terminals):

1:X0 2:X1 3:X2 4:X3 5:X4 6:X5 7:X6 8:X7

9:X8 10:X9 11:XA 12:XB 13:XC 14:XD 15:XE 16:XF

17:COM 18:COM (two parallel common terminals, shared for all 32 agujas)

19:X10 ~ 32:X1F (remaining 16 input points)

Two Sensor Wiring Modes

1. Sink Wiring (Mainstream NPN proximity / photoelectric sensors)

COM terminal connected to 0V; 24V+ sensor output signal wired to X terminals

2. Source Wiring (PNP sensors)

COM terminal connected to +24V; 0V sensor output signal wired to X terminals

Input Rating: CC 24 V, ON ≥15V, OFF ≤5V, single-point current 6mA

Standard Terminal Screw Torque: 0.8~1.2N·m

6.3 CC-Link IE Field Cable Wiring (P1/P2 RJ45 Ports)

1. Topología: Daisy-chain connection

PLC master station RJ45 → Remote module P1(EN); Module P2(AFUERA) → P1 of next module

2. Mandatory Cable Standards

Cable: Cat5e/Cat6 double-shielded STP straight-through cable; cable shields crimped to RJ45 metal housings at both ends

Maximum single segment length: 100metro (not to be exceeded)

Cross-over cables, unshielded cables and low-quality cables are prohibited

3. Shield Treatment: Connect cable shield ends to PLC master FG and module FG respectively; single-end or double-end grounding is acceptable, floating shield is forbidden.

7 Noise Reduction Wiring Specifications (Avoid Communication Dropouts & Input False Triggering)

1. Separate power cables (CA 220 V., motor wires) from communication/I/O cables in separate cable trays with minimum 100mm clearance; install metal shielding partitions if separation is impossible.
2. All cables routed inside metal cable trays with reliable tray grounding.
3. Single-end grounding for I/O signal wires; multi-point double-end grounding is prohibited to prevent circulating current interference.
4. Avoid routing cables closely along inverter or contactor output sides.
5. Coil excess cables into small loops; large-area circular routing is forbidden (inductive interference risk).
6. Wire stripping length controlled at 5~6mm to prevent copper wire exposure and short-circuit risks.

8 Pre-power-on Full System Inspection Checklist (Mandatory After Installation)

1. Terminales de potencia: No short circuits, no reverse polarity wiring, FG reliably grounded
2. I/O Terminals: No copper wire overlap between adjacent terminals, COM wiring correct
3. Ethernet Cables: STP shield cables fully inserted, no loose links, no loop topology
4. Station DIP Switches: Unique non-zero station number set, no duplicate station numbers on network
5. Instalación Mecánica: Module latches fully locked, rail stoppers fixed, no tension stress on cables
6. Ambiente: No water accumulation, metal debris or dust buildup inside cabinet

9 PLC Software Configuration (GX Works3 Matching Settings)

9.1 Compatible Master Station Modules

Q Series: QJ71GF11-T2; L Series: LJ71GF11-T2; Serie FX5U: FX5-CCLIEF

9.2 Network Parameter Configuration Steps

1. Create new project, navigate to [Network Parameters] → CC-Link IE Field
2. Add remote intelligent station, select model NZ2GF2B1-32D, input station number matching DIP switch setting
3. Logical Station Occupation: 1 station; RX/RY allocated for 32 input points, 20 RWr & 20 RWw registers
4. Input Filter Response Time (8 software gears): 0/0.2/1/1.5/5/10/20/70EM

Ordinary switches: 5~10ms for anti-chattering; high-speed pulse signals: 0EM

5. Write parameters to PLC, restart PLC and remote modules; steady RUN light indicates normal communication

10 Common Post-installation Faults & Contramedidas

11 Instalación & Maintenance Prohibited Operations (Hard Restrictions)

1. Hot plugging/unplugging of RJ45 Ethernet cables and I/O terminal blocks is strictly forbidden
2. AC voltage shall never be connected to any module terminal
3. Do not disconnect module FG ground or leave cable shields floating
4. Do not over-tighten terminal screws to avoid thread stripping and base damage
5. Do not install modules in unprotected outdoor environments or high-humidity condensation conditions
6. Ordinary UTP cables cannot be used for CC-Link IE communication wiring
