ABB ACS880-01-246A-4 Variateur de fréquence

The ACS880-01 series is ABB’s flagship wall-mounted industrial single-drive variable frequency drive. Équipé de la technologie DTC Direct Torque Control auto-développée, il prend en charge plusieurs types de moteurs, y compris les moteurs asynchrones, permanent magnet synchronous motors and synchronous reluctance motors. Integrated with safety, communication and energy efficiency management functions, it serves as the standard drive solution for general industrial and process industries.

1. Breakdown of Model Code

`ACS880-01-246A-4`

1. ACS880: All-compatible industrial single-drive VFD series with standard DTC Direct Torque Control, power coverage ranging from 0.55 kW à 3200 kW across the full lineup.
2. -01: Wall-mounted single drive module design, available for direct wall mounting or cabinet installation with a compact single-drive form factor.
3. 246UN: Rated continuous output current of the VFD, 246 UN, the core reference parameter for motor matching and overload protection.
4. -4: Voltage class identifier, nominally designed for 480 V three-phase power grids, supporting wide input voltage from 380 V to 500 V for various power supply scenarios at home and overseas.
5. Core Electrical Technical Specifications
6. Power and Current Ratings

2. Performances de contrôle

Modes de contrôle: DTC Direct Torque Control, V/f Scalar Control, Contrôle vectoriel sans capteur

Torque Step Response: <5 ms in open-loop mode with minor speed fluctuation under load disturbance

Speed Control Accuracy: ±10% rated slip (open-loop); ±0.01% rated speed (closed-loop)

Compatible Motor Types: Asynchronous Induction Motors, Permanent Magnet Synchronous Motors, Synchronous Reluctance Motors, High-Speed Motors

III. Mechanical and Hardware Specifications

1. Standard Built-in Functions
2. Fonctions de sécurité: Standard STO Safe Torque Off function with SIL 3 / PL e safety level, no additional safety relays required.
3. Hardware Integration: Built-in Class C3 EMC filter, DC reactor and braking chopper, greatly reducing procurement and wiring work for peripheral accessories.
4. Stockage & Mise en service: Removable STC storage unit for one-click migration of parameters and programs; standard multi-language assistant control panel with Chinese language support.
5. Basic I/O Interfaces: 6 Entrées numériques (DEPUIS), 3 Sorties numériques (FAIRE), 2 Entrées analogiques (IA), 2 Analog Outputs (AU), reserved expansion interface for encoders.
6. Capacité de communication: Built-in Modbus RTU protocol and embedded web server, supporting remote monitoring and parameter configuration over local area networks.
7. Energy Efficiency Management: Built-in energy optimizer and energy consumption statistics, supporting sleep/wake-up and automatic energy-saving operation modes.
8. Comprehensive Protection Mechanisms: Complete protection against overcurrent, surtension, sous-tension, surcharge, surchauffe, défaut à la terre, court-circuit, motor phase loss, etc..
9. Comparison of Adjacent Models with the Same Voltage Class (-4 Série)

1. Core Selection Differences Between Suffix -3 et -4

Voltage suffixes must be distinguished carefully for domestic project selection to avoid mismatching motors and power grids:

> Conseil de sélection: Prioritize models with suffix -3 for standard domestic 380 V grids; suffixe -4 is mandatory for export equipment and 480 V power supply scenarios.

VII. Scénarios d'application typiques

Machines générales: Convoyeurs à bande, screw feeders, mélangeurs, concasseurs, overhead travelling cranes

Fluid Equipment: Ventilateurs centrifuges, axial fans, centrifugal water pumps, pompes à vide, screw compressors

Process Industry: Chemical reaction kettles, metallurgical roller tables, mine hoists, municipal water treatment, food packaging lines

Scénarios spéciaux: Export complete sets of equipment, production line renovation for overseas factories, mine and ship projects with 480 V power supply

VIII. Common Fault Troubleshooting Matrix

1. Ordering and Accessories Description

The order number of the base unit shall comply with results from ABB official selection tools; suffix coding rules for all series accessories are universal.

Common accessory suffixes:

+D150: Upgrade to ACS-AP-W Bluetooth assistant control panel for wireless commissioning via mobile phones/tablets

+B056: Standard factory-matched braking resistor

+E202: Upgrade to Class C2 EMC filter for harsh electromagnetic environments

+K475: PCB conformal coated board for humid, dusty and corrosive harsh environments

+N5050: Built-in Profinet industrial Ethernet communication module

+L502: Incremental encoder interface module for high-precision closed-loop speed control

Full Packing List of Standard Factory Package for ABB ACS880-01-246A-4 (R8 Frame, IP21 Standard Unit)

1. Core Main Unit (Fully Pre-Integrated from Factory)
2. ACS880-01-246A-4 Wall-Mounted VFD Main Unit (R8 Frame, IP21)

Factory pre-installed standard internal hardware:

ZCU-12 Main Control Unit (equipped with standard I/O terminals, STO Safe Torque Off circuit, RS485 Modbus and USB commissioning port)

Built-in DC Choke (DCL, standard for R5~R9 frames to suppress harmonics)

Built-in braking chopper (standard for R8 frame, only external braking resistor required)

Conformal coated control board (all standard deliveries come with coated boards)

Complete main power circuit, cooling fans and power terminal copper busbars

Integrated dedicated IP21 cable entry box with separate compartments for main circuit and control cables

2. ACS-AP-W Bluetooth Assistant Chinese Control Panel (Standard, Detachable)

Supports Bluetooth connection with Drive Composer commissioning software, Chinese/English language switching, parameter setting and fault log viewing.

1. Matching Installation Hardware Kit (Separate Small Packaging Bag)
2. Wall-mount fixing bolts and expansion screws for wall installation
3. Sealing cover for cable entry box, dustproof buckles, rubber cable sealing gaskets
4. Insulated protective cover for main power terminals and protective cover for control terminals
5. Lifting eye bolts (special for heavy-duty R6/R7/R8 frames for transportation and hoisting)
6. Extension mounting buckles for control panel (for external panel mounting on cabinet doors if needed)

III. Paper Documentation Package (Multi-Language Including Chinese)

1. ACS880-01 Quick Installation and Startup Guide (Chinese Version)
2. Multi-language safety warning manual (electrical safety, capacitor discharge, hoisting warnings)
3. Overall dimension drawings and terminal wiring schematic diagrams
4. Factory inspection certificate and product nameplate parameter sheet
5. Brief instructions for optional expansion modules (fieldbus cards, encoder cards, Cartes d'extension E/S)
6. Electronic Documentation CD

Full files contained in the CD:

1. Complete ACS880-01 hardware manual and firmware parameter manual (Chinois & English PDF)
2. Drive Composer PC commissioning software installation package
3. Supporting manuals and wiring drawings for all optional modules
4. Fault code lookup document and motor parameter identification guide
5. Protective Packaging Auxiliary Materials
6. Reinforced factory hard carton, load-bearing wooden pallet at bottom (standard wooden pallet for heavy-duty R8 frames for forklift handling)
7. Shockproof foam corner protectors and bottom buffer foam for the main unit
8. Plastic moisture-proof dust wrapping film and binding straps

Important Note: Optional Accessories Not Included in Standard Package (Separate Order Required)

1. External braking resistors and braking units
2. External EMC input/output filters
3. Fieldbus adapters (FENA-01 Profinet, FPBA-01 Profibus, etc.)
4. FEN-xx encoder interface modules, I/O expansion modules
5. IP55 protection enclosure kit (order code +B056)
6. Extension cables for cabinet door-mounted control panels
7. Input/output AC line reactors
8. Special customized kits for marine certification, explosion-proof and low-temperature applications

Supplementary Remarks

1. This list applies to base units with standard IP21 wall-mounted design without additional +Bxx/Cxx special options; if +Bxx/Cxx special options are added during ordering, corresponding accessory assemblies will be included in the package.
2. R8 frame (including 246A-4) features a heavy main unit with a standard wooden pallet in factory packaging; small frames R1-R5 are supplied without wooden pallets.
3. ACS-AP-W control panel is a mandatory factory standard accessory and will not be shipped separately. If the economical basic ACS-AP-S panel is required as replacement, specify it during ordering.

Official Overload Capacity Parameters of ACS880-01-246A-4 (Conditions de fonctionnement standard: 40 °C Ambient Temperature, Altitude ≤1000 m)

The overload capacity of this model is divided into two operation modes based on load characteristics: Light Overload (Variable Torque VT) and Heavy Overload (Constant Torque CT). All overload cycles last 5 minutes, with a hardware-limited instantaneous maximum current ceiling. The marking `246A` represents the VFD’s rated output current; voltage suffixes such as -3/-4 do not alter overload current parameters, only the matching motor power.

Key Supplementary Explanations

1. Hardware Current Limit Constraint: The peak output current of all operating scenarios is capped by IGBT hardware at maximum 350 UN; le 150% overload current of 309 A under heavy-duty mode is below this ceiling and fully deliverable.
2. Derating Rules:

If ambient temperature exceeds 40 °C, the rated output current is derated by 1% per 1 °C rise (max withstand temperature 60 °C), with synchronous reduction of overload capacity.

If installation altitude exceeds 1000 m, the rated output current is derated by 1% per 100 m elevation gain.

3. Mécanisme de protection: When overload duration or current exceeds specifications, the VFD will trigger an overload warning first; sustained violation will lead to `F0011` motor overload trip, combined with heatsink overtemperature protection for dual safety coverage.
4. Changement de mode: The two overload modes can be switched via parameter `22.02`. The selected mode must match actual load characteristics; prolonged operation beyond rated overload specifications accelerates aging of power components.

Full Cross-Brand Comparison Table for ABB ACS880-01-246A-4 (132 kW Usage intensif / 246 A CT)

Reference Unit: ACS880-01-246A-4

Core Reference Specifications: 380~500 V wide voltage, 132 kW CT heavy duty, heavy-duty rated current 206 UN, 150% surcharge pour 60 s; 160 kW VT light duty, light-duty current 234 UN, 110% surcharge pour 60 s; built-in DC reactor + Filtre CEM + braking chopper + STO safety function.

1. High-End Foreign Brand Counterparts (Original Imported / Top European & American Brands, Direct Replacement for Heavy-Duty Applications)

1. Domestic High-End Industrial Counterparts (Domestic Replacement with Equivalent Performance & Lower Cost)

1. Key Replacement Selection Differences & Risk Warnings
2. Critical Voltage Matching Notes

Reference ACS880-01-246A-4: 380~500 V wide voltage, dedicated for export and overseas 480 Équipement V;

The equivalent current model for standard domestic 380 V applications is ACS880-01-246A-3 (380~415 V).

For replacement selection, all matching models must carry suffix 4 (400 V wide voltage); narrow-range 380 V models are forbidden.

2. Built-in Hardware Differences (Key Points for Retrofit Replacement)
3. Standard built-in configuration of ABB ACS880: Réacteur à courant continu + Class C3 EMC filter + braking chopper + STO
4. Siemens G120C and Schneider ATV630 come with standard STO, but DC reactors are mostly optional and must be purchased separately for replacement to avoid excessive harmonic distortion.
5. Domestic MD880/CH2000 series feature built-in braking units, while DC reactors are optional for partial specifications.
6. Core Overload Capacity Comparison (Mandatory for Heavy-Duty Applications)

ABB Reference: CT heavy-duty baseline current 206 UN, 150% surcharge (309 UN) sustainable for 60 s

All high-end counterpart models (G120C / VTT630 / GA800 / MD880) deliver equivalent overload performance with heavy-duty current ranging from 202 Un à 208 UN

Economical ATV340 / G120XA lack the 150% heavy-duty profile and only support 110% light overload, leading to frequent tripping under impact loads.

4. Installation Dimension Reference

ACS880-01-246A-4 is R8 frame (963 × 681 × 386 mm, 58.6 kilos).

Siemens G120C and Schneider ATV630 models of identical power have smaller footprints with no cabinet expansion required for retrofits; domestic MD880 dimensions are close to ABB, allowing shared mounting cutouts.

1. Quick Selection Conclusion
2. Heavy Industry / Mixing / Convoyage / Levage (Constant Torque Heavy Duty): Prioritize Siemens G120C, Schneider ATV630 and Inovance MD880 for fully equivalent replacement in current rating, overload capacity and functions.
3. Export Equipment / Overseas 480 V Power Supply: Must select wide-voltage models with suffix -4; narrow-range 380 V units are prohibited.
4. Ventilateurs & Pompes (Light Duty Without Impact): Economical ATV340 and G120XA are available at lower cost.
5. Demand for Original Same Platform, DTC Control and Factory Integrated Solution: Directly adopt the same series ACS880-01-246A-4.
